2013 VOLKSWAGEN TOUAREG Engine

x Shape of the bank.
x Objects in the water.
x Maximum fording depth of the vehicle.
Before driving through water
Stop, get out of the vehicle, and assess the situation ⇒ :
x Measure water depth from one side to the other. Check the firmness of the bed and banks; check
for drop-offs and obstacles in the water ⇒ .
x Make sure it is possible to enter and exit the water safely.
x Check the angle of the embankment and the firmness of the ground on each bank.
x Switch to off-road mode.
Driving through standing and slow-moving water
The vehicle can drive through standing water if the ground under the water is firm enough ⇒ .
Never exceed maximum fording depth.
x Drive slowly into a river in the direction of the flow. Never exceed the departure/approach angle
and lateral angle (vehicle slope).
x Always drive at a constant speed to the other side.
This will help prevent engine damage from the water. It also allows an air pocket to form in front of the
engine that can supply it with the necessary air.
Entering the water quickly or driving too fast through the water will create a bow wave. A bow wave
can force its way into the engine air intake duct and seriously damage the engine.
Driving through fast-moving water
Driving through fast-moving water is very dangerous ⇒ .
The vehicle can be swept away by the current. Even vehicles with high ground clearance can get
stuck if the ground is washed out from under the tires. Fast-moving water will build up against the side
of your vehicle. This will make the water deeper. Always think about this before entering the water.
Water volume, speed, and depth can be very unpredictable and dangerous.
If you are uncertain how fast the water is flowing, look for a shallower place where you can cross in
safety. If you cannot find a safe place to cross, turn back.
Headlight washer system instructions
Do not use the headlight washer system when driving through water. Things in the water can enter
into the openings when the washer nozzles are extended. This can prevent the washer nozzles from
retracting to their normal position. If this should happen, CARefully remove the objects.
After driving through water
x After crossing through deep water, stop the engine and check the oil dipstick. If there are beads of
water on the oil dipstick or the oil level has increased, do not start the engine. Change the engine oil
immediately. Depending on the amount of water in the oil, running or starting the engine can result in
engine failure or serious engine damage.
x Always dry the brakes by braking a couple of times.

.WARNING
Flowing water is very powerful and can sweep your vehicle away. This can lead create an
extremely dangerous situation and cause an accident with serious personal injuries.
x Never take routes or risks that could put you or your passengers in danger. If you cannot
go on or have doubts about the safety of your route, turn back and take a new route.
x Never stop in the water.
x If water gets into the engine, your vehicle can break down. You will lose control of a
broken down vehicle, and it can be swept away.
x Soft surfaces, mud, underwater obstacles, and holes can cause accidents and can cause
the vehicle to break down in the water. This can lead pose extreme danger.
x Rapidly flowing water can develop strong forces that can pull the vehicle downstream.
This can cause accidents and fatal injuries.
x Drive through water only where the banks and bottom are firm enough and the water is
shallower at all points than the maximum permissible fording depth for your vehicle ⇒ table .
.NOTICE
x Vehicle components such as the engine, drive train, suspension or electrical system may
be severely damaged by driving through water.
x Avoid stopping in deep water. This can let water get inside the vehicle.
x On soft ground, the tires dig into the surface. This reduces fording depth. Make sure that
the ground is sufficiently firm.
x Avoid creating a bow wave in front of the vehicle while driving through water. A bow wave
could force its way into the engine air intake duct and seriously damage the engine.
x If you even briefly exceed the maximum fording depth when driving through water, severe
engine damage will result. This engine damage will lead to a vehicle breakdown. This can
disable the vehicle in the water.
x Never drive over salt flats or through salt or salty water. Salt causes vehicle corrosion.
Rinse all parts of the vehicle that were exposed to salt or salt water right away with fresh
water.
Driving over snow-covered terrain
.

.WARNING
Never try to drive up or down slopes that are too steep for your vehicle. The vehicle could
slide away, tip over, or roll over.
x Never take routes or risks that could put you or your passengers in danger. If you cannot
go on or have doubts about the safety of your route, turn back and take a new route.
x The lateral angle must never be more than the maximum angle approved for the vehicle.
x Always drive along the fall line when driving up or down a slope.
x Never try to turn the vehicle around on a slope. The vehicle could tip over or roll down the
slope.
x If the engine stalls or you can no longer drive up the slope for any reason, stop and apply
the foot brake. If stalled, apply the foot brake and restart the engine. Then shift into Reverse
(R) and CARefully back your vehicle straight down the slope along the fall line. Keep the
vehicle speed slow and even.
x If the engine will not restart, apply constant pressure to the foot brake and CARefully back
straight down the slope the same way you drove up. Keep the vehicle speed slow and even.
x If the engine is running, select Reverse and CARefully back straight down the slope the
same way you drove up. Use engine braking power and the foot brake to keep the vehicle
speed slow and even.
x Never just roll down a slope with the transmission in Neutral (N). You could lose control of
the vehicle.
Driving crosswise on a slope

Fig. 283 Steer downhill along the fall line.

d Check tires, suspension struts, and axles for damage and remove coarse dirt, stones, and foreign
objects from the tire tread.
d Examine the vehicle underbody and remove objects such as twigs, leaves, or bits of wood that
have gotten stuck in the brake system, the wheels, the suspension, the exhaust system, of the
engine ⇒ . If damage or leaks are detected, see an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
d Remove coarse dirt from the radiator grille and the vehicle underbody, Exterior CARe and
cleaning.
d Check the engine compartment to for dirt that interferes with engine operation

Preparations for working in the engine compartment

.WARNING
Unintended vehicle movement during maintenance work can cause serious personal injuries.
x Never work under the vehicle unless you have safely secured the vehicle from moving. If
you must work under the vehicle with the wheels on the ground, always make sure that the
vehicle is on level ground, that all 4 wheels are chocked to keep them from moving, and that
the key is not in the ignition.
x If you must work under a vehicle raised on a floor jack, always make sure that the vehicle
is safely supported on safety stands intended for that purpose that are strong enough to
support the weight of the vehicle. The jack supplied with the vehicle is not strong enough for
this purpose and can collapse causing serious personal injury.
.WARNING
The engine compartment of any motor vehicle is a potentially dangerous area and can cause
serious personal injury.
x Always use extreme caution when doing any work in the engine compartment. Always
follow commonly accepted safety practices and use common sense. Never risk personal
injury.
x Never perform any work in the engine compartment unless you know exactly how to
CARry out the job and have the correct technical information and the correct tools.
x If you are uncertain about what to do, have the work performed by an authorized
Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified
workshop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID - High Intensity Discharge (Xenon)
lamps and HO7 bulbs replaced by a qualified technician. Serious personal injury may result
from improperly performed work.
x Never open or close the engine hood if steam or coolant is escaping. Hot steam or coolant
can cause serious burns. Always wait until you no longer see or hear steam or coolant
escaping from the engine.
x Always let the engine cool down completely before CARefully opening the hood.
x Hot parts of the engine and the exhaust system will burn skin on contact.
x When the engine has cooled down and you are ready to open the hood:
– Firmly apply the electronic parking brake and shift the transmission into Park (P).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the remote control vehicle key is out
of range of the vehicle and that the vehicle cannot be started by depressing the starter
button.
– Always keep children and others away from the engine compartment and never leave
them unsupervised.
x The engine coolant system is under pressure when the engine is hot. Never unscrew the
coolant expansion tank cap when the engine is hot. Hot coolant can spray out and cause
severe burns and other serious injuries.
– Turn the cap slowly and very CARefully in a counterclockwise direction while applying
light downward pressure on the top of the cap.
– Always protect your face, hands, and arms from hot escaping coolant or steam by
covering the cap with a large, thick rag.
x Never spill fluids on the engine or exhaust system when refilling. Spilling fluids onto hot
parts of the engine or exhaust system can cause a fire.

.WARNING
High voltage systems in the engine compartment can cause electrical shocks or even
electrocution, severe burns, other serious injuries, and even death!
x Never short-circuit the electrical system. Be especially CAReful when using jumper
cables. The vehicle's battery could explode!
x To reduce the risk of electrical shock and personal injury while the engine is running or
being started:
– Never touch ignition cables. Never touch other components of the high-voltage
electronic ignition system.
– Never touch the wiring of the HID - High Intensity Discharge (Xenon) headlights.
.WARNING
Moving parts in the engine compartment can cause serious personal injury on contact.
x Never reach into the area around or touch the radiator fan. Contact with the blades can
cause serious personal injury. Always remember that the radiator fan is temperature-
controlled and can come on suddenly even when the engine has been switched off for a while
and the key has been removed from the ignition.
x If you have to perform a check or repair when the engine is running, there are more risks
from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the
high-voltage ignition system. Always use extreme CARe.
– Always make sure that jewelry, loose clothing and long hair do not get caught in
rotating engine parts. Before starting any work remove your jewelry, take off your necktie,
tie back and cover your hair, and do not wear clothing that can hang down and get caught
in moving engine parts.
– Always use extreme caution if the accelerator pedal has to be depressed to perform a
check. The vehicle will start to move even if the parking brake is on.
x Never leave any objects in the engine compartment, for example cleaning rags and tools.
Objects left behind can cause malfunctions, engine damage, and even fires.
.WARNING
Operating fluids and some materials in the engine compartment can catch fire easily, causing
burns and other serious personal injuries!
x Do not smoke.
x Never work next to open flames or sparks.
x Never pour or spill operating fluids or other flammable liquids on the engine. These fluids
can ignite on hot engine parts and cause injuries.
x If work on the fuel system or the electrical system is necessary:
– Always disconnect the 12 Volt vehicle battery. Make sure the vehicle is unlocked when
you disconnect the battery, or the alarm will go off. Never touch the electrical wiring of the
ignition system.
– Never work near heaters, water heaters, or other open flames.
x Always have a functional, approved fire extinguisher nearby.

.NOTICE
When changing or topping off fluids, make sure that you pour the fluids into the correct
reservoirs. Adding the wrong type of operating fluids will cause serious malfunctions and
engine damage!
.Fluid leaks are harmful to the environment. Regularly check the ground underneath your vehicle
for this reason. If you find spots of oil or other fluids, have your vehicle checked by your authorized
Volkswagen dealer or authorized Volkswagen Service Facility. Dispose of leaked operating fluids
properly.
