A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461432
WARNING:
Always observe the following items fo r preventing accidental activation.
• Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
• Never use unspecified tester or other measuring device.
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the air bag diagnosis sensor unit for damage, bend and loose con-
nection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the main harness.
2.CHECK AIR BAG DIAGNOSIS SENSOR UNIT
Check the air bag diagnosis sensor unit. Refer to SRC-40, "Work Flow"
.
Is the inspection result normal?
YES >> Replace the main harness.
NO >> Replace parts whose air bag system has a malfunction.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN-66
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 1)]
MAIN LINE BETWEEN M&A AND A-
BAG CIRCUIT (WITH MANUAL A/C)
MAIN LINE BETWEEN M&A AND A-BAG CIRCUIT (WITH MANUAL A/C)
Diagnosis ProcedureINFOID:0000000009461440
1.CHECK HARNESS CONTINUITY (OPEN CIRCUIT)
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect the following harness connectors.
- Combination meter
-BCM
4. Check the continuity between the combination meter harness connector and the BCM harness connector.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main line between the combination meter and the air bag diag-
nosis sensor unit.
NO >> Repair the main line between the combination meter and the air bag diagnosis sensor unit.
Combination meter harness connector BCM harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M24 39
M18 60 Existed
38 59 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN-74
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 1)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461448
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the steering angle sensor for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of steering angle sensor.
2. Check the resistance between the steeri ng angle sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the steering angle sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the steering angle sensor. Refer to BRC-47, "Wiring Dia-
gram".
Is the inspection result normal?
YES (Present error)>>Replace the steering angle sensor. Refer to BRC-132, "Removal and Installation".
YES (Past error)>>Error was detected in the steering angle sensor branch line.
NO >> Repair the power supply and the ground circuit.
Steering angle sensor harness connector Resistance (Ω)
Connector No. Terminal No.
M53 5 2 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN
A-BAG BRANCH LINE CIRCUITLAN-75
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 1)]
C
D E
F
G H
I
J
K L
B
A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461449
WARNING:
Always observe the following items fo r preventing accidental activation.
• Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
• Never use unspecified tester or other measuring device.
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the air bag diagnosis sensor unit for damage, bend and loose con-
nection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the main harness.
2.CHECK AIR BAG DIAGNOSIS SENSOR UNIT
Check the air bag diagnosis sensor unit. Refer to SRC-40, "Work Flow"
.
Is the inspection result normal?
YES >> Replace the main harness.
NO >> Replace parts whose air bag system has a malfunction.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN
MAIN LINE BETWEEN M&A AND A-BAG CIRCUIT (WITH AUTO A/C)
LAN-81
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D E
F
G H
I
J
K L
B
A
O P
N
MAIN LINE BETWEEN M&A AND A-
BAG CIRCUIT (WITH AUTO A/C)
Diagnosis ProcedureINFOID:0000000009461454
1.CHECK HARNESS CONTINUITY (OPEN CIRCUIT)
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Disconnect the following harness connectors.
- Combination meter
- A/C auto amp.
-ECM
4. Check the continuity between the combination meter harness connector and the A/C auto amp. harness
connector.
Is the inspection result normal?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the main line between the combination meter and the air bag diag-
nosis sensor unit.
NO >> Repair the main line between the air bag diagnosis sensor unit and the air bag diagnosis sensor
unit.
Combination meter harness connector A/C auto amp. harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M24 39
M152 1 Existed
38 21 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN-82
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
MAIN LINE BETWEEN A-BAG AND HVAC CIRCUIT
MAIN LINE BETWEEN A-
BAG AND HVAC CIRCUIT
Diagnosis ProcedureINFOID:0000000009461455
1.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect the following harness connectors.
- Combination meter
- A/C auto amp.
-ECM
4. Check the continuity between the combination meter harness connector and the A/C auto amp. harness
connector.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main line between the air bag diagnosis sensor unit and the A/C
auto amp.
NO >> Repair the main line between the air bag diagnosis sensor unit and the A/C auto amp.
Combination meter harness connector A/C auto amp. harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M24 39
M152 1 Existed
38 21 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN-90
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461463
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the steering angle sensor for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of steering angle sensor.
2. Check the resistance between the steeri ng angle sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the steering angle sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the steering angle sensor. Refer to BRC-47, "Wiring Dia-
gram".
Is the inspection result normal?
YES (Present error)>>Replace the steering angle sensor. Refer to BRC-132, "Removal and Installation".
YES (Past error)>>Error was detected in the steering angle sensor branch line.
NO >> Repair the power supply and the ground circuit.
Steering angle sensor harness connector Resistance (Ω)
Connector No. Terminal No.
M53 5 2 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN
A-BAG BRANCH LINE CIRCUITLAN-91
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D E
F
G H
I
J
K L
B
A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461464
WARNING:
Always observe the following items fo r preventing accidental activation.
• Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
• Never use unspecified tester or other measuring device.
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the air bag diagnosis sensor unit for damage, bend and loose con-
nection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the main harness.
2.CHECK AIR BAG DIAGNOSIS SENSOR UNIT
Check the air bag diagnosis sensor unit. Refer to SRC-40, "Work Flow"
.
Is the inspection result normal?
YES >> Replace the main harness.
NO >> Replace parts whose air bag system has a malfunction.
