2014 Acura TL Owner's Manual

Î
Although your tire pressure is
monitored, you must manually check
thetirepressuresmonthly.
Each tire, including the spare, should
be checked monthly when the
vehicle is cold, and set to the
recommended inf lation pressure as
specif ied on the vehicle placard and
intheowner’smanual(seepage).
For example, if you check and f ill
your tires in a warm area, then drive
in extremely cold weather, the tire
pressure will be lower than
measured and could be underinf lated
and cause the low tire pressure/
TPMS indicator to come on. Or, if
youcheckandadjustyourtire
pressure in cooler conditions, and
drive into extremely hot conditions,
the tire may become overinf lated.
However, the low tire pressure/
TPMS indicator will not come on if
thetiresareoverinflated.
Refer to page for tire inflation
guidelines.
If there is a problem with the TPMS,
this indicator begins to f lash. It stops
flashing after approximately 1
minute, then stays on. You will also
see a ‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display (see page ). Toselectthetirepressuremonitor,
press the INFO button several times
with the ignition switch in the ON
(II) position or with the power mode
ON.
You will see the above display on the
multi-inf ormation display when each
tire pressure is normal.
517 570
568
CONT INUED
Tire Pressure Monitor
Tire Pressure Monitoring System (TPMS)
Driving
515
U.S.
Example: Technology Package is shown.
12/07/20 11:36:50 31TK4640_520

Î Each tire pressure is shown in PSI
(U.S. models) or in kPa (Canadian
models).If any of the tires has low pressure,
thetirepressuremonitoralsoshows
the above message and each tire
pressure to warn you about the low
tire pressure when you select the
displaybypressingtheINFObutton
several times.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low, the sensor in that
tire immediately sends a signal that
causes the low tire pressure/TPMS
indicator in the instrument panel to
come on. If this happens, you will see
which tire is losing pressure on the
multi-inf ormation display along with
a ‘‘CHECK TIRE PRESSURE’’
message.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
:
184 187
Tire Pressure Monitoring System (TPMS)
516
Canadian model
Canada
This shows that the front left tire is
losing pressure. U.S. model
Example: Technology Package is
shown.
12/07/20 11:36:57 31TK4640_521

If there is a problem with the TPMS,
thetirepressuremonitorshowsa
‘‘TPMS ERROR’’ message and the
tire pressure readings are not
displayed. If this happens, you will
f irst see a system warning message
‘‘CHECK TPMS SYSTEM’’ on the
multi-inf ormation display.If there is a problem with the TPMS,
youwillseetheabovemessageon
the multi-information display.If the low tire pressure/TPMS
indicator comes on, or the multi-
inf ormation display shows a
‘‘CHECK TPMS SYSTEM’’ message,
the VSA system automatically turns
on even when the VSA system is
turned of f by pressing the VSA OFF
switch (see page ). If this
happens, you cannot turn the VSA
system of f by pressing the VSA OFF
switch again.
When you restart the vehicle with
thecompactsparetire,theTPMS
system message will also be
displayed on the multi-information
display af ter several miles
(kilometers) driving.
If you see this message, the system
is of f and is not monitoring the tire
pressures. Have the system checked
by your dealer as soon as possible.
Also, the low tire pressure/TPMS
indicator begins to f lash, then stays
on (see page ). 511
515
TPMS System Failure
Tire Pressure Monitoring System (TPMS)
Driving
517
U.S. model Canadian model
12/07/20 11:37:05 31TK4640_522

If you have a f lat tire, the low tire
pressure/TPMS indicator and tire
monitor indicator will come on.
Replace the indicated f lat tire with
thecompactsparetire(seepage).
After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on while
driving. Af ter several miles
(kilometers) driving, this indicator
begins to f lash, then stays on again.
You will also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
inf ormation display. This is normal;
the system cannot monitor the spare
tire pressure. Manually check the
spare tire pressure to be sure it is
correct.
This indicator and the warning
message on the multi-inf ormation
display will go of f , af ter several miles
(kilometers) driving, when the spare tire is replaced with the specified
regular tire equipped with the tire
pressure monitor sensor.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
If the low tire pressure/TPMS
indicator and the low tire position on
the low tire pressure monitor do not
go out af ter inf lating the tires to the
specified values, have your dealer
check the system as soon as possible. Each wheel (except the compact
sparetirewheel)isequippedwitha
tire pressure sensor. You must use
TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
qualif ied technician.
This device complies with the
appropriate requirements or the
required standards. See page f or
more inf ormation.
583 628
Changing a T ire with T PMS
Tire Pressure Monitoring System (TPMS)
518
12/07/20 11:37:12 31TK4640_523

If the system detects vehicles in
adjacent lanes, it automatically
illuminates the appropriate indicator
to provide assistance when you
change lanes. It is not a substitute
for visual confirmation that it is safe
to change lanes.
The blind spot inf ormation system
(BSI) is designed to assist you when
you are changing lanes.If equipped
Blind Spot Inf ormation System (BSI)
Driving
519
Failure to visually confirm that it
is safe to change lanes before
doing so may result in a crash
and serious injury or death.
Do not rely only on the blind
spot information system when
changing lanes.
Always look in your mirrors, to
either side of your vehicle, and
behind you for other vehicles
before changing lanes.
12/07/20 11:37:17 31TK4640_524

A: Approximately 1.6 f t. (0.5 m)
B: Approximately 10 f t. (3 m)
C: Approximately 10 f t. (3 m)
BSI system is designed to detect
vehicles in specif ied alert zones
adjacent to your vehicle, particularly
in harder to see areas commonly
known as ‘‘blind spots.’’When BSI detects a vehicle in an
alert zone, a BSI alert indicator
comes on near the corresponding
outside rearview mirror.
While your vehicle is moving
f orward at a speed between 6 mph
(10 km/h) and 100 mph (160 km/h),
the BSI alert indicator comes on
under either of the f ollowing
conditions:
The system will not alert you to all
vehicles in blind spot zones (such as
vehicles you have just passed which
youshouldalreadybeawareof)
unless it remains in the alert zone f or
approximately 2 or more seconds.
Another vehicle overtakes you,
entering the alert zone from
behind, at a speed that dif f ers
f rom your vehicle’s speed by no
more than 31 mph (50 km/h).
You pass a vehicle at a speed that
differs from that vehicle’s speed
by no more than 12 mph (20
km/h). The indicator comes on
approximately 2 seconds af ter the
vehicle enters the alert zone. While the system is on, BSI is active
whenever the shif t lever is in the D
or S position.
Blind Spot Inf ormation System (BSI)
BSI System Operation
520
A
B
CALERT
ZONE
12/07/20 11:37:25 31TK4640_525

CONT INUED
Blind Spot Inf ormation System (BSI)
Driving
521
BSI INDICATOR
BSI OFF BUTTONMULTI-INFORMATION DISPLAY
BSI ALERT INDICATOR
LEFT SIDE RIGHT SIDE
U.S. model is shown.
12/07/20 11:37:30 31TK4640_526

The BSI alert indicator starts to blink
as a reminder if you move the turn
signal lever in the direction of the
detected vehicle.Radar sensors, located underneath
each corner of the rear bumper,
detect objects. Do not cover this area
with labels or stickers of any kind.
Always keep this area f ree of any
kind of dirt every time you get in the
vehicle.Impacts to the radar sensors or the
area around them can af f ect system
perf ormance. If an impact occurs,
have the system checked by your
dealer.
Blind Spot Inf ormation System (BSI)
522
ALERT INDICATOR
LEVER
ILLUMINATEBLINK
12/07/20 11:37:35 31TK4640_527
