2014 LEXUS LX570 Owners Manual

5
When trouble arises
8475-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) Other messages
If the following message is displayed, take appropriate action and confirm
that the message has disappeared. (  P. 335)Message Correction procedure
Select the four-wheel drive control switch in L4 and
shift the shift lever to “D” or “R”.
Confirm the operating conditions.
Confirm the operating conditions to operate Turn
Assist function.
Turn on the Crawl Control switch to operate Turn
Assist function.

8485-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) ■
Resetting the tire pressure warning data
After adjusting the tire inflation pressu re, be sure to initialize the data. (  P. 76 4 )
If the message remains on, the system ma y have malfunctioned. Have the vehicle
inspected by your Lexus dealer as soon as possible. ■
Warning message in vehicle-to-vehicle distance control mode of the dynamic
radar cruise control (if equipped)
In the following cases, the warning message may not be displayed even if vehicle-
to-vehicle distance decreases: ●
When your vehicle and the vehicle ahead are traveling at the same speed or the
vehicle ahead is traveling more quickly than your vehicle ●
When the vehicle ahead is traveling at a very low speed ●
Immediately after cruise control speed is set ●
At the instant the accelerator pedal is depressed
NOTICE■
While the engine oil level warning is displayed
Continued engine operation with low engine oil will damage the engine.

5
When trouble arises
8495-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) If you have a flat tire Remove the flat tire and replace it with the spare provided.
■ Before jacking up the vehicle
● Stop the vehicle on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to “P”.
● Turn off the 4-Wheel AHC. (  P. 318)
● Stop the engine.
● Turn on the emergency flashers.
■ Location of the spare tire, jack and tools
Jack To o l b o x
Spare tire

8505-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) Taking out the jack
Remove the cover.
Unhook the rubber band and take
out the jack.
Loosen
Tighten
Loosen and remove the jack.STEP 1
STEP 2

5
When trouble arises
8515-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) Taking out the tool box
Remove the cover.
Take out the tool box.STEP 1
STEP 2

8525-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) Taking out the spare tire
Assembling the jack handle. Remove the jack handle and the jack extension bar from the tool box
and assemble by following these steps.
Loosen the screw using a
screwdriver.
Assemble the jack handle and
the jack handle extension bar
and tighten the screw. Check that the screw is firmly tight-
ened.
Open the cover.STEP 1
STEP 2

5
When trouble arises
8535-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) Insert the jack handle extension
into the lowering screw.
Lower
Raise Place a rag under the jack handle
extension to protect the back door.
Lower the spare tire completely to
the ground.
Pull out the spare tire and remove
the holding bracket.STEP 3
STEP 4
STEP 5

8545-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) Replacing a flat tire
Chock the tires.
Pry off the wheel ornament, using
the beveled end of the wheel orna-
ment remover as shown.STEP 1STEP 1
Flat tire Wheel chock positions
Front Left-hand side Behind the rear right-hand side tire
Right-hand side Behind the rear left-hand side tire
Rear Left-hand side In front of the front right-hand side tire
Right-hand side In front of the front left-hand side tireSTEP 2
