2014 Acura TL fuse box

The vehicle’s f uses are contained in
threefuseboxes.
The interior f use box is located
under the dashboard on the driver’s
side. The f use label is attached
under the steering column.The passenger’s side interior f use
box is on the lower passenger’s side
panel. To remove the f use box lid,
put your f inger in the notch on the
lid, and pull it upward slightly, then
pull it toward you and take it out of
its hinges.The under-hood f use box is on the
driver’s side next to the air cleaner
housing.
To access the under-hood f use box,
remove the lef t-side engine
compartment cover (see page ).
Toaccessthefusebox,turnthe
knob on the under cover one-quarter
turn and pull the f ront of the cover
straight down to remove it from the
dashboard. 542
Fuses
600
FUSE LABEL
NOTCH
DRIVER’S SIDE PASSENGER’S SIDE
UNDER-HOOD
AIR CLEANER HOUSING
TAB
12/07/20 11:47:24 31TK4640_605

Î
Î
If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
, and , or the diagram on
thefuseboxlidorthefuselabel,
which f use or f uses control that
component. Check those f uses f irst,
but check all the f uses bef ore
deciding that a blown f use is not the
cause. Replace any blown f uses and
check if the device works. Remove the cover f rom the f use
box.
Check each of the large f uses in
the under-hood f use box by
looking at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. VEHICLE
OFF (LOCK) Mode is the
equivalent of LOCK (0). For
more inf ormation, see pages
and .
Turn the ignition switch to the
LOCK (0) position.
Make sure the headlights and all
other accessories are of f .
3.
1.
2.
:
604 605 606
184 187
CONT INUED
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed
601
FUSEBLOWN
12/07/20 11:47:32 31TK4640_606

Look f or a blown wire inside the
f use. If it is blown, replace it with
one of the spare f uses of the same
rating or lower.
Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse boxes by
pulling out each one with the f use
pullerprovidedonthebackof the
under-hood f use box cover.
Also check the combined f use box in
the under-hood f use box.
5.
4.
Fuses
602
BLOWN
FUSE PULLER
BLOWN
12/07/20 11:47:37 31TK4640_607

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate that anything is wrong.
Replace the f use with one of the
correct rating as soon as you can.
Your vehicle has spare fuses on the
back of the under-hood f use box
cover. 6.
Fuses
T aking Care of t he Unexpect ed
603
FUSE PULLER SPARE FUSES
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
12/07/20 11:47:43 31TK4640_608

µ
µ
µ
µ
µ
µ
µ
µµ
µ
µ
µ
µ
µ
µ
µ µ
µ
µ
Î
Î
ÎÎ
Î
Î
Î
Î
Î Î
No.
Circuits Protected
No.
Amps. Amps.
Circuits Protected Circuits Protected
No. Amps.
11
12
21
22
23
24
25
26 IG Main
Sub Fan Motor
Sub Fan Motor
Driver’s Side Fuse Box
Main Fan Motor
Driver’s Side Light Main
Wiper Motor
Passenger’s Side Light Main
31
32
33
34
35
36
37
38
120 A
40 A
70 A
40 A
30 A
40 A
30 A
30 A 50 A
40 A
30 A
60 A
40 A
30 A
30 A
30 A
30 A
Battery
Passenger’s Side Fuse Box
EPS
ABS/VSA MTR
ABS/VSA
Passenger’s Side Fuse Box
Option
Headlight Washer
SH-AWD Rear Defroster
Not Used
Not Used
Not Used
Heater Motor
Hazard
Horn and Stop
Keyless Access System
Battery Sensor
IG Coil
FI Sub
Back Up
Interior Lights
FI Main
DBW
Back Up FI ECU
MG Clutch
Radiator Fan Timer
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21 40 A
40 A
15 A
20 A
7.5 A
7.5 A 15 A
15 A
10 A
7.5 A 15 A
15 A
7.5 A
7.5 A
7.5 A
If equipped Used on SH-AWD models
1:
2:
3: Used on 2WD models1
2
1
2
3
1 1
Fuse Locations
604
UNDER-HOOD FUSE BOX
12/08/08 20:03:07 31TK4640_609

µ
µ
µ
Î
ÎÎ Î
Î
No. Amps.
Circuits Protected
Amps.
No. Circuits Protected
CONT INUED
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
3210 A
10 A
7.5 A 15 A
7.5 A
7.5 A
7.5 A
7.5 A 20 A
20 A
20 A
20 A
15 A
20 A
15 A
10 A
10 A
10 A
7.5 A 15 A
7.5 A
Blind Spot Information
System
SH-AWD
Washer
Wiper
ODS
ABS/VSA
Not Used
Starter Relay
Fuel Pump
7.5 A
7.5 A
20 A
7.5 A
7.5 A
7.5 A
7.5 A 20 A
1
2
3
4
5
6
7
8
9 VB SOL
SRS
Meter
ACG
Not Used
Daytime Running Lights
A/C
Accessory, Key, Lock
Accessory
Driver’s Power Seat Sliding
Moonroof
Driver’s Power Seat Reclining
Rear Left Power Window
Front ACC Socket
Driver’s Power Window
Driver’s Side Door Lock
FrontLeftFogLight
Lef t Side Small Lights
(Exterior)
Left Headlight High Beam
TPMS
Left Headlight Low Beam
Not Used
STS
: If equipped
Fuse Locations
T aking Care of t he Unexpect ed
605
INTERIOR FUSE BOX
Driver’s side
12/07/20 11:47:59 31TK4640_610

µµ
µ
µ
µ
µ
µ
Î
Î
No. Amps. Circuits Protected Amps.
No. Circuits Protected
1
2
3
4
5
6 10 A
10 A
10 A
15 A
7.5 A Right Headlight High Beam
Right Side Small Lights
(Exterior)
Right Front Fog Light
Right Headlight Low Beam
Not Used
Interior Lights 20 A
20 A
10 A
20 A
10 A
20 A
20 A
15 A
7.5 A 20 A
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 Not Used
Passenger’s Power Seat
Reclining
Passenger’s Power Seat
Sliding
Right Side Door Lock
Rear Passenger’s Side
Power Window
Keyless Access System
Front Passenger’s Power
Window
Not Used
Premium amplifier
Console ACC Socket
Not Used
Lumbar Support
Seat Heaters
Not Used
Not Used
Not Used
: If equipped
Fuse Locations
606
INTERIOR FUSE BOX
Passenger’s side
12/07/20 11:48:05 31TK4640_611

ÎÎ Î
Î
Î
Î
Î
CONT INUED
Specif ications
Technical Inf ormation
615
Engine (2WD)
Lights
Fuses Engine (SH-AWD)3.50 x 3.66 in (89.0 x 93.0 mm)
Water cooled 4-stroke
SOHC VTEC 6-cylinder (V6), gasoline engine
212 cu-in (3,471 cm
)
11.2 : 1
Type
BorexStroke
Displacement
Compression ratio
Spark plugs
On vehicles with high voltage discharge type low beam headlights,
replacement of a bulb should be performed by your dealer.
Headlight (Low beam )
Headlight (High beam/DRL)
Front turn signal/parking
lights
Front side marker lights
Front fog lights
Rear turn signal lights
Back-up lights
Rear side marker lights
Stop/taillights
Side turn signal lights
High-mount brake light
License plate lights
Trunk light
Door courtesy lights
Vanity mirror lights
Console compartment light
Glove box Light
Foot light
35 W (D2S)
60 W (HB3)
28/8 W
3CP
55 W (H11)
21 W
16 W
3CP
3CP
5W
3.4 W
1.4 W
1.4 W
1.4 W
Interior
Under-hood See pages 606 or the fuse label
attached to the inside of the fuse
box door.
See page 604 or the fuse box
cover.DILZKR7A11G
Type
BorexStroke
Displacement
Compression ratio
Spark plugs 3.54 x 3.78 in (90.0 x 96.0 mm)
223.5 cu-in (3,664 cm
)
11.2 : 1
ILZKR7B-11S
SXU22HCR11S
Water cooled 4-stroke
SOHC VTEC 6-cylinder (V6), gasoline engine
See pages 605 or the fuse label
attached on the under panel. NGK: NGK:
DENSO:
1:
2 : Replacement of a light bulb should be done by your dealer. LED
Driver’s side
Passenger’s side
LED
LED
LED
(Amber)
(Amber)
1
2 2
2
2
