2015 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

Front passenger side overview

Fig. 9 Overview of the front passenger side.
Key to fig. 9:
(1) Passenger front airbag location in the instrument panel (approximate)
(2) Opening handle for the upper glove compartment (if equipped)
(3) Opening handle for the lower glove compartment
(4) Air vents  –

Symbols on the roof console

Fig. 11 In the roof console: Button for opening and closing the convertible top.

Symbol Meaning
* /   Interior and reading lights

/ a 3-button module for vehicles without Car-NetTM ⇒ Booklet Mobile
Phone Package.
• > • 3-button module for vehicles with Car-NetTM

Instrument cluster

WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver distrac-tion causes accidents, collisions and serious personal injury!
x Never set the stopwatch when the vehicle is moving.
NOTICE
To help prevent engine damage, always avoid high engine speeds, full throttle acceleration and heavy engine loads when the engine is cold.
The digital clock is set using the buttons in the instrument cluster
Displays and warning lights (Basic version)

Fig. 15 In the instrument cluster display (examples): A: Open engine hood, B: Open luggage compartment lid, C: Open driver door.

Key to ⇒ fig. 15 See
A

Selector lever positions (automatic transmission)
The selector lever position is shown both on the side of the selector lever and in the instrument cluster display. The respective gear may also be shown in the instrument cluster display in Drive (D) and
Sport Drive (S), as well as in Tiptronic® mode ⇒  Shifting.
Gear recommendation
When the vehicle is moving, a fuel economy gear recommendation may appear in the instrument
cluster display ⇒  Shifting.
Engine identification code
Press and hold the /./
