2016 Citroen JUMPER Owner's Manual

183
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
Touch screen Audio-Telematic system
Multimedia audio system - Bluetooth® telephone - GPS navigation
Contents
First steps
1 84
Glossary


185
Steering mounted controls

1
86
Menus
187
ra

dio

188
DAB (Digital Audio Broadcasting) radio

1
92
Media


19 4
na

vigation
2
02
Telephone


206
Vehicle information
2

10
Settings


212
Voice commands

2
22
The system is protected in such a way that it will only operate in
your vehicle. As as safety measure, the driver must only carry out operations
which require prolonged attention while the vehicle is stationary.
When the engine is switched off and to prevent discharging of
the battery, the system switches off following the activation of
the energy economy mode.
Touch Screen Audio - Telematic System
AUDio and TELEMATiCS
10

184
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
First steps
Use the buttons arranged below the touch
screen for access to the main menus, then
press the virtual buttons in the touch screen.in very hot conditions, the volume
may be limited to protect the system.
re

turn to the initial situation take place
once the temperature in the passenger
compartment drops.
The system may also go into standby
(screen and sound completely off) for a
minimum period of 5 minutes.
Touch Screen Audio - Telematic System

185
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
Screen off / on.
Activate, deactivate, adjust certain
system and vehicle functions. Eject CD.
Mute / restore volume (mute / pause).
Abandon the current operation.
Go up one level (menu or folder). Press: on / off.
Rotate: adjust the volume
(each source is independent).
Radio, rotate: search for a radio
station.
Media, rotate: select the previous /
next track.
Press: confirm the option displayed in
the screen.The screen is of the "resistive" type, it
is necessary to press firmly, particularly
for "flick" gestures (scrolling through a
list, moving the map...). A simple wipe
will not be enough. pressing with more
than one finger is not recognised.
The screen can be used when wearing
gloves. This technology allows use at
all temperatures.
To clean the screen, use a soft
non-abrasive cloth (spectacles cloth)
without any additional product.
Do not use pointed objects on the
screen.
Do not touch the screen with wet
hands.
Glossary
Menu
item Significance /
co rresponding
action
V
o
LU
ME Adjust the volume by rotation.
rA

D io
A
ccess the radio menu.
MED
iA A

ccess the media menu and the
different audio sources.
nAV A

ccess the navigation menu.
PH
o

n
E A

ccess the telephone menu.
M
or
E A

ccess vehicle information.
B
r

o
W
SE
TU
n E
SC
roL

LTurn the button to:
-

m
ove in a menu or a list.
-

s
elect a radio station.
E
nT

E r
C
onfirm an option displayed in
the screen by pressing.
Touch Screen Audio - Telematic System
AUDio and TELEMATiCS
10

186
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
Steering mounted controls
Pause / restore the CD, USB/iPod,
Bluetooth® sources.
Mute / restore sound from the radio.
Switch the microphone off / on during
a telephone call.
Switch voice recognition on.
in

terrupt a voice message to start a
new voice command.
i

nterrupt voice recognition.
Push up or down: increase or
decrease the volume for voice
announcements and music sources,
hands-free and speaking texts. Accept an incoming call.
Accept a second incoming call and
put the current call on hold.
Switch on voice recognition for the
telephone function.
in

terrupt a voice message to issue
another voice command.
i

nterrupt voice recognition. Radio, push up or down: select the
next / previous station.
Radio, hold up or down: sweep
frequencies up / down until the button
is released.
Media, push up or down: select the
next / previous track.
Media, hold up or down: fast for ward

/
b

ack until the button is released.
rej

ect the incoming call.
End the call in progress.
Touch Screen Audio - Telematic System

187
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
Menus
navigation
Mediarad
io
Settings
tel

ephone Vehicle information
Settings for the navigation system and select a
destination.
Select from the different music sources.
Activate, deactivate, and adjust certain
functions.
Select from the different radio sources.
Activate, deactivate, and adjust certain
functions.
Activate, deactivate, and adjust certain
functions.
Connect a mobile telephone via Bluetooth
®.
Access to the ambient temperature, the clock,
the compass and the trip computer.
Touch Screen Audio - Telematic System
AUDio and TELEMATiCS
10

188
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
radio
Level 1Level 2Level 3
Touch Screen Audio - Telematic System

189
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
Level 1Level 2 Level 3co mment
rAd

IO Briefly press the buttons for an automatic search.
Press and hold the buttons for a quick search.
rAd

IO
Preset Make a long press on the button to present the
current radio station.
The current station is highlighted.
Press the "All" button to display all of the preset
radio stations in the waveband selected.
rAd

IO
n

avigate List of stations
Selection a station with a press.
Update the list according to reception.
Press these buttons to scroll through the radio
stations received.
Go directly to the desired letter in the list.
rAd

IO
AM/FM/
d
A
B
ch
oose the waveband Choose the waveband
rAd

IO
Adjustment
dir

ect adjustment The screen virtual keypad can used to enter a
single number corresponding to a station.
The symbols allow precise adjustment of the
frequency.
rAd

IO
Info Information
Display information on the current radio station.
Touch Screen Audio - Telematic System
AUDio and TELEMATiCS
10

190
jumper_en_Chap10a_Autoradio-Fiat-tactile-1_ed01-2015
Level 1Level 2Level 3
Touch Screen Audio - Telematic System
