Headrestraint HeadrestraintHeadrestraint Headrestraint
Headrestraint
The front seats have headrestraint. They protect front seat occupants
from whiplash and other injuries in the event of impact. For best
protection, adjust the centre of the headrestraint so that it is in the
same level as your ears.
Drivers seat occupant should not adjust headrestraint while driving.
It is unsafe.
To raise headrestraint, pull it upward.
To lower, push the headrestraint down.
CAUTION CAUTIONCAUTION CAUTION
CAUTION
Ensure headrestraint are adjusted before driving.
Take care of electrical wiring for LCD monitor, while removing
the headrestraint.
Middle Seat (60:40) Middle Seat (60:40)Middle Seat (60:40) Middle Seat (60:40)
Middle Seat (60:40)
Middle seat is in 2 parts (60:40). Space for two occupants is at RH
side and space for single occupant is at the LH side. These seats can
be independently folded, as & when required for carrying long
objects. The RH side seat backrest is provided with latch for folding
at RH back and LH side seat back is provided with latch for folding at
LH back. Pulling the latch to the front allows the seat back to fold.
For keeping the seat back upright just push back the seat up till it
gets locked in the latch pin.
COMFORT AND CONVENIENCE
Middle seat
HEADRESTR HEADRESTRHEADRESTR HEADRESTR
HEADRESTR
AINT AND MIDDLE SEA AINT AND MIDDLE SEAAINT AND MIDDLE SEA AINT AND MIDDLE SEA
AINT AND MIDDLE SEA
T TT T
T
Poor Adjustment Good Adjustment
ProCarManuals.com

58
Folding of Middle Seat Folding of Middle SeatFolding of Middle Seat Folding of Middle Seat
Folding of Middle Seat
The seat base is provided with folding arrangement so that you can fold
the rear seat forward. To fold the rear seat, first delatch seat back by
pulling lever (1) and rest on the seat base.
After rear seat backs are folded pull the lever (2) provided at the seat
base sides and take the respective seat base up so that it is vertical.
To keep seat base horizontal, simply push back the seat base.
This folding feature gives additional space for keeping luggage.
Arm Rest cum Cup Holder Arm Rest cum Cup HolderArm Rest cum Cup Holder Arm Rest cum Cup Holder
Arm Rest cum Cup Holder
Arm rest cum cup holder is provided at the centre of middle passenger
seat backrest.
To use as an armrest - Pull out the strap at the top end and rest it on the
seat in horizontal position.
To open cup holder - Press the knob to open the arm rest lid and
swing out the cup holders.
Place back the cup holder into the arm rest box and close the
lid,when it is not in use.
COMFORT AND CONVENIENCEMIDDLE SEA MIDDLE SEAMIDDLE SEA MIDDLE SEA
MIDDLE SEA
T AND ARM REST CUM CUP HOLDER T AND ARM REST CUM CUP HOLDERT AND ARM REST CUM CUP HOLDER T AND ARM REST CUM CUP HOLDER
T AND ARM REST CUM CUP HOLDER
Arm RestCup Holder
ProCarManuals.com

59
Jump Seat (if fitted) Jump Seat (if fitted)Jump Seat (if fitted) Jump Seat (if fitted)
Jump Seat (if fitted)
The jump seats with hinges are provided at the rear side of the
vehicle. Jump seats can be folded to get increased luggage space
when needed.
T TT T
T
o oo o
o
ols olsols ols
ols
Tools are placed on floor below the (RHS) rear seat. To access the
tools fold the rear seat forward, set aside the floor carpet.
Rotate the pinion anticlockwise & take out the tools. Rotate the
pinion clockwise to fit against the seat.
Jack JackJack Jack
Jack
Jack is placed in
vehicle below the right hand side rear jump seat,
which can be accessed by opening the tail gate.
Jack
COMFORT AND CONVENIENCEJUMP SEA JUMP SEAJUMP SEA JUMP SEA
JUMP SEA
T TT T
T
,, ,,
,
JA JA JA JA
JA
CK AND CK AND CK AND CK AND
CK AND
T TT T
T
OOLS OOLSOOLS OOLS
OOLS
ProCarManuals.com

60
COMFORT AND CONVENIENCE
Motorised Rear View Mirror Motorised Rear View MirrorMotorised Rear View Mirror Motorised Rear View Mirror
Motorised Rear View Mirror
Motorised Rear View Mirrors are fitted on both front doors and can
be adjusted to the desired position with the help of a switch provided
on the driver side door.
Motorised Rear View Mirrors allow the driver to adjust the mirrors
without lowering the glasses and without moving from his position.
1. Move the main switch to L (for left side) and R (for right side)
2. Use the 4 positions of the knob to adjust the rear view mirrors to
correct angles.
These mirrors are provided with demister. The switch is commonised
with Rear windshield demister.
C CC C
C
igar igarigar igar
igar
ett ettett ett
ett
e Ligh e Lighe Ligh e Ligh
e Ligh
t tt t
t
er and A er and Aer and A er and A
er and A
sh sh sh sh
sh
T TT T
T
r rr r
r
a aa a
a
y (F y (Fy (F y (F
y (F
r rr r
r
on onon on
on
t) t)t) t)
t)
With ignition switch in ‘ACC’ position, press the cigarette lighter fully in.
When heated to specified temperature it pops out. Take the lighter out and
light your cigarette. After use place the lighter in its position.
NOTICE NOTICENOTICE NOTICE
NOTICE
Do not insert any other part or accessory in cigarette lighter slot. It
may damage cigarette lighter.
Do not attempt to touch the hot coil. It may cause scalding.
Ash tray is provided near cigarette lighter for occupants of front seats .
To open ash tray press the lid gently.1. Cigarette Lighter 2. Ashtray1
MO MOMO MO
MO
T TT T
T
ORISED REAR ORISED REAR ORISED REAR ORISED REAR
ORISED REAR
VIE VIEVIE VIE
VIE
W MIRR W MIRRW MIRR W MIRR
W MIRR
OR AND CIGARET OR AND CIGARETOR AND CIGARET OR AND CIGARET
OR AND CIGARET
TE LIGHTER & ASH TE LIGHTER & ASH TE LIGHTER & ASH TE LIGHTER & ASH
TE LIGHTER & ASH
TR TRTR TR
TR
A AA A
A
Y YY Y
Y
Motorised Rear View Mirror Switch
ProCarManuals.com

61
C CC C
C
igar igarigar igar
igar
ett ettett ett
ett
e Ligh e Lighe Ligh e Ligh
e Ligh
t tt t
t
er and A er and Aer and A er and A
er and A
sh sh sh sh
sh
T TT T
T
r rr r
r
a aa a
a
y (R y (Ry (R y (R
y (R
ear) ear)ear) ear)
ear)
The cigarette lighter is also provided on the console (below air vents).
Ash tray is also provided near cigarette lighter for occupants of rear
seats.
To open ash tray pull it out by sliding.
F FF F
F
uel uel uel uel
uel
T TT T
T
ank F ank Fank F ank F
ank F
lap laplap lap
lap
It is operated by the switch provided on the dash board centre panel.
To open the fuel tank flap press the operating switch. The solenoid
provided near the fuel tank flap releases the fuel tank flap open. To
close the fuel tank flap just push the flap manually to its original position.
In case of battery run down the fuel tank flap can be opened manually.
First open the tail gate and pull the nylon rope to open the fuel flap.
COMFORT AND CONVENIENCE
2
1
1. Cigarette Lighter 2. Ashtray
CIGARET CIGARET CIGARET CIGARET
CIGARET
TE LIGHTER & ASH TE LIGHTER & ASH TE LIGHTER & ASH TE LIGHTER & ASH
TE LIGHTER & ASH
TR TRTR TR
TR
A AA A
A
Y AND FUEL Y AND FUEL Y AND FUEL Y AND FUEL
Y AND FUEL
T TT T
T
ANK FL ANK FLANK FL ANK FL
ANK FL
AP APAP AP
AP
ProCarManuals.com

62
Mechanically operated fuel tank flap (if fitted) Mechanically operated fuel tank flap (if fitted)Mechanically operated fuel tank flap (if fitted) Mechanically operated fuel tank flap (if fitted)
Mechanically operated fuel tank flap (if fitted)
Fuel tank flap opening lever is provided below driver seat on right hand
side. To open flap, pull the lever up and to lock simply close the flap.
Glove Box Glove BoxGlove Box Glove Box
Glove Box
Glove box is located on the co-driver’s side of the dashboard. The
glove box can be locked by the key common for ignition and door.
The glove box lamp will glow when the glove box lid is opened and
will go off as soon as the glove box lid is closed.
COMFORT AND CONVENIENCE
Glove Box
Mechanical fuel tank flap
opening lever
FUEL FUEL FUEL FUEL
FUEL
T TT T
T
ANK FL ANK FLANK FL ANK FL
ANK FL
AP AND GL AP AND GLAP AND GL AP AND GL
AP AND GL
OVE BO OVE BOOVE BO OVE BO
OVE BO
X XX X
X
ProCarManuals.com

63
INSIDE REAR INSIDE REAR INSIDE REAR INSIDE REAR
INSIDE REAR
VIE VIEVIE VIE
VIE
W MIRR W MIRRW MIRR W MIRR
W MIRR
OR AND INTERIOR R OR AND INTERIOR ROR AND INTERIOR R OR AND INTERIOR R
OR AND INTERIOR R
OOF LIGHT OOF LIGHTOOF LIGHT OOF LIGHT
OOF LIGHT
S SS S
S
Inside Rear View Mirror Inside Rear View MirrorInside Rear View Mirror Inside Rear View Mirror
Inside Rear View Mirror
An additional antiglare rear view mirror is fitted inside the cab.
Use antiglare position only when necessary because it reduces rear
view clarity.
Sun Visors Sun VisorsSun Visors Sun Visors
Sun Visors
Two adjustable sun visors are provided inside the cab to prevent
sun glare.
Lower the sun visor to protect the eyes from the bright sun light. The
sun visor also moves side ways towards the door window.
The back of co-driver sun visor is provided with a vanity mirror.
CAUTION CAUTIONCAUTION CAUTION
CAUTION
Always return the sun visor to its original position when not required.
It may block driver’s vision.
Interior Roof Lights Interior Roof LightsInterior Roof Lights Interior Roof Lights
Interior Roof Lights
The roof lamp has three positions ON, OFF and DOOR. When the switch
is in DOOR position and if you enter in the vehicle and close the door
the roof lamp will not go off immediately. It will continue to glow for a
few seconds and allow you to settle and insert the ignition key in the
switch.
However if you switch on the ignition before 15 seconds, the roof lamp
goes off gradualy.
COMFORT AND CONVENIENCE
Front reading lamps Front reading lampsFront reading lamps Front reading lamps
Front reading lamps
Reading lamp Reading lampReading lamp Reading lamp
Reading lamp
Push Buttons Push ButtonsPush Buttons Push Buttons
Push Buttons
O-OFF O-OFFO-OFF O-OFF
O-OFF
,, ,,
,
I-DOOR, I-DOOR, I-DOOR, I-DOOR,
I-DOOR,
II-ON II-ON II-ON II-ON
II-ONRear Roof lamp Rear Roof lampRear Roof lamp Rear Roof lamp
Rear Roof lamp
Sunvisors Rear View Mirror
ProCarManuals.com

64
COMFORT AND CONVENIENCE‘FOLL ‘FOLL‘FOLL ‘FOLL
‘FOLL
O OO O
O
W ME HOME’ W ME HOME’W ME HOME’ W ME HOME’
W ME HOME’
HEADL HEADL HEADL HEADL
HEADL
AMPS AMPSAMPS AMPS
AMPS
“Follow me home” Headlamps :
After closing the door, your car’s headlights remain ON for
approximately 30 seconds to help you reach your destination
in the dark.
If the car’s headlamps remain ON for five minutes or more and
when switched off, ignition key removed and the door locked
or kept open, the headlamp’s Low-beam comes ON
automatically for approximately 30 seconds to help the car
occupant reach his / her destination safely. If, within 15 minutes,
the car is locked using a remote key, the headlamp will come
ON for a further 30 seconds. If the remote key is used again
within 15 minutes, this procedure is repeated. If the occupant
returns to the car within 15 minutes after last switching it off,
the headlamp again comes ON when the door is unlocked.
(P (P(P (P
(P
lease not lease notlease not lease not
lease not
e – e – e – e –
e –
T TT T
T
he r he rhe r he r
he r
ep epep ep
ep
ea eaea ea
ea
tabilit tabilittabilit tabilit
tabilit
y func y funcy func y func
y func
tion of the tion of thetion of the tion of the
tion of the
Headlamps coming ON again within 15 minutes is not Headlamps coming ON again within 15 minutes is notHeadlamps coming ON again within 15 minutes is not Headlamps coming ON again within 15 minutes is not
Headlamps coming ON again within 15 minutes is not
available for the LX version) available for the LX version)available for the LX version) available for the LX version)
available for the LX version)
ProCarManuals.com
