2015 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

WARNING
Some kinds of cigarette lighters can be lit unintentionally, or crushed causing a fire that can result in serious burns and vehicle damage.
x Always make sure that there are no lighters in the seat tracks or near other moving parts before adjusting the seats.
x Before closing a storage compartment, always make sure that no cigarette lighter can be activated, crushed, or otherwise damaged.
x Never leave a cigarette lighter in a storage compartment, on the instrument panel, or in other places in the vehicle. Heat buildup in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. High temperatures could cause the cigarette lighter to catch fire.
Examples of improper seating positions

WARNING
Contact with parts of the vehicle interior can cause serious personal injury in a crash.
x Always make sure that all vehicle occupants stay in a proper seating position and are properly restrained whenever the vehicle is moving.
x Improper seating positions increase the risk of serious and fatal injury, especially when an airbag deploys and strikes a passenger in an improper seating position.
Proper seating position

Fig. 42 The driver should never sit closer than 10 inches (25 cm) of the steering wheel.

Fig. 43 Proper safety belt positioning and head restraint adjustment.

For your own safety and to reduce injuries in the event of sudden braking maneuvers or accidents, Volkswagen recommends the following seating positions:
Applies to all vehicle occupants:
x Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Position the back of your head as close as possible to the head restraint ⇒ fig. 42 and ⇒ fig. 43.
x Push the head restraint completely down for short people, even if the top of the head is then below the upper edge of the head restraint.
x Tall people should pull the head restraint all the way up.
x Adjust the seat backrest angle to an upright position so that your back is in full contact with it when the vehicle is moving.
x Always keep both feet on the floor and in the footwell whenever the vehicle is moving.
x Always adjust and fasten safety belts properly ⇒  Safety belts.
Driver - seat and steering wheel adjustment:
x Adjust the steering wheel so that there are at least 10 inches (25 cm) between the steering wheel
and your breast bone ⇒ fig. 42. When adjusting the proper distance to the steering wheel, grasp the top of the steering wheel with your elbows slightly bent.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag inflates.
x Adjust the steering wheel so that the steering wheel cover points at your chest and not at your face. Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help protect you in a collision.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping your knee(s) slightly bent.
x Adjust the seat height so that the top point of the steering wheel can be reached.
x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the airbag is deployed.

Manual controls on the driver and front passenger seats

Fig. 44 Controls on the left front seat.

Adjusting the front and rear head restraints

Fig. 45 Adjusting the head restraints.

WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash.
x Every person in the vehicle must have a properly adjusted head restraint to minimize the risk of neck injury in a crash. Each head restraint must be adjusted according to the occu-pants' size so that the upper edge is even with the top of the person's head, but no lower than eye level. Always sit so that the back of your head is as close as possible to the head re-straint.
x Never adjust head restraint while driving.
Removing and reinstalling the head restraints

Fig. 46 Removing the front head restraints.

Fig. 47 Removing the rear head restraints.

Removing the front head restraints
x Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the
way up ⇒  in Adjusting the front and rear head restraints. Recline the backrest with the head re-straint so that there is enough overhead clearance to remove it.
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 46 (1) to unlock the head restraint.
x Push the flat object (plastic card) in against the guide rod to depress a release button located under the cap (not visible).
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The right-hand guide rod is now released.
x To release the left-hand guide rod, press button (2) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (2).
Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Adjust the head restraint according to the occupant's size ⇒  Adjusting the front and rear head restraints.
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward ⇒  Luggage compartment.
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 47 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward ⇒  Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size ⇒  Adjusting the front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are proper-ly protected.

NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle could otherwise be damaged.
Adjusting the steering wheel position

Fig. 48 Manual adjustment for the steering wheel position.
