13. Insert the front retainer of the window into the doorchannel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do
so can result in wind and water leaks or damage to
the window.
14. Insert the retainer along the bottom edge of thewindow into the bottom side channel, beginning at
the front and working to the rear of the vehicle.
Finish by closing the zipper completely and attaching
1 — Incorrect Insertion
2 — Correct Insertion
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 287

the Velcro along the top and rear of the window.
Repeat this step for the opposite side.
288 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

15. Locate the black swing gate bar. Slide the swing gatebar over the receiver at the bottom inside of the rear
window. The spongy part of the seal should be down
and pointed outward to seal with the swing gate
when closed. 16. Install the rear window by starting both zipper ends
at the lower left corner of the rear window opening.
Ensure that the zippers are properly started and
aligned before zipping to prevent damage.
17. Run the first zipper fully around to the right side of the window.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 289

18. Grasp the swing gate bar and position it into theswing gate brackets. 19. Insert the rear window retainer into the swing gate
bracket on both the left and right sides.
290 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

20. Complete the installation of the sail panel by insert-ing the rest of the retainer into the body channel.
21. Close the header latches and return the sun visors to their secured position.SUNRIDER (FOUR-DOOR MODELS) — IF
EQUIPPED
CAUTION!
Operating the top, opening a door or lowering a
window while the top is wet may allow water to drip
into the vehicle’s interior.
NOTE: If you are going to be driving faster than 40 mph
(64 km/h) with the Sunrider feature open, it is recom-
mended that you remove the rear window of the vehicle.3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 291

Opening The Sunrider
1. Unclip and move the sun visors to the side.
2. Release the header latches from the loops on thewindshield frame. 3. Make sure to slide the plastic sleeves forward to
unlock the Sunrider links.
292 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4. Grasp the front side bow behind the header, and liftthe top. 5. Fold back the front section of the top and gently rest
the header on top of the rear portion of the deck.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 293

6. Fold the top so that the material forms aWas shown.
Enter the vehicle and move the material into two folds. 7. Secure the top by using the two provided straps. Each
strap will wrap around the side bow and Velcro to
itself; use one strap on each side of the vehicle.
