2015 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

Displays (Premium version)

Fig. 16 In the instrument cluster display: A: Open engine hood, B: Open luggage compartment lid, C: Open driver door.

Key to ⇒ fig. 16 See
C

Compass display (if applicable)
On vehicles equipped with compass display, the current compass direction is indicated in the instru-ment cluster display when the ignition and navigation system are switched on.
Selector lever positions (automatic transmission)
The selector lever position is shown both on the side of the selector lever and in the instrument cluster display. The respective gear may also be shown in the instrument cluster display in Drive (D) and
Sport Drive (S), as well as in Tiptronic® mode ⇒  Shifting.
Gear recommendation
When the vehicle is moving, a fuel economy gear recommendation may appear in the instrument
cluster display ⇒  Shifting.
Engine identification code
Press and hold the /./

Service reminder display

Vehicles with Basic display:
1. Switch off the ignition.
2. Push the /./

Vehicles with Basic display:
6. Switch off the emergency flashers.

Do not reset the service reminder between service intervals; otherwise incorrect information will be displayed.
The service reminder disappears after a few seconds or after the /+

Volkswagen Information System

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, and program-ming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Menu structure – overview (Basic version)
