2014 MITSUBISHI OUTLANDER Owners Manual

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-155
5
 The seat belt is not fastened when the ignition switch or operation mode is in ON.
 Wear your seat belt properly. Refer to “Seat belt warning” on page 4-22.
 There is a fault in the fuel system.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.
 The vehicle is being driven with the parking brake still applied.
 Release the parking brake.
Refer to “Brake warning
display” on page 5-169.
 There is a fault in the engi
ne oil circul
ation system.
Park your vehicle in a safe
place as soon as possible
and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked.Refer to “Oil pressure
warning display” on page
5-170.
 There is a fault in the charging system.
Park your vehicle in a safe
place as soon as possible
and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice for assistance.
Refer to “Charging system
warning display” on page
5-170.
Screen
Cause
Do this (Reference)
BK0200500US.book 155 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-156 Features and controls
5
 There is a fault in the SRS airbag or the pre-tensioner system.
 Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked, immediately. Refer to “SRS airbag/Pre-t
ensioner system warning”
on page 4-39.
 There is a fault in the Active stability control (ASC).
Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked.Refer to “Active stability control (ASC)” on page 5-90.
 There is a fault in the Hill start assist.
Have the vehicle checked at
an authorized Mitsubi-
shi Motors dealer or a repa
ir facility of your choice.
Refer to “Hill start assist” on page 5-85.
 There is a fault in the electronically controlled 4WD system.
 Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked.Refer to “Electronically c
ontrolled 4WD system” on
page 5-75.
 There is a fault in the automatic transaxle or CVT.
Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked.Refer to “Automatic tr
ansaxle” on page 5-60.
Refer to “Continuously
variable transmission
(CVT)” on page 5-68.
 The electronically controlled 4WD
system is hot. Refer to “Electr
onically controlled
4WD system” on
page 5-75.
Screen
Cause
Do this (Reference)
BK0200500US.book 156 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-157
5
 The fuel is running low.
Refuel as soon as possible. Refer to “Fuel remaining
display screen” on page
5-129.
 The outside temperature is 37 °F (3 °C) or less.
Be careful driving on frozen ground.  The ground may be frozen even when this warning is not displayed, so
drive carefully.
 The Adaptive Cruise Control System (ACC) has detected the approach of
the vehicles in front.
 Increase the following distance by depressing the brake pedal or marking ot
her decelerating control.
Refer to “Adaptive Cruise Control System (ACC): Proximity alarm” on page 5-101.
 The Forward Collision Mi
tigation System (FCM)
has detected the danger of collision.
 Take appropriate action such as depressing the brake to avoid collision. Refer to “FCM braking function” on page 5-108.
 The Adaptive Cruise Control System (ACC) detected a stop of the ve
hicle in front and stopped
your vehicle, but the brak
e will be re
leased soon.
 Depress the brake pedal
as soon as your vehicle
comes to a stop. Refer to “How to use ACC” on page 5-98.
Screen
Cause
Do this (Reference)
BK0200500US.book 157 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-158 Features and controls
5
 The Adaptive Cruise Control System (ACC) control is automatically canceled and the system is placed in the ‘standby’ state.
Refer to “How to use ACC” on page 5-98.
 Conditions for the start of control are not met, the Adaptive Cruise Control Sy
stem (ACC) can not start
the control.  The Adaptive Cruise Control System (ACC) can not start the control because th
e speed is out of speed
range.  The Adaptive Cruise Control System (ACC) can not start the control because not
detected the approach of
the vehicles in front.  The Adaptive Cruise Control System (ACC) is tem- porarily unavailable due to conditions such as the adhesion of contaminants to the sensor.  There is a fault in the Adaptive Cruise Control Sys- tem (ACC).
 Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “Adaptive Cruise
Control System (ACC)”
on page 5-96.
Screen
Cause
Do this (Reference)
BK0200500US.book 158 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-159
5
 There is a fault in the Forward Collision Mitigation System (FCM).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “Forward Colli
sion Mitigation System
(FCM)” on page 5-107.
 FCM braking function of the Forward Collision Mit- igation System (FCM) has been activated.
Refer to “FCM braking
function” on page 5-108.
 The Forward Collision Mitig
ation System (FCM) is
temporarily unavailable due
to conditions such as the
adhesion of contaminants to the sensor.  The Lane Departure Warn
ing (LDW) has detected
that your vehicle is about to
leave or has left the lane.
Refer to “Lane Departure
Warning (LDW)” on page
5-111.
 The Lane Departure Warni
ng (LDW) is temporarily
unavailable due to too high of a temperature of the LDW camera.  There is a fault in the
Lane Departure Warning
(LDW).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.Refer to “Lane Departure
Warning (LDW)” on page
5-111.
Screen
Cause
Do this (Reference)
BK0200500US.book 159 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-160 Features and controls
5
N00579100026
On vehicles equipped
with Mitsubishi Multi-
Communication System, the following infor- mation on navigation will
be displayed when
guidance location such as junction and desti- nation is approached af
ter you set the destina-
tion and started the route guidance.Navigation information display
(if
so equipped)1- Guidance display
Shows the direction of vehicle travel and the guidance location.
2- Remaining distance display
Shows the distance to the location where the guidance is displayed.NOTE
 Please read this section and also the separate owner’s manual for Mi
tsubishi Multi-Com-
munication System.
Direction of vehicle travel (Example) Destination Ferry terminal Tollbooth Intermediate destination (Example)
BK0200500US.book 160 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-161
5
N00558201252
The operation status of each syst
em is displayed on the informat
ion screen. For furthe
r details, refer to
the appropriate page
for each system.
Other interrupt displays
Screen
System operation status
Reference
 When starting the engine, the selector lever is in a positi
on other than the “P”
(PARK) or the “N” (NEUTRAL) posi-tion, or you pressed the engine switch without depressing the brake pedal.
 Place the selector lever in the “P” (PARK) position, depress and hold the brake pedal with the right foot, and then press the engine switch to start the engine. Refer to “Starting and stopping the engine” on page 5-23.
Screen
System operation status
Reference
 When “4WD ECO” drive mode is selected with the drive mode selector.
Refer to “Electronica
lly controlled 4WD
system” on page 5-75.
 When “4WD AUTO” mode is selected with the drive mode selector.  When “4WD LOCK” mode is selected with the drive mode selector.
BK0200500US.book 161 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-162 Features and controls
5
 When “AWC ECO” mode of S-AWC is selected.
Refer to “S-AWC (Super-All Wheel Con- trol)” on page 5-78.
 When “NORMAL” mode of S-AWC is selected.  When “SNOW” mode of S-AWC is selected.  When “LOCK” mode of S-AWC is selected.  When the ECO mode is ac
tivated. Refer to “ECO m
ode switch” on page 5-178.
Screen
System operation status
Reference
