2015 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

Lift points for the vehicle

Fig. 152 Front lift point for workshop hoist or floor jack.

Fig. 153 Rear lift point for workshop hoist or floor jack.
The vehicle may only be raised at the lift points shown in illustrations ⇒ fig. 152 and ⇒ fig. 153. If the
vehicle is lifted at different points, vehicle damage ⇒  and serious injuries may occur ⇒ .
Workshop hoists that use fluid cushions (receiving platforms) must not be used for lifting the vehicle.
There are many precautions that have to be followed when lifting a vehicle on a workshop hoist or floor jack. Do not try to lift a vehicle on a workshop hoist or floor jack unless you have the training, knowledge, and experience to be able to do so safely.
Information about lifting the vehicle with the vehicle jack ⇒  Lifting the vehicle with the vehicle jack.

WARNING
Improperly lifting your vehicle with a workshop hoist or a floor jack can cause the vehicle to fall off and cause serious personal injury.
x Always read and heed the operating instructions from the floor jack manufacturer and legal regulations if necessary before using the floor jack to lift the vehicle.
x Never let anyone stay in the vehicle when it is being lifted or when it is off the ground.
x Always lift your vehicle only at the designated lift points shown in the illustrations
⇒ fig. 152 and ⇒ fig. 153. Not using the designated lift points can cause the vehicle to fall off the floor jack when heavy parts such as the engine or transmission are removed.
x Always make sure that the vehicle's lift points lie as flat as possible and centered on the carrier plates of the floor jack.
x Never start the engine when you have raised the vehicle on the floor jack. The engine vibrations and vehicle movements could knock the vehicle off the floor jack.
x If you must work under a vehicle raised on a floor jack, always make sure that the vehicle is safely supported on safety stands intended for that purpose that are strong enough to support the weight of the vehicle.
x Never use the floor jack as a ladder or step ladder.
x Always make sure that the weight of the vehicle is not heavier than the lifting capacity of the floor jack and safety stands being used.
NOTICE
x To help prevent serious vehicle damage, never lift the vehicle by the engine oil pan, transmission housing, or by the front or rear axles or suspension.
x To help prevent damage to the underbody or chassis, always insert a rubber pad between the hoist and the lifting points. In addition make sure the lifting arms have enough clearance.
x The lifting arms should not touch side sills or other parts of the vehicle.

In an emergency

Protecting yourself and the vehicle

Fig. 154 In the center of the instrument panel: Button for the emergency flashers.

Switch on the emergency flashers when:
x Traffic suddenly slows down or stops in front of you to warn those approaching from behind.
x In any emergency situation.
x If the vehicle breaks down.
x When being towed.
Always obey traffic laws that govern the use of emergency flashers where you are driving.
If the emergency flashers are not working, a different method – as permitted by law – must be used to alert other motorists and cyclists to the breakdown.
WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.
WARNING
The vehicle exhaust system and the catalytic converter or diesel particulate filter get very hot. They can cause fires and serious personal injury.
x Never park where parts of the hot exhaust system or catalytic converter could ignite flammable materials, such as dry grass, brush, leaves, spilled fuel, etc.
NOTICE
To help prevent damage to the vehicle if you should have to push it a short distance by hand, never push against spoilers, lights, body panels, windows, or similar parts. Concentrating force on these parts of the vehicle can cause expensive damage that may not always be obvious right away.
The vehicle battery will be drained if the emergency flashers are on for a long time – even if the ignition is switched off.

Emergency closing and opening

WARNING
Before using the emergency procedure to close the convertible top, park the vehicle as far away from moving traffic as possible. If necessary, switch on the emergency flashers and set up a warning triangle. Obey all applicable legal requirements.
NOTICE
If the vehicle's battery fails or the power windows won't work, the door windows are not lowered when the door is opened or closed. Always close and open the door carefully to help prevent damage to the window, the paint, or the rubber seal.
NOTICE
To help prevent vehicle damage, carefully remove and properly reinstall parts after emergency locking or unlocking.
Manually unlocking and locking the driver door

Fig. 155 Door handle on driver door: Concealed lock cylinder.

Special considerations when unlocking:
x If the vehicle is equipped with an anti-theft alarm system, the system remains activated for the
unlocked vehicle. But the alarm is not triggered at first ⇒  Power locking system.
x Open the driver door. The alarm will sound.
x Switch on the ignition. For vehicles with Keyless Access, deactivate the alarm by holding the
remote control vehicle key to the right of the steering column trim and pressing the starter button ⇒  Starting and stopping the engine, if necessary. The electronic immobilizer recognizes a valid remote control vehicle key when the ignition is switched on and deactivates the anti-theft alarm system.
The driver door can be unlocked separately from the inside the vehicle by pulling the door
handle to open the door ⇒  Unlocking or locking the vehicle from the inside.
The anti-theft alarm system, when installed, is not activated when the vehicle is locked manually
with the key bit ⇒  Anti-theft alarm system.
Manually locking the passenger door

Fig. 156 On the edge of the passenger door: Manually locking the door with the vehicle key.
