2014 TOYOTA GT86 Owners Manual

17
B
Inside door lock buttons
P. 56
Outside rear view mirror switches 
P. 80
Window lock switch
P. 83
Power window switches P. 83
Door lock switch P. 56
: If equipped

18
C
Shift lock override button  P. 412
Shift lever P. 181, 188
Parking brake lever P. 192
VSC/TRC off switch P. 226
Seat heater switches  P. 273
Driving pattern selector switch  P. 183
“VSC SPORT” switch P. 226
Power outlet P. 271
: If equipped
Pictorial index
Interior
(Right-hand drive vehicles)

19
Tilt and telescopic steering
lock release lever
P. 78
Gauges and meters
Multi-information display P. 194
P. 203
Clock P. 268
Windshield wiper and
washer switch
P. 217
Emergency flasher
switch
P. 362
Floor mat P. 275
Hood lock release lever P. 297
Fuel filler door opener P. 87
Engine (ignition) switch (vehicles with a
smart entry & start system)
P. 169
SRS driver knee airbag P. 104
Headlight switch
Turn signal lever
Fog light switch P. 208
P. 191
P. 215
AUX/USB port 
P. 258
: If equipped
Pictorial index
Instrument panel
(Right-hand drive vehicles)

20
A
Rear window and outside rear view mirror defoggers
switch
/rear window defogger switch  P. 256
Vehicles with an automatic air conditioning system Vehicles with a manual air conditioning system
Air conditioning
system
P. 240
Air conditioning
system
P. 248
Rear window and outside rear view
mirror defoggers switch
P. 256
Pictorial index
Instrument panel
(Right-hand drive vehicles)

21
C
B
Engine (ignition) switch (vehicles
without a smart entry & start system)
P. 178
Cruise control switch  P. 220Horn
SRS driver airbag P. 193
P. 104
Instrument panel light control dial P. 196
Manual headlight leveling dial 
P. 210
Trunk opener P. 58
: If equipped
Paddle shift switches  P. 184, 186
Tire pressure warning system reset switch
P. 316

22
For your information
Main Owner’s Manual
Please note that this manual covers all models and all equipment, including
options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of color and equipment.
Accessories, spare parts and modification of your Toyota
A wide variety of non genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. Using these spare parts and
accessories which are not genuine Toyota produces may adversely affect
the safety of your vehicle, even though these parts may be approved by cer-
tain authorities in your country. Toyota Motor Corporation therefore cannot
accept any liability or guarantee spare parts and accessories which are not
genuine Toyota Products, nor for replacement or installation involving such
parts.
This vehicle should not be modified with non genuine Toyota products. Modi-
fication with non genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problem resulting from the modification may
not be covered under warranty.

23
Installation of an RF-transmitter system
The installation of an RF-transmitter system in your vehicle could affect elec-
tronic systems such as:
Multiport fuel injection system/sequential multiport fuel injection system
Cruise control system
Anti-lock brake system
SRS airbag system
Seat belt pretensioner system
Be sure to check with any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional for precautionary measures or spe-
cial instructions regarding installation of an RF-transmitter system.
Further information regarding frequency bands, power levels, antenna posi-
tions and installation provisions for the installation of RF-transmitters, is
available on request at any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional.

24
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main pur-
pose of an EDR is to record, in certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle, data that will assist
in understanding how a vehicle’s systems performed. The EDR is designed
to record data related to vehicle dynamics and safety systems for a short
period of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• How far (if at all) the driver was depressing the accelerator and/or brake
pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ-
ation occurs; no data are recorded by the EDR under normal driving condi-
tions and no personal data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law enforcement, could combine
the EDR data with the type of personally identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access
to the vehicle or the EDR is needed. In addition to the vehicle manufacturer,
other parties, such as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or the EDR.
Disclosure of the EDR data
Toyota will not disclose the data recorded in an EDR to a third party except
when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehicle)
is obtained
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Toyota in a law suit
However, if necessary, Toyota may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing
information about the specific vehicle or vehicle owner
