CAUTION!
Do not use Alcohol and Alcohol-based and/or Keton
based cleaning products to clean leather seats, as
damage to the seat may result.
Cleaning Headlights
Your vehicle is equipped with plastic headlights and fog
lights that are lighter and less susceptible to stone break-
age than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPAR Glass Cleaner, or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or windows
equipped with radio antennas. Do not use scrapers or
other sharp instrument that may scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or cloth that you are using. Do not spray cleaner
directly on the mirror.
7
MAINTAINING YOUR VEHICLE 623

Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft cloth. A mild soap solution maybe used, but do not use high alcohol content or
abrasive cleaners. If soap is used, wipe clean with a
clean damp cloth.
2. Dry with a soft cloth.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage can also weaken the fabric. If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the
vehicle to wash them. Dry with a soft cloth.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
WARNING!
A frayed or torn belt could rip apart in a collision and
leave you with no protection. Inspect the belt system
periodically, checking for cuts, frays, or loose parts.
Damaged parts must be replaced immediately. Do
not disassemble or modify the system. Seat belt
assemblies must be replaced after a collision if they
have been damaged (i.e., bent retractor, torn web-
bing, etc.).
624 MAINTAINING YOUR VEHICLE

FUSES
WARNING!
•When replacing a blown fuse, always use an ap-
propriate replacement fuse with the same amp
rating as the original fuse. Never replace a fuse
with another fuse of higher amp rating. Never
replace a blown fuse with metal wires or any other
material. Failure to use proper fuses may result in
serious personal injury, fire and/or property dam-
age.
• Before replacing a fuse, make sure that the ignition
is off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
(Continued)
WARNING! (Continued)
•If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
7
MAINTAINING YOUR VEHICLE 625

Power Distribution Center (Fuses)
The Power Distribution Center is located in the engine
compartment near the battery. This center contains car-
tridge fuses, mini-fuses, micro-fuses, circuit breakers and
relays. A label that identifies each component is printed
on the inside of the cover.
Cavity Cartridge FuseBlade FuseDescription
F06 – – Not Used
F07 – – Not Used
F08 –25 Amp Clear Engine Control Module (ECM)/Fuel Inj.
F09 – – Not Used
Power Distribution Center
626 MAINTAINING YOUR VEHICLE

Cavity Cartridge FuseBlade FuseDescription
F10 –20 Amp Yellow Power Transfer Unit (PTU) –
If Equipped
F11 – – Not Used
F12 –20 Amp Yellow Brake Vacuum Pump – If Equipped
F13 –10 Amp Red Engine Control Module (ECM)/VSM
(Engine Stop/Start Only)
F14 –10 Amp Red Drivetrain Control Module (DTCM)/
Power Transfer Unit (PTU) – If
Equipped/RDM/Brake System Module (BSM)/Brake Pedal Switch/EPB (Electric Park Brake)
F15 – – Not Used
F16 –20 Amp Yellow Ignition Coil
F17 – – Not Used
F18 – – Not Used
F19 40 Amp Green –Starter Solenoid
7
MAINTAINING YOUR VEHICLE 627

Cavity Cartridge FuseBlade FuseDescription
F20 –10 Amp Red A/C Compressor Clutch
F21 – – Not Used
F22 – 5 Amp Tan Radiator Fan Enable
F23 – 70 Amp Tan Body Controller Module (BCM) –
Feed 2
F23 –50 Amp Red Voltage Stability Module (VSM) #2 –
If Equipped With Engine Stop/Start Option
F24 – – Not Used
F25B –20 Amp Yellow Front Washer Pump – If Equipped with
Engine Stop/Start Option
F26 – – Not Used
F27 – – Not Used
F28 –15 Amp Blue Transmission Control Module (TCM)
F29 – – Not Used
628 MAINTAINING YOUR VEHICLE

Cavity Cartridge FuseBlade FuseDescription
F30 –10 Amp Red Engine Control Module (ECM)/EPS/
Fuel Pump Relay Feed
F31 – – Not Used
F32 – – Not Used
F33 – – Not Used
F34 – – Not Used
F35 – – Not Used
F36 – – Not Used
F37 50 Amp Red –Radiator Fan PWM Controller
F38 – – Not Used
F39 40 Amp Green –HVAC Blower Motor
F40 – – Not Used
F41 50 Amp Red –Voltage Stability Module (VSM) #1 –
If Equipped With Engine Stop/Start Option
7
MAINTAINING YOUR VEHICLE 629

Cavity Cartridge FuseBlade FuseDescription
F41 60 Amp Yellow —Body Controller Module (BCM) –
Feed 1
F42 – – Not Used
F43 –20 Amp Yellow Fuel Pump Motor
F44 – – Not Used
F45 30 Amp Pink –Passenger Door Module (PDM) – If
Equipped
F46 25 Amp Clear –Sunroof – If Equipped
F47 – – Not Used
F48 30 Amp Pink –Driver Door Module (DDM)
F49 30 Amp Pink –Power Inverter (115V A/C) – If
Equipped
F50 30 Amp Pink –Windshield Wiper Smart Motor
(WWSM)
F51 – – Not Used
