2014 Acura TL Owner's Manual

In addition, the total weight of the
vehicle, all occupants, accessories,
cargo, and trailer tongue load must
not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross
Axle Weight Rating (GAWR). Both
areonalabelonthedriver’s
doorjamb.Store or secure all items that could
be thrown around and hurt
someone during a crash.
Do not put any items on top of the
trunk panel. They can block your
view and be thrown around the
vehicle during a crash.
Example 1
Example 2
Example 3
CONT INUED
Carrying Cargo in the Passenger
Compartment
Carrying Cargo
Bef ore Driving
483
Passenger Weight
150 lbs x 2 = 300 lbs
(68kgx2=136kg)
Passenger Weight
150 lbs x 4 = 600 lbs
(68kgx4=272kg)
Passenger Weight
150 lbs x 5 = 750 lbs
(68kgx5=340kg)
Max Load 850 lbs
(385 kg)
Max Load 850 lbs (385 kg)
Max Load 850 lbs (385 kg) Cargo Weight
550 lbs
(249 kg)
Cargo Weight
250 lbs
(113 kg)
Cargo Weight
100 lbs
(45 kg)
12/07/20 11:32:57 31TK4640_488

Be sure items placed on the f loor
behind the f ront seats cannot roll
underneath and interf ere with the
proper operation of the seats, the
sensors under the seats, or the
driver’s ability to operate the
pedals.
Keep all cargo below the bottom
of the windows. If it is higher, it
could interf ere with the proper
operation of the side curtain
airbags.
Keep the glove box closed while
driving. If it is open, a passenger
could injure their knees during a
crash or sudden stop.Cargo hook buttons in the trunk can
be used to install a net f or securing
items.
The cargo net can be used to help
hold down items stored in the trunk.
Distribute cargo evenly on the
f loor of the trunk, placing the
heaviest items on the bottom and
as far forward as possible.
If you carry large items that
prevent you f rom closing the trunk
lid, exhaust gas can enter the
passenger area. To avoid the
possibility of
, f ollow the instructions
on page . 57
If equipped
Cargo Nets
Carrying Cargo in the Trunk Cargo Hook Buttons
carbon monoxide
poisoning
Carrying Cargo
484
CARGO HOOK BUTTON
12/07/20 11:33:06 31TK4640_489

This section gives you tips on
starting the engine under various
conditions, and how to operate the
manual and automatic transmissions.
It also includes important
information on parking your vehicle,
the braking system, the Super
Handling-All Wheel Drive
(SH-AWD
) system, the vehicle
stability assist (VSA
), aka
electronic stability control (ESC),
system, the tire pressure monitoring
system (TPMS), and the blind spot
inf ormation system (BSI). ........................
Preparing to Drive . 486
Starting the Engine
(Models without Keyless .....................
Access System) . 487
Starting the Engine (Models with Keyless .....................
Access System) . 489
...................
Manual Transmission . 491
..............
Automatic Transmission . 494
Driving with the Paddle
.......................................
Shif ters . 499
Super Handling-All Wheel ...
Drive (SH-AWD
) System . 504
...........................................
Parking . 506
.............................
Braking System . 507
...............
Anti-lock Brakes (ABS) . 508
Vehicle Stability Assist (VSA
),
aka Electronic Stability ........
Control (ESC), System . 510
.........................
Hill Start Assist . 512
Tire Pressure Monitoring ........................
System (TPMS) . 514
Blind Spot Inf ormation System ...........................................
(BSI) . 519
...........................
Towing a Trailer . 528
...................
Towing Your Vehicle . 528
Driving
Driving
485
TM
TM
12/07/20 11:33:10 31TK4640_490

Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice.Check the seat adjustment (see
page ).
Check the adjustment of the
inside and outside mirrors (see
page ).
Check the steering wheel
adjustment (see page ).
Make sure the doors are securely
closed and locked.
Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ).When you start the engine, check
the gauges and indicators in the
instrument panel, and the
messages on the multi-inf ormation
display (see pages , and
).
Youshoulddothesechecksand
adjustments bef ore you drive your
vehicle:
Check that the hood is f ully closed.
Check that the trunk is f ully
closed.
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure.
Check that any items you may be
carrying are stored properly or
f astened down securely.
3.
2.
1.
7.
8.
9.
4.
5. 6.
63
16
10. 11.
78 76
167
146
161
Preparing to Drive
486
12/07/20 11:33:19 31TK4640_491

µ
Your vehicle’s starting system has an
auto control mode. When you turn
the ignition switch to the START
(III) position, this f eature keeps the
engine’s starter motor running until
the engine starts. Follow these
instructions to start the engine:
Make sure the shif t lever is in
Park. Press on the brake pedal. In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery. Apply the parking brake. Without touching the accelerator
pedal, turn the ignition switch to
the START (III) position, then
release the ignition switch. You do
not need to hold the ignition
switch in the START (III) position
to start the engine. The starter
motor runs until the engine starts
or a maximum of 10 25 seconds
depending on engine coolant
temperature.
If the engine does not start, wait at
least 10 seconds bef ore trying
again.
1.
2.
3. 4.
Starting the Engine (Models without Keyless Access System)
Driving
487
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem.
T he immobilizer system protects your
vehicle f rom thef t. If an improperly
coded key (or other device) is used, the
engine’s f uel system is disabled. For
more inf ormation, see page . 149
12/07/20 11:33:26 31TK4640_492

If there is a problem with the
starting system, you will see a
‘‘CHECK STARTING SYSTEM’’
message on the multi-inf ormation
display when the ignition switch is
turned to the ON (II) position. You
will also see this message when the
auto control mode of the starting
system has a problem.If this message is on, the ignition
switchhastobeheldintheSTART
(III) position manually until the
engine starts. The ignition switch
canbeheldinthatpositionupto15
seconds.
Even though you may be able to
start the engine manually without
the auto control mode of the starting
system, have your vehicle inspected
by a dealer.
Check Starting System Message
Starting the Engine (Models without Keyless Access System)
488
12/07/20 11:33:31 31TK4640_493

µ
The keyless access remote battery
becomes weak or dead. The keyless access remote system
main switch is of f .
In either of the f ollowing cases, you
should insert the keyless access
remote into the keyless remote slot.
For more inf ormation, see pages
and .
Your vehicle’s starting system has an
auto control mode. When you have
your keyless access remote and push
the engine start/stop button while
depressing the brake pedal (A/T) or
clutch pedal (M/T), this f eature
keeps the engine’s starter motor
running until the engine starts.
Follow these instructions to start the
engine:
Make sure the shif t lever is in
Park. Press on the brake pedal. Press the clutch pedal down all the
way. The power mode f rom ON to
START does not f unction unless
the clutch pedal is pressed. In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery. Apply the parking brake. Without touching the accelerator
pedal, push and release the engine
start/stop button. You do not need
to hold the engine start/stop
button to start the engine. The
starter motor runs until the engine
starts or a maximum of 10 25
seconds depending on engine
coolant temperature.If the engine does not start, wait at
least 10 seconds bef ore trying
again.
1.
2.
3. 4.194 195
Automatic transmission:
Manual transmission:
Starting the Engine (Models with Keyless Access System)
Driving
489
T he immobilizer system protects your
vehicle f rom thef t. If an improperly
coded keyless access remote (or other
device) is used, the engine’s f uel system
is disabled. For more inf ormation, see
page .
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem. 149
12/07/20 11:33:41 31TK4640_494

If you cannot start the engine using
the normal engine start procedure,
do the f ollowing:Set the parking brake.
If there is a problem with the
starting system, you will see a
‘‘CHECK STARTING SYSTEM’’
message on the multi-inf ormation
display with the power mode ON.
You will also see this message when
the auto control mode of the starting
system has a problem. Do not f ollow this procedure unless
it is a case of emergency. Even if you
can start the engine using this
method, the system may have a
malf unction. Contact your dealer as
soon as possible.Press and hold the engine start/
stop button f or about 15 seconds
while pressing the brake pedal
(automatic) or the clutch pedal
(manual). Press the engine start/stop button
to turn on the ACCESSORY mode. Put the shif t lever into Park.
If this message is on, you should
press and hold the engine start/stop
button until the engine starts. The
engine start/stop button may need to
be held several seconds bef ore the
starter motor runs. The starter
motor can be run up to 15 seconds.
Your vehicle has the engine start/
stop button instead of an ignition
switch to select the power mode. For
more information, see page . Even though you may be able to
start the engine manually without
the auto control mode of the starting
system, have your vehicle inspected
by a dealer.
1.
2.
3.
4.
184
Automatic transmission:
Starting the Engine (Models with Keyless Access System)
Emergency Engine Start
Check Starting System Message
490
