2014 CHRYSLER 300 SRT Owners Manual

Page 529 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual Cavity Cartridge Fuse Mini-FuseDescription
64 –25 Amp Natu-
ral Rear Windows
65 –10 Amp Red Airbag Module
66 –– Fuse – Spare
67 –15 Amp Blue Run Sense
68 –15 Amp Blue Illumination/Rear S

Page 530 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual REPLACEMENT BULBS
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.
Interior Bulbs
Bulb Number
Rear

Page 531 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual Bulb Number
Daytime Running Lamp LED (Serviced at Authorized Dealer)
Front Fog Lamp – If
Equipped H11
Front Sidemarker Lamp LED (Serviced at Authorized Dealer)
Rear Tail/Stop/Turn
Lamp LED (Serviced

Page 532 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual WARNING!
A transient high voltage occurs at the bulb sockets of
HID headlamps when the headlamp switch is turned
ON. It may cause serious electrical shock or electro-
cution if not serviced properly.

Page 533 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Front T

Page 534 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual 4. Remove the three wing nuts from the back of the taillamp assembly.
5. Pull the tail lamp assembly away from the vehicle enough to access the electrical connector.
6. Push the electrical connector l

Page 535 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual 4. Reinstall the bulb and socket assembly.
5. Reattach the lamp to the rear fascia, and then installthe screws.
Socket Assembly
1 — License Lamp Bulb
2 — Socket7
MAINTAINING YOUR VEHICLE 533

Page 536 of 590

CHRYSLER 300 SRT 2014 2.G Owners Manual FLUID CAPACITIES
U.S.Metric
Fuel (Approximate) 19 Gallons72 Liters
Engine Oil With Filter
6.4 Liter Engine (SAE 0W-40, Synthetic API Certified) 7 Quarts6.6 Liters
Cooling System *
6.4 Liter Engine (MO
