2013 VOLKSWAGEN TOUAREG ESP

Files, folders and playlists on a data medium are sorted by name in alphanumerical order.
The illustration shows a typical audio data CD that contains tracks b, folders a and sub folders
⇒ fig. 147.
The tracks are played back as follows:
1. Tracks (1) and (2) in the CD's root directory
2. Track (3) and (4) in the first directory F1 in the root directory of the CD.
3. Track (5) in the first subdirectory F1.1 of the directory F1
4. Track (6) in the first subdirectory F1.1.1 of the subdirectory F1.1
5. Track (7) in the second subdirectory F1.2 of the directory F1
6. Track (8) and (9) in the second directory F2
Play lists ´ are treated like directories in the playback sequence.
.WARNING
Driving on today’s roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
.Compressed video files (Podcasts, AVI) on a data medium are treated like audio files when
played back.
.Play lists are not automatically played, they must be specifically selected via the menu for track
selection.
Playback of video files in the Audio menu
.

x Press the Deletefunction key to delete all selected entries.
x Accept the confirmation dialog by pressing the Deletefunction key.
The delete process may take some time, depending on the number of files being deleted.
.For copyright reasons, all files stored in the media library need to be deleted before the unit is
passed on.
.Using the voice control, you can also record the name of an artist, album or track stored in the
media center after the corresponding voice command
External audio source connected via AUX-IN

.WARNING
Driving on today’s roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
Requirements and information

Fig. 154 MEDIA-IN multimedia jack.

Opening the DVD film menu manually
The DVD film menu must be opened manually if the DVD film menu does not open automatically with
the unit's own menu control, or if the video DVD is already being played.
x In the video DVD menu, press the Menufunction key to open the unit's own menu control .
x If an introduction is playing, it can be skipped by pressing the Menufunction key in the unit's own
menu control ⇒ fig. 157 (B).
The DVD film menu is displayed (A).
DVD does not start!
Note that an inserted DVD cannot start automatically if the volume is set to “0” (display: +). A played
media source is always stopped (paused) in this case.
.The visual appearance of the DVD film menus and the menu options which it offers are the
responsibility of the DVD manufacturer.
.The language of a video DVD for voice output can be changed .
.The DVD manufacturer is responsible for the different ways in which individual films respond to
identical commands.
Video DVD menu: controlling playback and changing display settings

Fig. 158 Video DVD menu.
.

Correct spelling of entries is important. In the same way as when selecting a destination address, it is
only possible to make entries that correspond with a point of interest stored in the navigation data.
In some lists, the Options interface can be used to put special objects into alphabetical order, according
to trade names or categories.
Selecting special and favorite destinations from the map
.

Function key: Effect
Create new telephone numbers: Opens an input window where you can enter a telephone number
manually.
Create business navigation destination: Opens a menu where you can select a navigation destination for
the “Business P”favorites category or convert a stored mailing address into a navigation
destination .
Create business mailing address: Opens a menu to enter a mailing address manually in input windows.
Create business mailing address: Opens a menu where you can select a navigation destination for the
“Private T” favorites category or convert a stored mailing address into a navigation destination .
Create private mailing address: Opens a menu to enter a mailing address manually in input windows.
Read contact: The voice command stored under Last name and First name is read out .
= Private contact: The directory entry is only displayed when the corresponding user profile is loaded.
If the check box = is cleared, the directory entry is transferred to the general user profile and is
always displayed .

If the prefix Create ... is not displayed in a function key, corresponding information is already stored.
This information is displayed below the function key (such as in .: Business navigation destination).
Press the function key to display or modify the stored information ⇒ fig. 186.
Converting mailing addresses into navigation destinations
Information that is stored as Business mailing address or Private mailing address can be converted into
navigation destinations, such as the telephone directory entries of a connected cell phone.
x Press the Create private navigation destination or Create business navigation destination
.button.
x Press the Create navigation destination function key.
The mailing address is converted into a navigation destination in the Infotainment System and
displayed in the Address entry menu where it can be edited further .
x Touch the OKfunction key.
The mailing address is now stored as a navigation destination. The navigation destination is displayed
and can be edited again.
x Press the Efunction key to close the menu.

x Press the NAV Infotainment button or the ... ...function key to switch to the Navigation main
menu.
x In the Navigation main menu, press the NAV Infotainment button or MAP function key to switch
back to the map view.
The map is displayed in the most recently selected type (2D or 3D). 3D and “Autozoom” are activated
by default .
Alternative routes: Selecting a calculated route
In the Navigation settings menu, you can specify that 3 alternative routes are suggested on the
map after the start of route guidance. These 3 routes correspond to the available route criteria Fast,
Short and Economical route Route 1 corresponds to the current setting in this case.
x Select the required route by pressing on the right of the map.
The setting for the route criteria in the Route options menu is changed accordingly.
If no route is selected then route guidance starts automatically after about one minute, using the
setting selected in the Route options.
Interrupting route guidance
Active route guidance can be stopped and later resumed from the new vehicle position at any time in
the Navigation main menu.
x In the Navigation main menu, press the Stop function key ⇒ fig. 209.
x Press the Start function key to continue route guidance ⇒ fig. 206.
Provision of navigation recommendations

Fig. 210 3D map display during route guidance.

Function key: Effect
Complete : Detailed driving recommendations with lane recommendation and additional
information.
Compact : Some additional navigation recommendations and information are left out.
Off : no spoken navigation recommendations.
Time display : Display  during route guidance.
Arrival time : the estimated time of arrival at the destination is displayed.
Driving time : the estimated driving time until reaching the destination is displayed.
Instrument cluster guidance : Visual navigation recommendations for guidance in the instrument
cluster .
Arrow view : Travel direction arrows show the direction of travel and the distance to the next
turn-off point.
Street view : Road and route view corresponding with the map display in the Infotainment
System.
= Voice guidance during phone call: Spoken navigation recommendations are also given during a
telephone call.
Advanced navigation settings : Allows settings for demo mode.
SIRIUS traffic ID : The Sirius traffic ID and the Internet address and the telephone number of the
Sirius activation hotline are displayed in the pop-up window .

Advanced navigation settings: Demo mode and manual location
x In the Advanced navigation settings menu, check the check box in the Demo mode
function key by pressing it ] to start virtual route guidance to the entered destination.
x Press the Enter current position manually function key to select a manual location in the same way
you entered a destination .
If demo mode is enabled , an additional pop-up window opens when you start route guidance.
x Pressing the Demo mode function key starts a “virtual route guidance” to the destination you have
entered.
x If you press the Normal mode function key, a “real route guidance” starts.
The sequence of events and the operations in virtual route guidance are similar to those in real route
guidance. Once a manual location has been entered, the virtual route guidance starts from that
position.
Virtual route guidance is repeated when you reach the fictitious destination and always starts again
from the starting point if it is interrupted.
When real route guidance is started following route guidance in demo mode, the unit first has to
reorient itself. Depending on the number of currently received satellites, this orientation may take
some time. Vehicle movement can reduce the re-orientation time
.If the vehicle is moved and the unit can determine its current location by GPS, any manually
entered location will be overwritten with the current vehicle location.
.Disable demo mode after use, otherwise you will be prompted to choose between virtual and
normal route guidance each time you start route guidance.
