2015 FIAT PANDA Owners Manual

RIGHT HAND DRIVE VERSIONS
CONTROL PANEL
AND INSTRUMENTS
The instrument background colour and type
may vary according to the version.
.
A. Speedometer (speed indicator) – B. Multifunction display – C. Rev counter
2-F0W0297
TOTkmi
C
1833

REPLACING FUSES
RIGHT HAND DRIVE VERSIONS
Dashboard fuse box
To access the fuses, remove the plastic
cover fig. 3 . The fuses are located in
the fuse box shown in fig. 4 .
F0W0294
F0W0295
FUSE LOCATION
3
4
PARKING
Switch off the engine and engage the
handbrake. Engage a gear (1stgear if parked
uphill or reverse if facing downhill) and leave
the wheels turned. If the car is parked on
a steep slope block the wheels with a wedge
or stone. Always remove the ignition key when
leaving the car.
HANDBRAKE
To engage the handbrake pull lever A f i g . 5
upwards until the car is secured. To
release the handbrake, raise lever
A slightly, hold down button B and
lower the lever.
If the car is parked on a steep slope, it
is also advisable to block the wheels
with a wedge or stone.
Never leave children alone in the
unattended car. Always remove the
ignition key when leaving the car and
take it with you.
F0W02965
1834

IMPORTANT INFORMATION AND RECOMMENDATIONS
WARNING
INTERIOR FITTINGS
❒Never travel with the glove compartment open: it could injure the passenger in the event of a crash.
❒The cigar lighter gets very hot. Handle it carefully and make sure that children do not touch it: risk of fire and/or burns. Always check that
the cigar lighter plug has been released.
ROOF RACK/SKI RACK
❒After travelling for a short distance, check that the fixing screws for the attachments are correctly tightened.
❒Never exceed the maximum permitted loads (see chapter "Technical specifications").
❒Evenly distribute the load and take into account, when driving, the increased responsiveness of the vehicle to side wind.
WIRING FOR RADIO SYSTEM
❒If you wish to have a sound system installed after purchasing the vehicle, first contact a Fiat Dealership whose qualified personnel will give
you advise about a sound system that does not damage the battery charge. Excessive non­running consumption damages the battery and
may cause your battery warranty to be terminated.
PROTECTING THE ENVIRONMENT
❒During normal service, the catalytic converter and the diesel particulate filter (DPF) reach high temperatures. Do not therefore park the
vehicle over inflammable materials (grass, dry leaves, pine needles, etc.): fire hazard.
INTERIORS
❒Never use flammable products, such as petrol ether or rectified petrol to clean the inside of the vehicle. The electrostatic charges which are
generated by rubbing during the cleaning operation may cause a fire.
❒Do not keep aerosol cans in the vehicle: they might explode. Aerosol cans must not be exposed to a temperature exceeding 50°C. When
the vehicle is exposed to sunlight, the internal temperature can greatly exceed this value.
POWER SUPPLY
❒Modifications or repairs to the supply system that are not carried out correctly or do not take the system technical specifications into
account can cause malfunctions leading to the risk of fire.
LOADING ADVICE(Panda VAN versions)
❒Abrupt braking or occasional impacts may cause sudden movements of the load with consequent situations of hazard for the driver and
passengers: before setting off, secure the load tightly using the partition and, where provided, the appropriate hooks. For securing use
cables, ropes or belts strong enough to hold the items to be secured.
185

WARNING
ROOF RACK/SKI RACK
❒Fully comply with the regulations in force concerning maximum clearance.
WIRING FOR RADIO SYSTEM
❒For connection to the radio system set-up, contact a Fiat Dealership to prevent any problem that could impair vehicle safety.
BODYWORK
❒In order to preserve the aesthetic appearance of the paint abrasive products and/or polishes should not be used for cleaning the vehicle.
❒Avoid washing with rollers and/or brushes in washing stations. Wash the vehicle only by hand using neutral pH detergents; dry it with a wet
chamois leather. Abrasive products and/or polishes should not be used for cleaning the vehicle. Bird droppings must be washed off
immediately and thoroughly as the acid they contain is particularly aggressive. Avoid (if at all possible) parking the vehicle under trees; remove
vegetable resins immediately as, when dried, it may only be possible to remove them with abrasive products and/or polishes, which is highly
inadvisable as they could alter the typical opaqueness of the paint. Do not use pure screen washer fluid for cleaning the windscreen and
rear window; dilute it min. 50% with water. Only use pure screen washer fluid when strictly necessary due to outside temperature conditions.
INTERIORS
❒Never use alcohol, petrols and derivatives to clean the dashboard and instrument panel lens.
WARNING
BODYWORK
❒Detergents pollute the environment. Only wash your vehicle in areas equipped to collect and treat wastewater from this type of activity.
186
