2015 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

– Travel time
– Curr. consump. (current fuel consumption)
– Avg. consump. (average fuel consumption)
– Route
– Odometer
– Average speed
– Digital speed (digital speed display)
– Oil temp.
– Coolant temp.
– Speed warning
– Back
▪ Lights & Vision
– Coming Home
– Leaving Home
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Units
– Temperature
– Consump./dist.
– Back
▪ Service
– Info
– Back
▪ Factory setting
Using the instrument cluster menus

Fig. 18 On the right side of the steering column (vehicles without a multi-function steering wheel): Windshield wiper lever with controls for instrument cluster menus and displays.

Fig. 19 Right side of the multi-function steering wheel (if equipped): Controls for the menus in the instrument cluster.

Main menus (Premium version)

When the ignition is switched on and memory 1 or 2 is displayed, press the /+

Display Function
Odometer The odometer indicates the total distance driven by the vehicle.
Average speed -- mph Average speed on trips per trip memories 1 and 2 (toggle). Displayed once the vehicle has been driven about 300 feet (100 m). Until then, dashes may appear instead of a number. The value displayed is updated every 5 seconds. Average speed -- km/h
-- mph Digital display of the current vehicle speed.
-- km/h
Oil temperature Current engine oil temperature (digital display).
Coolant temperature Coolant temperature (digital display).
Speed warning --- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display.
Speed warning --- km/h

Switching between the displays
x Vehicles without a multifunction steering wheel: Press the rocker switch 42)0 in the windshield wiper
lever ⇒ fig. 18 (2).
x Vehicles with a multifunction steering wheel: Press the * or the + button ⇒ fig. 19.
Storing speed for the speed warning
x Select the Speed warning -- mph or Speed warning -- km/h display.
x Press the /+

Settings menu (Premium version)

Volkswagen Car-Net: Connecting you and your
vehicle

WARNING
Driver distraction causes accidents, collisions and serious personal injury! Using application software and Volkswagen Car-Net services while driving can distract the driver from traffic.
x Always drive attentively and responsibly.
Volkswagen Car-Net service
