Power Distribution Center (Fuses)
The Power Distribution Center is located in the engine
compartment near the battery. This center contains car-
tridge fuses, mini-fuses, micro-fuses, circuit breakers and
relays. A label that identifies each component is printed
on the inside of the cover.
Cavity Cartridge FuseBlade FuseDescription
F06 – – Not Used
F07 – – Not Used
F08 –25 Amp Clear Engine Control Module (ECM)/Fuel Inj.
F09 – – Not Used
Power Distribution Center
626 MAINTAINING YOUR VEHICLE

Cavity Cartridge FuseBlade FuseDescription
F30 –10 Amp Red Engine Control Module (ECM)/EPS/
Fuel Pump Relay Feed
F31 – – Not Used
F32 – – Not Used
F33 – – Not Used
F34 – – Not Used
F35 – – Not Used
F36 – – Not Used
F37 50 Amp Red –Radiator Fan PWM Controller
F38 – – Not Used
F39 40 Amp Green –HVAC Blower Motor
F40 – – Not Used
F41 50 Amp Red –Voltage Stability Module (VSM) #1 –
If Equipped With Engine Stop/Start Option
7
MAINTAINING YOUR VEHICLE 629

In Mexico Contact
Av. Prolongacion Paseo de la Reforma, 1240
Sante Fe C.P. 05109
Mexico, D. F.
In Mexico City: 5081-7568
Outside Mexico City: 1-800-505-1300
Puerto Rico And U.S. Virgin Islands
Customer Service Chrysler International Services LLC
P.O. Box 191857
San Juan 00919-1857
Tel.: (787) 782-5757
Fax: (787) 782-3345
Customer Assistance For The Hearing Or Speech
Impaired (TDD/TTY)
To assist customers who have hearing difficulties, the
manufacturer has installed special TDD (Telecommuni-
cation Devices for the Deaf) equipment at its customer
center. Any hearing or speech impaired customer, who
has access to a TDD or a conventional teletypewriter
(TTY) in the United States, can communicate with the
manufacturer by dialing 1-800-380-CHRY.
Canadian residents with hearing difficulties that require
assistance can use the special needs relay service offered
by Bell Canada. For TTY teletypewriter users, dial 711
and for Voice callers, dial 1-800-855-0511 to connect with
a Bell Relay Service operator.
Service Contract
You may have purchased a service contract for a vehicle
to help protect you from the high cost of unexpected
repairs after the manufacturer’s New Vehicle Limited
9
