2015 MAZDA MODEL 3 HATCHBACK Navigation Manual (in English)

3
Table of contents
1 Warnings and Safety information ........................................................................\
.. 6
2 Getting started ........................................................................\
................................. 7
2.1 Before using the navigation system ........................................................................\
..........7
2.2 Navigation menu ........................................................................\
.....................................8
2.3 Buttons and other controls on the screen ........................................................................\
9
2.3.1 Using keyboards ........................................................................\
............................................. 9
2.3.2 Press and Hold ........................................................................\
................................................. 9
2.4 Map screen ........................................................................\
............................................10
2.4.1 Navigating on the map ........................................................................\
.................................. 10
2.4.2 Position markers ........................................................................\
........................................... 11
2.4.2.1 Selected map location (Cursor) and selected map object ............................................................ 11
2.4.3 Objects on the map ........................................................................\
....................................... 11
2.4.3.1 Streets and roads ...................................................................\
........................................................ 11
2.4.3.2 Turn preview and Next street ........................................................................\
................................ 12
2.4.3.3 Lane information and Signposts ........................................................................\
........................... 13
2.4.3.4 Junction view ........................................................................\
......................................................... 14
2.4.3.5 Highway/Freeway exit services ........................................................................\
............................ 14
2.4.3.6 Elements of the active route ........................................................................\
.................................. 15
2.4.4 Manipulating the map ........................................................................\
.................................... 16
2.4.5 Checking the details of the current position (Where Am I?) ................................................ 18
3 On-road navigation ........................................................................\
....................... 19
3.1 Selecting the destination of a route ........................................................................\
.......19
3.1.1 Entering an address or a part of the address ........................................................................\
.. 20
3.1.1.1 Entering an address ........................................................................\
.............................................. 20
3.1.1.2 Entering the midpoint of a street as the destination ..................................................................... 23
3.1.1.3 Selecting an intersection as the destination ........................................................................\
......... 25
3.1.1.4 Selecting a city center as the destination ........................................................................\
.............. 27
3.1.2 Selecting the destination from the POI (point of interest) ..................................................... 29
3.1.2.1 Quick search for a POI (point of interest) ........................................................................\
............. 29
3.1.2.2 Searching for Help nearby ........................................................................\
.................................... 32
3.1.2.3 Searching for a POI (point of interest) by category ...................................................................... 33
3.1.2.4 Searching for a POI (point of interest) by name ............................................................................ 36
3.1.3 Searching for a Place using Local Search (Only some countries and\
regions) ..................... 39
3.1.4 Selecting a map location as the destination ........................................................................\
.. 40
3.1.5 Selecting the destination from your Favorites ...................................................................... 42
3.1.6 Selecting a recent destination from the History .................................................................... 43
3.1.7 Entering the coordinate of the destination ........................................................................\
.... 44
3.2 Checking route parameters and accessing route related functions ...............................46
3.3 Modifying the route ........................................................................\
................................47
3.3.1 Selecting a new destination when already having a route: New Route, Waypoint or Final Destination ........................................................................\
... 47
3.3.2 Editing the list of destinations (Edit Route) ........................................................................\
.. 48
3.3.3 Checking route alternatives when planning the route ........................................................... 49
/"7"76#&JOEC







4
3.3.4 Changing the road types used in route planning ................................................................... 50
3.4 Saving a location as a Favorite destination ..................................................................51
3.4.1 Editing the details of a Favorite destination ........................................................................\
. 51
4 Reference Guide ........................................................................\
............................. 52
4.1 Concepts ........................................................................\
................................................52
4.1.1 Smart Zoom ........................................................................\
.................................................. 52
4.1.2 Route calculation and recalculation ........................................................................\
.............. 52
4.1.3 Road safety cameras and other proximity alert points (Only some c\
ountries and regions) .. 53
4.1.4 Speed limit warning (Only some countries and regions) ....................................................... 54
4.1.5 Traffi
c information in route planning (Only some countries and regions) ............................ 54
4.1.5.1 Historical traf fi c ......................................................................\
...................................................... 54
4.1.5.2 Online traf fi c information (Only some countries and regions)...................................................... 55
4.2 Settings menu ......................................................\
...........................................................56
4.2.1 Guidance Settings ........................................................................\
.......................................... 57
4.2.2 Warning S ettings ................................................................\
........................................ ............ 57
4.2.3 Traffi c settings ........................................................................\
............................................... 58
4.2.4 Route settings ........................................................................\
................................................ 59
4.2.5 Map settings ........................................................................\
.................................................. 60
4.2.6 Visual Guidance settings ........................................................................\
............................... 61
4.2.7 Connected Settings (Only some countries and regions) ........................................................ 61
5 Wi-Fi™ (Only some countries and regions) ........................................................ 62
5.1 What is Wi-Fi™*? ........................................................................\
..................................62
5.2 Connecting to Wi-Fi™ ........................................................................\
...........................63
5.2.1 Turning Wi-Fi™ on.............................................................\
........................................... ........ 63
5.2.2 Adding a network ........................................................................\
........................................... 63
5.2.3 Stopping connection to network ........................................................................\
.................... 64
6 Glossary ........................................................................\
......................................... 65
7 End-User Terms........................................................................\
.............................. 67
/"7"76#&JOEC







/"7"76#&JOEC







6
1 Warnings and Safety information
The navigation system guides you to your destination using the GPS recei\
ver. The navigation
system does not transmit your GPS position and you cannot be tracked.
It is important that you look at the display only when it is safe to do \
so. If you are the
driver of the vehicle, we recommend that you operate the navigation syst\
em before you
start your journey. Plan the route before your departure and stop if you need to change
the route.
Drive the vehicle according to the road signs and the road shape. If you\
deviate from the
recommended route, the navigation system changes the instructions accord\
ingly.
For more information, consult the End-User Terms (page 67).
/"7"76#&JOEC







7
2 Getting started
2.1 Before using the navigation system
To use the navigation system, the SD card containing the map information \
needs to be inserted
in the SD card slot.
SD card slot
When inserting the SD card, never move the slider on the side of the SD \
card to the LOCK
position. If the slider is set to LOCK, the SD card cannot be read and t\
he navigation system will
not operate.
This SD card is valid for use in only one vehicle. Never use it in anoth\
er vehicle. If the SD card
is used fi rst in one vehicle and then in another, the navigation system for either one of the
vehicles may become inoperable.
/"7"76#&JOEC







8
2.2 Navigation menu
You can reach all parts of the navigation system from the Navigation menu\
.
Select
and open the navigation menu.

You have the following options: •
/ : Open/close
Opens and closes the UMP (menu bar).
The UMP (menu bar) is displayed on the lower part of the screen.
•
: Adds a destination.
Select your destination by entering an address or selecting a POI (poin\
t of interest), a
location on the map or one of your Favorite destinations. You can also look up your recent
destinations from the Smart History by entering the coordinates. If an I\
nternet connection
is available, Local Search can be of further help to fi nd your destination.
•
: Displays the screen where traf fi c information and the GPS reception conditions can
be set and veri fi ed.
•
: Cancels waypoint/route
•
: Finds Places nearby
You can search for points of interest (POI) near the vehicle position.
•
: Displays the route parameters and the route in its full length on the \
map. You can
also perform route-related actions such as editing or canceling your rou\
te, picking route
alternatives, avoiding parts of the route, simulating navigation or addi\
ng the destination to
your Favorites.
•
/ / : Changes View mode
The map view mode can be changed (2D north up/2D heading up/3D).
•
: Switches to the Settings screen where you change navigation settings.
Note! Some functions are not available depending on some countries and
regions.
/"7"76#&JOEC







9
2.3 Buttons and other controls on the screen
2.3.1 Using keyboards
You only need to enter letters or numbers when you cannot avoid it. You can type with your
fi ngertips on the full-screen keyboards and you can switch between various\
keyboard layouts,
for example English, Greek or numerical.
Task Instruction
Correcting your entry on the
keyboard Select to remove the unneeded character(s). Select and
hold the button to delete several characters or the entire input
string.
Entering a space, for
example between a fi rst
name and a family name or
in multi-word street names Select the
button at the bottom center
of the screen.
Entering upper and lower
case letters When entering a text, the fi
rst character appears in upper case
while the rest of the text is in lower case. Select
to enter an
upper case letter or select twice to turn on Caps Lock. Select
again and lower case letters return.
Finalizing the keyboard entry Select
.
• Accepting the suggested search result
• Saving your input
Select
.
• Opening the list of search results
Canceling the keyboard
entry (returning to the
previous screen) Select
.
2.3.2 Press and Hold
You usually need to select the screen only once, however, some useful features can be
accessed with combined touch screen selecting. Those are as follows:
Action Button(s)
Details
Continue
pressing the
button., Touching the button on the map screen once changes
the scale in one step. Continuously touching the button
changes the scale sequentially.
, Touching the button on the map screen once changes
the point of view in one step. Continuously touching the
button changes the point of view sequentially.
, Touching the button on the map screen once rotates the
map. Continuously touching the button rotates the map
sequentially.
Touching the button on the keyboard screen once erases
one character. Continuously touching the button erases
several characters rapidly.
/"7"76#&JOEC







10
2.4 Map screen
2.4.1 Navigating on the map
The data fi elds are different when you are navigating an active route and when you have no
specifi ed destination (the burgundy line is not displayed).
Field Description
Shows the speed limit of the current road if the map contains it.

Shows the distance you need to travel on the route before
reaching your
fi nal destination.
Shows the estimated arrival time at the fi nal destination of the
route.
If the navigation system is capable of receiving live traf fi c
information, the calculation takes into account traf fi c delays
affecting your route.
This estimation can be inaccurate at times.
Note! Some functions are not available depending on some countries and
regions.
/"7"76#&JOEC
