2015 Citroen C4 warning

195
C4-2_en_Chap09_conduite_ed01-2015
C4-2_en_Chap09_conduite_ed01-2015
Lane departure warning system
Activation
Deactivation
DetectionOperating fault
System which detects the involuntary crossing o
f   longitudinal   traffic   lane   markings   on   the
g

round   (solid   or   broken   line).
Sensors,
  fitted   below   the   front   bumper,   trigger
a

  warning   if   the   vehicle   drifts   over   a   lane
m

arking   (speed   higher   than   50   mph   (80   km/h)).
This
  system   is   particularly   useful   on   motor ways
a

nd   main   roads. In
  the   event   of   a   malfunction,   the
s

ervice   warning   lamp   comes   on,
a

ccompanied   by   an   audible   signal
a

nd   a   message   in   the   screen.
Contact   a   CITROËN   dealer   or   a   qualified
w

orkshop.
The   lane   departure   warning   system
c

annot   in   any   circumstances   replace
t

he   need   for   vigilance   on   the   part   of   the
d

river.
It
  is   necessary   to   observe   driving
r

egulations   and   take   a   break   every
two
  hours. The
  detection   may   be   impeded:
- i f   the   sensors   are   dirty   (mud,   snow...),
-
 i

f   the   markings   on   the   ground   are
 w

orn,
-
i

f there is little contrast between the
markings
  on   the   ground   and   the   road
 s

ur face.
You
  are   warned   by   the   vibration   of   the   driver's
s

eat   cushion:
-

o
n   the   right-hand   side,   if   the   marking   on
t

he   ground   has   been   crossed   on   the   right,
-

o
n   the   left-hand   side,   if   the   marking   on   the
g

round   has   been   crossed   on   the   left.
No
  warning   is   transmitted   while   the   direction
i

ndicator   is   active   and   for   approximately
2

0 seconds after the direction indicator is
switched
  off.
A
  warning   may   be   transmitted   if   a   direction
m

arking   (e.g.   arrow)   or   non-standard   marking
(

e.g.   graffiti)   is   crossed.
F

Press this button, the indicator lamp comes on.
F Press
  this   button   again,   the   indicator   lamp  g
oes   off.
The
  status   of   the   system   remains   in   the
m

emory   when   the   ignition   is   switched   off.
9
Driving

196
C4-2_en_Chap09_conduite_ed01-2015
C4-2_en_Chap09_conduite_ed01-2015
blind spot sensors
This driving assistance system warns the driver of the presence of another vehicle in the blind
spot
  angle   of   their   vehicle   (areas   masked   from
t

he   driver's   field   of   vision),   as   soon   as   this
p

resents   a   potential   danger.
Operation
F On  switching   on   the   ignition,   or   engine  r
unning,   press   this   button   to   activate   the
f

unction;   the   warning   lamp   comes   on.
Sensors
  fitted   in   the   front   and   rear   bumpers
m

onitor   the   blind   spots.
A

warning

lamp

appears

in

the

door

mirror

on
 t
he

side

in

question:
-
 i
mmediately,

when

being

overtaken,
-

a

fter a delay of about one second, when
overtaking

a

vehicle

slowly.
This

system

is

designed

to

improve

s

afety

when

driving

and

is

in

no

c

ircumstances

a

substitute

for

the

use

o

f

the

interior

rear

view

mirror

and

door

m

irrors.

It

is

the

driver's

responsibility

to

c

onstantly

check

the

traffic,

to

assess

t

he distances and relative speeds
of other vehicles and to predict their
movements

before

deciding

whether

to

c

hange
 lan

e.
The

blind

spot

sensor

system

can

never

r

eplace

the

need

for

vigilance

on

the

p

art

of

the

driver.
driving

197
C4-2_en_Chap09_conduite_ed01-2015
C4-2_en_Chap09_conduite_ed01-2015
No alert will be given in the following situations:
-  i n   the   presence   of   immobile   objects
(

parked   vehicles,   barriers,   street   lamps,
r

oad
 s
igns...),
-

w
ith   vehicles   moving   in   the   opposite
d

irection,
-

d
riving   on   a   sinuous   road   or   a   sharp
c

o r n e r,
The

alert

is

given

by

a

warning

lamp

which

c

omes

on

in

the

door

mirror

on

the

side

in

q

uestion

as

soon

as

a

vehicle

-

car,

lorry,

c

ycle -

is

detected

and

the

following

conditions

a

re

fulfilled:
-

a

ll

the

vehicles

must

be

moving

in

the

sa

me
 d

irection,
-

t

he

speed

of

your

vehicle

is

between

7

and

7

5

mph

(12

and

140

km/h),
-

w

hen

you

overtake

a

vehicle

with

a

speed

d

ifference

of

less

than

6

mph

(10

km/h),
-

w

hen

a

vehicle

overtakes

you

with

a

speed

d

ifference

of

less

than

15

mph

(25

km/h),
-

t

he

traffic

must

be

flowing

normally,
-

i

n

the

case

of

an

overtaking

manoeuvre,
 i
f

this

is

prolonged

and

the

vehicle

being
 ov
ertaken

remains

in

the

blind

spot,
-

y

ou

are

driving

on

a

straight

or

slightly

c

urved road,
-

y

our

vehicle

is

not

pulling

a

trailer,

a

c

aravan... -
 w hen   overtaking   (or   being   overtaken   by)   a  v
ery   long   vehicle   (lorry,   coach...)   which   is
a

t   the   same   time   detected   at   the   rear   in   the
b

lind   spot   angle   and   present   in   the   driver's
f

orward field of vision,
-

i
n   very   heavy   traffic:   vehicles   detected   in
f

ront and behind are confused with a lorry
or
  a   stationary   object,
-

w
hen   overtaking   quickly.
9
driving

198
C4-2_en_Chap09_conduite_ed01-2015
C4-2_en_Chap09_conduite_ed01-2015
F To  deactivate   the   system,   press   this   button  a
gain;   the   warning   lamp   goes   off.
The
  state   of   the   system   remains   in   memory   on
s

witching   off   the   ignition.
Operating fault
The system is automatically deactivated when   towing   with   a   towbar   approved   by
CIT

ROËN. The
  system   may   suffer   temporary
i

nterference in certain weather
conditions(rain,
 h
ail...).
In   particular,   driving   on   a   wet   sur face
o

r   moving   from   a   dry   area   to   a   wet   area
c

an   cause   false   alerts   (for   example,   the
p

resence   of   a   fog   of   water   droplets   in
t

he   blind   spot   angle   is   interpreted   as   a
v

ehicle).
In bad or wintry weather, ensure that
the   sensors   are   not   covered   by   mud,   ice
o

r   snow.
Take   care   not   to   cover   the   warning   zone
i

n   the   door   mirrors   or   the   detection
z

ones   on   the   front   and   rear   bumpers
w

ith   adhesive   labels   or   other   objects;
t

hey   may   hamper   the   correct   operation  o
f   the   system.
In   the   event   of   a   fault,   the   warning   lamp   in   the
b

utton   flashes   then   goes   off.
Have   it   checked   by   a   CITROËN   dealer   or   a
q

ualified
 w
orkshop.
Driving

206
C4-2_en_Chap09_conduite_ed01-2015
C4-2_en_Chap09_conduite_ed01-2015
In addition to the rear parking sensors, the front parking   sensors   are   triggered   when   an   obstacle i

s detected in front and the speed of the vehicle is
still
  below   6   mph   (10   km/h).
The
  front   parking   sensors   are   interrupted   if   the
 v

ehicle   stops   for   more   than   three   seconds   in
 f

or ward   gear,   if   no   further   obstacles   are   detected
 o

r   when   the   speed   of   the   vehicle   exceeds   6   mph
 (

10   km/h).
Front parking sensors
Deactivation/Activation of the
front and rear parking sensors
The function is deactivated by pressing this button.   The   indicator   lamp   in   the   button
comes
  on.
Pressing
  this   button   again   reactivates   the
f

unction.   The   indicator   lamp   in   the   button
goes
  off.
Operating fault
In the event of a malfunction of the   system,   when   reverse   gear
i

s   engaged   this   warning   lamp   is
d

isplayed   in   the   instrument   panel
a

nd/or   a   message   appears   in   the
s

creen,   accompanied   by   an   audible
s

ignal   (short   beep).
Contact a CITR
oËn

dealer or a
qualified
 w

orkshop.
The

sound

emitted

by

the

speaker

(front

or

r

ear)

indicates

whether

the

obstacle

is

in

front

o

r

behind. The function will be deactivated
automatically

if

a

trailer

is

being

towed

o

r

a

bicycle

carrier

is

fitted

(vehicle

f

itted with a towbar or bicycle carrier
recommended

by

CITROËN). In bad weather or in winter, ensure
that the sensors are not covered with
mud,
  ice   or   snow.   When   reverse   gear   is
e

ngaged,   an   audible   signal   (long   beep)
i

ndicates   that   the   sensors   may   be   dirty.
Certain
  sound   sources   (motorcycle,
l

orry,
  pneumatic   drill,   etc.)   may   trigger
t

he

audible   signals   of   the   parking
s

ensor   system.
driving

208
C4-2_en_Chap10_verification_ed01-2015
C4-2_en_Chap10_verification_ed01-2015
Fuel tank
Capacity of the tank: approximately 60 litres.When the low fuel level in the
tank
  is   reached,   this   warning   lamp
c

omes   on   in   the   instrument   panel,
a

ccompanied   by   an   audible   warning
a

nd   the   display   of   an   alert   message.
W

hen   it   first   comes   on,   around
6
litres   of   fuel   remain   in   the   tank.
Low fuel level
Additions of fuel must be of at least 5 litres to be   registered   by   the   fuel   gauge.
Opening
  the   filler   cap   may   result   in   an   inrush   of
a

ir.   This   vacuum   is   entirely   normal   and   results
f

rom   the   sealing   of   the   fuel   system.
F

P
ress control A   until   the   automatic   opening
o

f   the   fuel   flap   is   heard.
 T

his   control   remains   active   for   a   few
m

inutes   after   switching   off   the   ignition.   If
n

ecessary,   switch   the   ignition   on   again   to
r

eactivate   it.
F

T
ake   care   to   select   the   pump   that   delivers
t

he   correct   fuel   for   your   vehicle.If you are filling your tank to the top, do not
persist after the third cut- off; this could
cause your vehicle to malfunction. F

I
ntroduce the nozzle so as to push in the
metal
  non-return   flap   B.
F

M
ake   sure   that   the   nozzle   is   pushed   in   as
f

ar   as   possible   before   starting   to   refuel
(

risk   of   blowback).
F

M
aintain   this   position   while   refuelling.
F

P
ush   the   fuel   flap   to   close   it.
With Stop & Start, never refuel with the
system

in

STOP

mode;

you

must

switch

o

ff

the

ignition

with

the

key,

or

the

S

TART/STOP

button

if

your

vehicle

has

K

eyless

Entry

and

Starting.
Until

sufficient

fuel

has

been

added,

every

t

ime

the

ignition

is

switched

on,

this

warning

l

amp

appears,

accompanied

by

an

audible

s

ignal

and

an

alert

message.

When

driving,

t

his

audible

signal

and

the

display

of

this

a

lert

message

are

repeated

with

increasing

f

requency,

as

the

level

drops

towards

0 .
You

must

refuel

as

soon

as

possible

to

avoid

r

unning

out.
If

you

run

out

of

fuel

(Diesel),

refer

to

the

c

orresponding
 s

ection.
Refuelling
Checks

218
C4-2_en_Chap10_verification_ed01-2015
C4-2_en_Chap10_verification_ed01-2015
Used products
The additive reservoir low level is indicated by:
To p p i n g u p
The reservoir must be topped up without delay by   a   CITROËN   dealer   or   a   qualified   workshop.
-

f
ixed   illumination   of   the   particle
f

ilter   warning   lamp,   accompanied
b

y   an   audible   signal   and   a
m

essage   that   the   particle   filter
a

dditive   level   is   too   low.
Additive level (Diesel with
particle filter)
Avoid prolonged contact of used oil or f
luids   with   the   skin.
Most
  of   these   fluids   are   harmful   to
h

ealth   or   indeed   very   corrosive.
do n

ot discard used oil or fluids into
sewers
  or   onto   the   ground.
Take
  used   oil   to   a   CITROËN   dealer   or
a

  qualified   workshop   (France)   or   to   an
a

uthorised   waste   disposal   site.
Checks

219
C4-2_en_Chap10_verification_ed01-2015
C4-2_en_Chap10_verification_ed01-2015
Checks
Particle filter (Diesel)
- fixed  illumination   of   the   particle  f
ilter   warning   lamp,   accompanied
b

y   an   audible   signal   and   a
m

essage   that   there   is   a   risk   of
b

lockage   of   the   particle   filter.
The presence of this label, in particular with
the

Stop

&

Start

system,

indicates

the

use

of

a s

pecific 12 V lead-acid battery with special
technology

and

specification.

The

involvement

o

f

a

CITROËN

dealer

or

a

qualified

workshop

i

s

essential

when

replacing

or

disconnecting

t

he

battery. As

soon

as   the   traffic   conditions   permit,
r

egenerate   the   filter   by   driving   at   a   speed   of   at
l

east

40

mph   (60   km/h)   until   the   warning   lamp
g

oes

off.
If

the

warning   lamp   stays   on,   refer   to   the
"

Additive

level"   section.
Unless

other wise

indicated,

check

these

components

in

accordance

with

the

manufacturer's

service

schedule

and   according   to   your   engine.
Other wise,

have

them

checked

by

a

CITROËN

dealer

or

a

qualified

workshop.
Air filter and passenger compartment filter
Refer to the manufacturer's s
ervice schedule for details of the
replacement
  intervals   for   these
c

omponents.
Oil filter
Replace the oil filter each time the e ngine   oil   is   changed.
Refer
  to   the   manufacturer's
s

ervice schedule for details of
the
  replacement   interval   for   this
c

omponent.
12 V battery
The battery does not require any maintenance.
H owever,   check   that   the   terminals   are   clean a

nd   correctly   tightened,   particularly   in   summer
 a

nd   winter.
When carrying out work on the battery, refer to the "12 V battery" section for details of the
precautions
  to   be   taken   before   disconnecting
t

he   battery   and   following   its   reconnection.Depending
  on   the   environment   (e.g.   dusty  a
tmosphere)   and   the   use   of   the   vehicle
(e.g.
  city   driving),   replace them twice as often
if necessary .
A
  clogged   passenger   compartment   filter   may
h

ave   an   adverse   effect   on   the   per formance
o

f   the   air   conditioning   system   and   generate
u

ndesirable
 o
dours.The start of saturation of the particle filter is
indicated
  by:
on a n

ew vehicle, the first operations of
regeneration
  of   the   particle   filter   may   be
a

ccompanied   by   the   smell   of   "burning",
w

hich   is   per fectly   normal.
Following
  prolonged   operation   of   the
v

ehicle at very low speed or at idle,
you
  may,   in   exceptional   circumstances,
n

otice   the   emission   of   water   vapour   at
t

he   exhaust   on   acceleration.   This   does
n

ot affect the behaviour of the vehicle
or
  the   environment.
10
Checks
