2014 TOYOTA 4RUNNER Owners Manual

892. Instrument cluster
2
Instrument cluster
4RUNNER (U)_(OM35A83U)
“MODE/ ” button
“SET/ ” button
Trip information (P. 9 0 )
Displays driving range and average fuel consumption
Outside temperature display ( P. 312)
Compass ( P. 335)
Clock ( P. 3 1 1 )
H (Hour) button ( P. 311)
M (Minute) button ( P. 3 1 1 )
Multi-terrain Select display ( P. 253)
Automatically displayed when using Multi-terrain Select
Accessor y meter
: If equipped
The accessory meter presents the driver with a variety of driv-
ing-related data including the cu rrent outside air temperature.
1
2
3
4
5
6
7
8
9

902. Instrument cluster
4RUNNER (U)_(OM35A83U)
Items displayed can be switched by pressing the “MODE/ ” button.
■Cruising range
Displays the estimated maximum dist ance that can be driven with the
quantity of fuel remaining
• This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
• When only a small amount of fuel is added to the tank, the display may not be updated.
■
Average fuel consumption
Displays the average fuel consumpt ion since the function was reset
• Pressing and holding the “SET/ ” button will reset the average fuel con-
sumption.
• Use the displayed average fuel consumption as a reference.
The daytime brightness of the accessory meter can be adjusted.
Turn the headlight switch off.
Press and hold the “MODE/ ” button.
Press the “MODE/ ” or “SET/ ” button to the desired
brightness level.
Press and hold the “SET/ ”
button.
Trip information
Accessory meter light control
1
2
3
4

912. Instrument cluster
2
Instrument cluster
4RUNNER (U)_(OM35A83U)
■Adjusting the brightness of the accessory meter
●If left idle for approximately 6 seconds or more while adjusting, the display
will revert to the trip information display.
● When the parking lights are on, the brightness of the accessory meter can
be adjusted only with the instrument panel light control.
● If the “MODE/ ” button is pressed and held when the accessory meter
light control is displayed, the display will switch to compass calibration.
(P. 335)
■ Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem with continu-
ing to use the display.
NOTICE
■The accessory meter at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
display. At extremely low temperatures, the display monitor may respond
slowly, and display changes may be delayed.

922. Instrument cluster
4RUNNER (U)_(OM35A83U)

93
Operation of
each component
3
4RUNNER (U)_(OM35A83U) 3-1. Key information
Keys .................................... 94
Side doors ......................... 100
3-2. Opening, closing and locking the doors
Smart key system ............. 107
Automatic running boards ............................. 114
Back door .......................... 117
3-3. Adjusting the seats Front seats ........................ 122
Rear seats......................... 125
Driving position memory ........................... 135
Head restraints.................. 139
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 142
Inside rear view mirror ...... 144
Outside rear view mirrors ............................. 146
3-5. Opening, closing the windows and moon roof
Power windows ................. 148
Power back window .......... 151
Moon roof .......................... 155

94
4RUNNER (U)_(OM35A83U)
3-1. Key information
Vehicles without a smart key system
Master keys
Operating the wireless remote con-
trol function
Va l e t k e y
Key number plate
Vehicles with a smart key system
The following keys are provided with the vehicle.
Electronic keys
• Operating the smart key system(P. 107)
• Operating the wireless remote control function
Mechanical keys
Key number plate
Keys
The keys
1
2
3
1
2
3

953-1. Key information
3
Operation of each component
4RUNNER (U)_(OM35A83U)
Vehicles without a smart key systemLocks all the doors ( P. 100)
Sounds the alarm
(press and hold) ( P. 9 6 )
Unlocks all the doors
(  P. 100)
Pressing the button unlocks the
driver’s door. Pressing the but-
ton again within 3 seconds
unlocks the other doors.
Opens the windows and
moon roof (press and hold)
*
*
: This setting must be customized
at your Toyota dealer.
Vehicles with a smart key system
Locks all the doors ( P. 100)
Unlocks all the doors
(  P. 100)
Pressing the button unlocks the
driver’s door. Pressing the but-
ton again within 3 seconds
unlocks the other doors.
Opens the windows and
moon roof (press and hold)
*
Sounds the alarm
(press and hold) ( P. 9 6 )
*: This setting must be customized
at your Toyota dealer.
Wireless remote control (if equipped)
1
2
3
4
1
2
3
4

963-1. Key information
4RUNNER (U)_(OM35A83U)
To take out the mechanical key,
push the release button and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and re-
attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electronic key bat-
tery is depleted or the entry function does not operate properly, you will
need the mechanical key. (P. 450)
■Panic mode
Vehicles without a smart key system
Vehicles with a smart key system
■ When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. ( P. 299)
Vehicles without a smart key system: Carry the master key for your own use
and provide the attendant with the valet key.
Vehicles with a smart key system: Remove the mechanical key for your own
use and provide the attendant with the electronic key only.
Using the mechanical key (vehic les with a smart key system)
When is pressed for longer than
about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.
When is pressed for longer than
about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the
electronic key.
