2014 Acura TL check engine

(f luid capacities and tire pressures)
(main controls)
(seat belts, SRS, and child protection)
(indicators, gauges, multi-inf ormation display, dashboard, and steering column)
( )
(fuel, vehicle break-in, and cargo loading)
(engine and transmission operation) (minder, f luid checking, minor services, and vehicle storage) (f lat tire, jump starting, overheating, and f uses)
(vehicle specif ications, tires, and emissions controls) (warranty and contact inf ormation)
(how to order)
climate control, audio, steering wheel, security, cruise control, HomeLink, and other convenience items
Contents
........................................................................\
........................................................................
Index .I
..................................................
Service Inf ormation Summary . last page
........................................................................\
.......................
Your Vehicle at a Glance .3
............................................................
Driver and Passenger Saf ety .5
.......
Instruments and Controls .61
..............
Features .225
.......................................................................
Bef ore Driving .467
........................................................................\
.................
Driving .485
.................................................
Maintenance .529
........................................
T aking Care of the Unexpected .581
..............................................
T echnical Inf ormation .611
.......................
Warranty and Client Relations (U.S. and Canada only) . 629
........................................................................\
..........
A uthorized Manuals (U.S. only) .633INDEX
1
12/07/20 10:30:04 31TK4640_006

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.ID numbers, dimensions, capacities,
and technical information.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints. A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
Explains the purpose of each
instrument panel indicator and gauge,
the multi-information display, and
how to use the controls on the
dashboard and steering column.
This section covers several problems
motorists sometimes experience,
and details how to handle them. The Maintenance Minder shows
you when you need to take your
vehicle to the dealer for maintenance
service. There is also a list of things
to check and instructions on how to
check them. The proper way to start the engine,
shif t the transmission, and park. What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo. How to operate the climate control
system, the audio system, and other
convenience f eatures.
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls T echnical Inf ormation
Warranty and Client Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
Features
T aking Care of the Unexpected Maintenance Driving Bef ore Driving
Overview of Contents
2
TM
12/07/20 10:30:19 31TK4640_007

Î
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position or
on models with keyless access
system, press the engine start/
stop button to set ON mode (see
page ).
If the indicator stays on after the
engine starts.
If the indicator comes on or
flashesonandoff whileyoudrive.
You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display. If you see any of these indications,
the airbag system components may
not work properly when you need
them. This indicator alerts you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
When you turn the ignition switch
to the ON (II) position, the indicator
should come on brief ly and then go
out(seepage ).Ifitdoesn’tcome
on, stays on, or comes on while
driving without a passenger in the
f ront seat, have the system checked.
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-inf ormation display.67
187
CONT INUED
Additional Inf ormation About Your Airbags
How the Side
Airbag Of f
Indicator Works
not
Driver and Passenger Saf ety
33
Canada
U.S.
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
12/07/20 10:34:05 31TK4640_038

ÎÎ Î
Î
The instrument panel has many
indicators to give you important
inf ormation about your vehicle.
You will also see a ‘‘FASTEN SEAT
BELT’’ message on the multi-
inf ormation display.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display. For
more information, see page .
The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running, and you
will see a ‘‘CHECK ENGINE OIL
LEVEL’’ message on the multi-
inf ormation display. For more
inf ormation, see page .
If either of you do not f asten your
seat belt while driving, the beeper
will sound and the indicator will f lash
again at regular intervals, and you
will see a ‘‘FASTEN SEAT BELT’’ or
‘‘FASTEN PASSENGER SEAT
BELT’’ message on the multi-
inf ormation display. For more
inf ormation, see page .
This indicator comes on when you
turn the ignition switch to the ON
(II) position. It reminds you and your
passengers to f asten your seat belts.
A beeper also sounds if you have not
f astened your seat belt.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pagesand .
If you turn the ignition switch to the
ON (II) position bef ore f astening
your seat belt, the beeper sounds
and the indicator f lashes. If you do
notfastenyourseatbeltbeforethe
beeper stops, the indicator stops
f lashing but remains on. If your f ront passenger does not
f asten their seat belt, the indicator
comes on about 6 seconds af ter the
ignition switch is turned to the ON
(II) position.
20
:
184 187 597
595
Instrument Panel Indicators
Seat Belt Reminder
Indicator Malf unction Indicator
Lamp
L ow Oil Pressure
Indicator
64
12/07/20 10:37:57 31TK4640_069

Î
Î
Î
CONT INUED
This indicator has two f unctions:
Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. Driving with
the parking brake not f ully
released can damage the brakes
and tires.
If you drive without releasing the
parking brake, a beeper will sound,
and you will also see a ‘‘RELEASE
PARKING BRAKE’’ message on
the multi-information display (see
page ).
This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. It will then go of f if
you have inserted a properly coded
ignition key, on models with keyless
access system, if an appropriate
keyless access remote is used. If it is
not a properly coded key or keyless
access remote, the indicator will
blink, and the engine’s f uel system
will be disabled (see page ).
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pagesand .
If this indicator comes on when the
engine is running, the battery is not
being charged, and you will also see
a ‘‘CHECK CHARGING SYSTEM’’
message on the multi-inf ormation
display. For more inf ormation, see
page .
1.
: 212
149
184 187
596
Instrument Panel Indicators
Charging System
Indicator
Parking Brake and
Brake System
Indicator
Immobilizer System
Indicator
Inst rument s and Cont rols
65
U.S. Canada
12/08/08 20:02:27 31TK4640_070

Î
Î
If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, it can
indicate a problem in the brake
system. You will also see a ‘‘LOW
BRAKE FLUID’’ or ‘‘CHECK
BRAKE SYSTEM’’ message on
the multi-information display. For
more information, see page . Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II), and
START Mode is the equivalent
of START (III). For more
information, see pages and
.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
If this indicator comes on at any
other time, there is a problem in the
ABS. If this happens, take the
vehicle to your dealer to have it
checked. With this indicator on, your
vehicle still has normal braking
ability but no anti-lock f unction. You
will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display. For more
inf ormation, see page .
2.
:
598 187184
508
Instrument Panel Indicators
Anti-lock Brake System
(A BS) Indicator
66
12/07/20 10:38:13 31TK4640_071

Î
Î
Î
This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. If it comes on at
any other time, it indicates that the
passenger’s side airbag has
automatically shut off. For more
inf ormation, see page .
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-inf ormation display. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. If it comes on at
any other time, it indicates a
potential problem with your f ront
airbags. This indicator will also alert
you to a potential problem with your
airbag system components. You will
also see a ‘‘CHECK AIRBAG
SYSTEM’’ message on the multi-
inf ormation display. For more
inf ormation, see page . :
33
32 187
184
Supplemental Restraint
System Indicator Side A irbag Of f
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
67
U.S. Canada
12/07/20 10:38:21 31TK4640_072

ÎÎ
ÎThis indicator comes on as a
reminder that you have turned of f
the vehicle stability assist (VSA)
system.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page .
This indicator has two f unctions:
It flashes when VSA is active (see
page ).
If itcomesonandstaysonatany
other time, there is a problem with
the VSA or Hill Start Assist (on
SH-AWD models only) system.
You will also see a ‘‘CHECK VSA
SYSTEM’’ or ‘‘CHECK HILL
START ASSIST SYSTEM’’
message on the multi-inf ormation
display. Take your vehicle to a
dealer to have it checked. Without
VSA, your vehicle still has normal
driving ability, but will not have
VSA traction and stability
enhancement. For more inf ormation, see page .
If the VSA indicator illuminates,
hill start assist will not be working.
Without hill start assist, the
vehicle will roll downhill
immediately when you release the
brakeonanincline.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II), and
START Mode is the equivalent
of START (III). For more
information, see pages and .
1.
2.
:
184
187 510
510 510
Vehicle Stability Assist
(VSA ) System Indicator VSA OFF Indicator
Instrument Panel Indicators
68
12/07/20 10:38:30 31TK4640_073
