2015 FIAT 500L Owners Manual

Bulb Number
Rear Tail/Stop LampsP21/5W
Rear Tail LampLED (See Authorized dealer)
Rear Turn Signal LampsP21W
Rear Backup LampsW16W
Rear Side Marker LampsLED (See Authorized dealer)
Center High Mounted Stop LampLED (See Authorized dealer)
Front Fog LampsH11
Rear Fog Lamps - If EquippedW16W
License Plate LampsW5W
NOTE:Numbers refer to commercial bulb types that can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized dealer or refer to the applicable Service Manual.
7
MAINTAINING YOUR VEHICLE 391

BULB REPLACEMENT
NOTE:Lens fogging can occur under certain atmo-
spheric conditions. This will usually clear as atmospheric
conditions change to allow the condensation to change
back into a vapor. Turning the lamps on will usually
accelerate the clearing process.
Headlamps Low Beam and High Beam
1. Remove the plastic sealing cap from the back of the
headlamp housing by turning it counter-clockwise .
2. Rotate the bulb counter-clockwise.
Headlamp Sealing Cap Removal
392 MAINTAINING YOUR VEHICLE

3. Remove the bulb when all the tabs are aligned with
the openings in the metal holder.
4. Disconnect the electrical connector from the bulb.
5. Install the new bulb and rotate clockwise to lock in
place.
Bulb Removal ProcedureElectrical Connector Removal
7
MAINTAINING YOUR VEHICLE 393

6. Reinstall the plastic cap.
New Bulb InstallationHeadlamp Sealing Cap Installation
394 MAINTAINING YOUR VEHICLE

Front Turn Signal, Parking And Daytime Running
Lamps
1. Turn front wheels inboard to access upper cover in
wheel liner.
2. Open the upper cover on the front of the wheel liner.
3. Remove the cap from the back of the lower headlamp
housing.
4. Rotate the bulb counter clockwise and remove.
5. Install the bulb into socket, and rotate bulb/socket
clockwise into lamp locking it in place.
6. Reinstall the plastic cap and close the cover on the
wheel liner.
Front Fog Lamps
To replace the front fog lights, see your authorized dealer.
Front, Rear Roof Lamps
1. Remove two screw and remove the lamp assembly.
2. Remove the socket bulb by turning counterclockwise.
3. Remove bulb and replace as needed.
4. Reinstall the bulb socket and rotate clockwise to lock
in place.
5. Reinstall lamp.7
MAINTAINING YOUR VEHICLE 395

Rear Tail, Stop, Backup And Turn Signal Lamps
1. Open the liftgate.
2. Remove the tail lamp access panel.
3. Remove the two screws that secure the tail lamp to the
body of the vehicle.
4. Remove the tail lamp assembly.
5. Remove the two screws that secure the backplate to
the tail lamp housing.
6. Separate the backplate from the tail lamp housing.
7. Remove the tail, stop, or turn signal bulbs by pushing
them slightly and turning counter-clockwise.
8. Remove the backup lamp bulb by pulling straight out.
9. Replace lamps as required and reinstall lamp.
Center High-Mounted Stop Lamp (CHMSL)
This light is an LED assembly. See your authorized dealer
for replacement.
396 MAINTAINING YOUR VEHICLE

FLUID CAPACITIES
U.S.Metric
Fuel (Approximate)13.1 Gallons50 Liters
Engine Oil with Filter
1.4L Turbo Engine4 Quarts3.8 Liters
Cooling System
1.4 Liter Turbo Engine (MOPAR®
Antifreeze/Engine Coolant 10
Year/150,000 Mile Formula).
6.1 Quarts5.8 Liters
7
MAINTAINING YOUR VEHICLE 397

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
ComponentFluid, Lubricant, or Genuine Part
Engine Coolant – 1.4L Turbo EngineWe recommend you use MOPAR® Antifreeze/Coolant
10 Year/150,000 Mile Formula OAT (Organic Additive
Technology) or equivalent meeting the requirements of
Chrysler Material Standard MS-90032.
Engine Oil – 1.4L Turbo EngineWe recommend you use SAE 5W-40 API Certified
Synthetic Engine Oil, meeting the requirements of
Chrysler Material Standard MS-12991. Refer to your
engine oil filler cap for correct SAE grade.
Engine Oil Filter – 1.4L Turbo EngineWe recommend you use MOPAR® Engine Oil Filter.
Spark Plugs – 1.4L Turbo EngineWe recommend you use MOPAR® Spark Plugs.
Fuel Selection – 1.4L Turbo Engine87 Octane Acceptable — 91 Octane Recommended
398 MAINTAINING YOUR VEHICLE
