2014 MITSUBISHI OUTLANDER Owners Manual

Front seats 4-6 Seat and restraint systems
4
Operate the switch in the direction of the arrows to adjust the seatback.
N00402101253
Operate the lever repeatedly to raise or lower the seat.
Operate the switch in the direction of the arrows to raise or lower the seat.
Power seat adjustment 1- Move forward2- Move backward
NOTE
 To prevent the battery
from completely dis-
charging, operate the power seat with theengine running.
WA R N I N G To reduce the risk of serious injury or death in the event of
an accident or sud-
den stop, all seatbacks should be kept inthe upright position while the vehicle is in motion. Seat belt performance during an accidentcan be adversely affect
ed if the seatbacks
are reclined. The more a seatback is reclined, the more likely seat belt perfor-mance will be advers
ely affected. If the
seat belt is not prop
erly positioned against
the body during an accident, there isincreased risk you will slide under the belt and receive serious
injury or death.
To adjust the seat height (Driver’s seat only) Manual seat adjustment
1- Raise 2- LowerPower seat adjustment
NOTE
 To prevent the battery
from completely dis-
charging, operate the power seat with the engine running.
BK0200500US.book 6 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Front seats
Seat and restraint systems 4-7
4
N00435601391
The heated seats can
be operated by pushing
the switch when the ignition switch or the
operation mode is in ON. The indicator light (A) will illuminate while the heater is on.
1- Raise or lower the
front end of the seat
2- Raise or lower the back end of the seat
3- Raise or lower the entire seatHeated seat (if so equipped)
1 (HI) - Heater high (for quick heating) 2 - Heater off 3 (LO) - Heater low (to
keep the seat warm)
WA R N I N GPersons who are unable to feel tempera- ture change or skin
pain due to age, ill-
ness, injury, medication, alcohol use, fatigue or other phys
ical conditions or
who have sensitive sk
in may suffer burns
when using the heated seat even at low temperatures. To reduce the risk of burns,people with such conditions must use care when using the heated seat.
BK0200500US.book 7 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Second row seats 4-8 Seat and restraint systems
4
N00402501231
When sitting in the mi
ddle seating position of
the second row seat, adjust the head restraints
to an appropriate height where they lock in position. Refer to “Head restraints” on page4-10. Pull the seat adjusting lever up and slide the seat forward or backwa
rd to the desired posi-
tion. Release the adjusting lever to lock the seat in place.
Pull the lever up and adjust the seatback by hand to the desired position, and release thelever. The seatback will lock in place.
CAUTION Switch off the heated seats when not in use. Operate the heaters at the “HI” position forquick heating. After the seat has becomewarm, set the heater switch to the “LO” posi- tion to keep it warm. S
light variations in the
seat temperature may be
felt while using the
heated seats. This is
caused by the operation
of the heater’s internal thermostat and does not indicate a malfunction. Do not place heavy obj
ects on the seat or
stick pins, needles, or
other pointed objects
into the seat. Do not place a blanket,
cushion, or other
insulating material on the seat while using the heater; doing so can
cause the heater ele-
ment to overheat. When cleaning the seat, do not use benzine, kerosene, gasoline, alc
ohol, or other organic
solvents; doing so can cause damage not only to the surface of the seat, but also to the heater. If water or any other li
quid is spilled on the
seat, allow it to dry thoroughly beforeattempting to use the heater. Turn the heater off immediately if it
appears to be malfunc-
tioning during use.
Second row seats
To adjust the seat forward or backward (vehicles with sec- ond row seat slide function)
NOTE
 You can adjust the seat forward or backward on either side separately.
WA R N I N G To make sure that the seat is securely locked, try to move it forward or back-ward without using
the adjusting lever.
CAUTIONWhen sliding (vehicles with second row seat slide function) or reclining the seat rearward, pay careful attention to the third row seat passengers.
To adjust the seatbacks
BK0200500US.book 8 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Second row seats
Seat and restraint systems 4-9
4
N00403001318
To use the armrest, tilt the arm rest down for use as shown. The arm rest includes a cup holder.
N00400101031
For third row seat passenger entry or exit, thesecond row seats can be moved forward.Pull up the lever (A) and tilt the seatback for- ward. Then slide the entire seat forward.
To return the seat, slide the entire seat back- ward to the desired position and then raise theseatback until it locks securely. After returning the seat, gently try to move it forward and backward to check that it issecurely retained and adjust the seatback to the normal seating position.
NOTE
 You can adjust the seatback forward or back- ward on either side separately.WA R N I N G To reduce the risk of serious injury or death in the event of
an accident or sud-
den stop, all seatbacks should be kept in the upright position wh
ile the vehicle is in
motion. Seat belt performance during an accident can be adversely affect
ed if the seatbacks
are reclined. The more a seatback is reclined, the more likely seat belt perfor- mance will be advers
ely affected. If the
seat belt is not prop
erly positioned against
the body during an accident, there is increased risk you will slide under the beltand receive serious
injury or death.
When a person is sitting in the middle seating position of the second row seats, the two sides of the second seats must have the same forward/backward position(vehicles with second row seat slide func- tion) and the same seatback angle.
Arm rest
NOTE
 Never sit on an arm rest. Doing so could damage the arm rest.
Accessing the third row seat (Walk-in function, Seating 7 passengers)
WA R N I N G To make sure that the seat is securely locked, try to move
it forward or back-
ward without using the lever. To reduce the risk of serious in
jury or death in the
event of an accident
or sudden stop, all
seatbacks should be kept in the upright position while the ve
hicle is in motion.
BK0200500US.book 9 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Third row seat (Seating 7 passengers) 4-10 Seat and restraint systems
4
N00419501073
Pull up the strap and ad
just the seatback by
hand to the desired position, and release thestrap.
N00404301594
Head restraints can reduc
e the risk of a whip-
lash injury if your vehicle is hit from the rear. The head restraints are equipped in the illus-trated position. To maximize the effectiveness of the head restraints, adjust the seatback to the uprightposition, and the head
restraint to the proper
position. Sit back against the seatback with your head close to
the head restraint.
Third row seat (Seating 7 passengers)
WA R N I N G The third row seats are intended for use by no more than two belted occupants,each of which does not exceed 160 cm (63 inches) in height. Exceeding these limitations can result inan increased risk of
personal injury or
death in the event
of an accident.
To adjust the seatback
Head restraints *: Seating 7 passengers
WA R N I N GDriving without the
head restraints in
place can cause you and your passengersserious injury or deat
h in an accident. To
reduce the risk of injury in an accident, always make sure the head restraints are installed and proper
ly positioned when
the seat is occupied. In order to minimize the risk of a neck injury due to a rear impact, the seatback must be adjusted to the upright position and the head restraint
must be adjusted to
the proper position before vehicle opera- tion. The driver shou
ld never adjust the
seat while the vehicle is in motion. Never place a cushion
or similar device on
the seatback. This can adversely affecthead restraint performance by increasing the distance betwee
n your head and the
restraint.
BK0200500US.book 10 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Head restraints
Seat and restraint systems 4-11
4
To reduce the risk of injury in an accident, adjust the head restraint height so that thecenter of the restraint is at your ear level when seated. Any person too tall for the restraint to reach their ear level when seatedshould raise the restraint to the highest locked position.  To raise the restraint, pull it straight up.  To lower the restraint, push down on it while pressing the lock knob (A) in the direction shown by the arrow. After adjusting the height, push down on the restraint to make sure it is locked in position.
Press the lock knob (A) in the direction shown by the arrows. Then pull the head restraint up and out of the seatback. First check that the head restraint is facing in the right direction as shown in the previousillustration, and then insert it into the seat- back. Push the head
restraint down while
When a person sits in the second center seating position, pull up
the head restraint
to a height at which it locks in position. Besure to make this adjustment before start- ing to drive. Serious injuries could other- wise be suffered in the result of an impact.NOTE
 The head restraint height in the second row outboard seats and the third row seats cannot be adjusted.WA R N I N G
Adjustment of the head restraint height (front seats)
To remove
WA R N I N G To help minimize the risk of neck injury in the event of an accident, the headrestraints must be properly installed and positioned to proper height before vehicle operation.
To install
BK0200500US.book 11 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Making a cargo area 4-12 Seat and restraint systems
4
pressing the lock knob (A) until the restraint locks into place.
N00405501115
N00405701120
The second row seat can be folded to create an additional cargo area.
CAUTION Check that the lock knob (A) is extended out as shown in the illustration. Then pull the head restraint up to make sure that it is locked in place and will
not come out of the
seatback.CAUTION The shape and size of the head restraint dif- fers according to the seat. Always use the correct head restraint provided for the seatand do not install the he
ad restraint in the
wrong direction.
Making a cargo area
WA R N I N G Never adjust the seats to make a cargo area when the vehicle is in motion or on a slope. The seats co
uld move more than
necessary or move su
ddenly and causing a
serious accident
and/or injury.
When returning a seat back to its seating position after fold
ing down, make sure
that the seat is firmly secured and seat beltbuckles are in proper
position. If the seat
is not secured, it could move causing a serious accident. Do not allow anyone to ride in the cargo area while the vehicle
is in motion. People
who are not properly seated and restrained can be seriously injured or killed in an accident.
 When driving the vehicle, do not allow anyone to sit on the third row seat if thesecond row seat is in the folded position.CAUTION In the cargo area, do not load the luggage higher than the top of the seats and makesure that the luggage is firmly secured. Restricted rear vision or
flying objects enter-
ing the passenger compartment during sud-den braking could result
in a serious accident
and/or injury. Seats should always be
operated by an adult.
Seat adjustments by a child could lead to an unexpected accident. When adjusting the seats, be careful not to catch your hand or leg.
Personal injury could
result.NOTE
 When the seatback of a front seat is reclined, return it to the upright
position before driv-
ing.
Folding the second row seats
WA R N I N G
BK0200500US.book 12 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Making a cargo area
Seat and restraint systems 4-13
4
1. Remove the head re
straints from the sec-
ond row outside seating position. Lower the head restraint for second rowmiddle seating position to its lowest posi- tion. Refer to “Head restraints” on page 4-10.2. When the left side second row seat is folded, store the seat belt for the middle seating position of the second row seat.Refer to “Detachable
center seat belt for
second row” on page 4-20. 3. On vehicles with the second row seat slidefunction, move the se
cond row seat fully
backward. Refer to “To adjust the seat forward orbackward” on page 4-8.
4. Lift the front end of the seat cushion. 5. Flip the seat cushion forward. On vehicles with the third row seats, move the lever (A) to the luggage area mode position.
6. Fold forward the seat belt buckle. 7. Pull up the lever (C), then fold the seat- back forward.
NOTE
 You can separately fold
the right and left side
of the second row seat.
To fold the second row seat
NOTE
 If you do not move the second row seat fully backward, you may not be able to fold the second row seat.
CAUTION Do not allow any person
to get on the plastic
cover (B), and do not
place luggage on it.
Doing so could damage
the plastic cover.
BK0200500US.book 13 ページ ２０１３年２月１２日　火曜日　午前９時４６分
