KEYS AND DOORS19
Safety
catch lever
Cab stay
lock lever
2. Hold the cab down, pull the safety
catch lever out and raise the cab to
tilt forward. Make sure that the cab
stay lock lever locks securely.
The cab will automatically lock when it
tilts fully forward.
CAUTION
When the cab tilts fully forward, make
sure the cab stay lock lever securely
locks and that the cab does not low-
er.
Cab stay lock
lever stopper
3. Plug the opening with the cab stay
lock lever stopper for additional se-
curity.
CAUTION
When tilting the cab, make sure that
the cab stay lock lever stopper has
immobilized the cab stay lock lever.
If it is not immobilized, the cab could
lower and cause death or serious in-
juries.
Dyna100/150_EE

20KEYS AND DOORS
1. Pull the cab stay lock lever stopper
up and return it to the upper hole.
While holding the cab with the grip,
pull the cab stay lock lever up to
unlock, then lower the cab slowly.
Before lowering the cab, check to see that
you have not forgotten any tools, rags,
etc.
CAUTION
When lowering the cab, make sure
that no one is around the cab.
2. Press down the cab lock handle
firmly.
Make sure the cab is securely locked.
CAUTION
Do not drive the vehicle without lock-
ing the cab securely. Otherwise, the
cab may be tilted unexpectedly, possi-
bly causing an accident.
Dyna100/150_EE
—Lowering the cab

KEYS AND DOORS21
1. To unlock the fuel tank cap, insert
the key and turn it counterclockwise.
When refueling, turn off the engine.
CAUTION
DDo not smoke, cause sparks or al-
low open flames when refueling.
The fumes are flammable.
DWhen opening the cap, do not re-
move the cap quickly. In hot weath-
er, fuel under pressure could cause
injury by spraying out of the filler
neck if the cap is suddenly re-
moved.
2. To remove the fuel tank cap, turn
the cap slowly counterclockwise,
then pause slightly before removing
it.
It is not unusual to hear a slight swoosh
when the cap is opened.When installing,
make sure the tabs in the cap are proper-
ly aligned with the cutouts in the tank
opening. Then lock the cap by turning the
key clockwise.
CAUTION
DMake sure the cap is tightened se-
curely to prevent fuel spillage in
the event of an accident.
DDue to the regulation of fuel tank
pressure that these caps provide,
Toyota recommends to use a genu-
ine Toyota fuel tank cap. Another
fuel tank cap of matching quality
can also be used.
Dyna100/150_EE
Fuel tank cap

22KEYS AND DOORS
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS23
Section 1−3
OPERATION OF INSTRUMENTS AND
CONTROLS
Seats, Seat belts, Steering wheel and Mirrors
DSeats 24..............................................
DDriver’s seat 24.......................................
DFolding up rear seat 26.................................
DHead restraints 27.....................................
DSeat belts 28..........................................
DSRS driver airbag 38...................................
DChild restraint 44......................................
DTilt and telescopic steering wheel 58....................
DOutside rear view mirrors 59............................
Dyna100/150_EE

24SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION
DDo not drive the vehicle unless the
occupants are properly seated. Do
not allow any occupants to sit on
top of a folded−down seatback, or
in the luggage compartment or car-
go area. If the occupants are im-
properly seated or restrained by
seat belts, death or serious injury
could result in the event of emer-
gency braking, sudden swerving or
an accident.
DDuring driving, do not allow any
passengers to stand up or move
around between seats. Otherwise,
death or serious injuries can occur
in the event of emergency braking,
sudden swerving or an accident.
Adjust the driver ’s seat so that the foot
pedals, steering wheel and instrument
panel controls are within easy reach of
the driver.
CAUTION
DDo not adjust the seat while the
vehicle is moving as the seat may
unexpectedly move and cause the
driver to lose control of the vehicle.
DWhen adjusting the seat, be careful
that the seat does not hit a lug-
gage.
DAfter adjusting the seat position, re-
lease the lever and try sliding the
seat forward and backward to make
sure it is locked in position.
DMake sure the seatback is securely
locked by pushing forward and rear-
ward on the top of the seatback.
Failure to do so will prevent the
seat belt from operating properly.
DDo not put objects under the driv-
er ’s seat. Otherwise, the objects
may interfere with the seat−lock
mechanism or unexpectedly push
up the seat position adjusting lever
and the seat may suddenly move,
causing the driver to lose control of
the vehicle.
DWhile adjusting the seat, do not put
your hands under the seat or near
the moving parts. Otherwise, you
may catch and injure your hands or
fingers.
Dyna100/150_EE
SeatsDriver’s seat—
—Seat adjustment precautions

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS25
1. SEAT POSITION ADJUSTING LEVER
Pull the lever up. Then slide the seat
to the desired position with slight body
pressure and release the lever.
2. SEATBACK ANGLE ADJUSTING
LEVER
Lean forward and pull the lever up.
Then lean back to the desired angle
and release the lever.
CAUTION
Avoid reclining the seatback any
more than needed. The seat belt pro-
vides maximum protection in a frontal
or rear collision when the driver is
sitting up straight and well back in
the seat. If you are reclined, the lap
belt may slide past your hips and
apply restraint forces directly to the
abdomen or your neck may contact
the shoulder belt. In the event of a
frontal collision, the more theseat is
reclined, the greater the risk of death
or serious injury.
3. SEAT LUMBAR SUPPORT
ADJUSTING LEVER
Pull the lever forward.
Repeat this until you have a comfortable
support.
Dyna100/150_EE
—Adjusting driver’s seat

26SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
1. Swing up the bottom cushion.2. Hook the strap.
Dyna100/150_EE
Folding up rear seat
