2013 TOYOTA LAND CRUISER display

632 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
■Warning message in vehicle-to-vehicle distance control mode of the
dynamic radar cruise control (if equipped)
In the following cases, the warning message may not be displayed even if
vehicle-to-vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same
speed or the vehicle ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed
■Resetting the tire pressure warning data
After adjusting the tire inflation pressure, be sure to initialize the data.
(P. 545)
If the message remains on, the system may have malfunctioned. Have the
vehicle inspected by your Toyota dealer as soon as possible.

692
LC200_OM_OM60F57U_(U)
6-2. Customization
Customizable features
Customizing vehicle features using the touch screen (vehicles
with navigation system)
Press “SETUP”.
Touch “Vehicle” on the “Setup” screen.
Touch “Vehicle Customization”.
Touch the setting to be changed.
Change each setting and touch
“Save”.
If “Save” is not touched before
switching to another screen, any
changes will be lost.
A message indicating that the settings are being saved will
appear.
Do not perform any other operations while this message is
displayed.
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences.
Programming of these preferences can be performed by your Toyota
dealer.
For vehicles with the navigation system, it is also possible to cus-
tomize certain vehicle features yourself using the touch screen.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.
STEP1
STEP2
STEP3
STEP4
STEP5

698 6-2. Customization
LC200_OM_OM60F57U_(U)
Automatic
light control
system
(P. 196)Light sensor sen-
sitivityStandard -2 to 2 O — O
Daytime running
light systemOn Off O — O
Time elapsed
before head-
lights automati-
cally turn off after
doors are closed30 secondsOff
O—O 60 seconds
90 seconds
Intuitive
parking
assist
(P. 229)Detection dis-
tance of the rear
center sensorFar Near O — O
Alert Volume
(alert volume can
be adjusted)3 1 to 5 O — O
Display setting
(when intuitive
parking assist is
operating)All sensors
displayedDisplay off O — O
Automatic
air
conditioning
system
(P. 336)A/C Auto switch
operationAuto Manual O — O
Eco Driving
Indicator
Light
(P. 156)Eco Driving
Indicator LightOn Off — O O
ItemFunctionDefault
settingCustomized
setting

699 6-2. Customization
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
*1: The settings can be changed when the mechanical key linked operation of
the power window is set to ON.
*2: The settings can be changed when the wireless remote control linked oper-
ation of the power window is set to ON.
*3: The settings can be changed when the entry function linked operation of the
power window is set to ON.
■Vehicle customization
●If the smart key system is turned “OFF”, unlock door cannot be selected.
●If the doors are not opened after unlocking and are then automatically re-
locked, a signal will be given if “Operation signal (Emergency flashers)”
or “Operation signal (Buzzer)” are set to ON.
■When setting using the vehicle switches (vehicles with navigation sys-
tem)
When using the vehicle switches to set an item that can also be set using the
touch screen, the item displayed on the touch screen will not change imme-
diately.
If the “ENGINE START STOP” switch is first turned to OFF, the screen dis-
play will change once the “ENGINE START STOP” switch is turned to IGNI-
TION ON mode again.
■When customizing using the touch screen (vehicles with navigation
system)
Stop the vehicle in a safe place, apply the parking brake, and shift the shift
lever to “P”. Also, to prevent battery discharge, leave the engine running
while customizing the features.

700 6-2. Customization
LC200_OM_OM60F57U_(U)
Multi-information display (P. 189)
CAUTION
■During customization
As the engine needs to be running during customization, ensure that the
vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may
collect and enter the vehicle. This may lead to death or a serious health haz-
ard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while cus-
tomizing features.
Available languagesEnglish (U.S.A.), Spanish

706
LC200_OM_OM60F57U_(U)
Abbreviation list
Abbreviation/Acronym list
ABBREVIATIONSMEANING
4WD Four Wheel Drive
A/C Air conditioning
ABS Anti-lock Brake System
AI-SHIFT Artificial Intelligence Shift control
ALR Automatic Locking Retractor
AUX Auxiliary
CRS Child Restraint System
DISP Display
ECT Electronic Controlled Transmission
EDR Event Data Recorder
ELR Emergency Locking Retractor
GAWR Gross Axle Weight Rating
GCWR Gross Combination Weight Rating
GPS Global Positioning System
GVWR Gross Vehicle Weight Rating
I/M Emission inspection and maintenance
INT Intermittent
KDSS Kinetic Dynamic Suspension System
LATCH Lower Anchors and Tethers for Children
LED Light Emitting Diode
MMT Methylcy clopentadienyl Manganese Tricarbonyl

710 Alphabetical index
LC200_OM_OM60F57U_(U)
Child safety
Airbag precautions ................122
Battery precautions ....... 541, 565
Child-protectors ....................... 47
Child restraint system............135
How your child should wear
the seat belt ..........................81
Installing child restraints ........ 140
Moon roof precautions .......... 100
Power window lock switch....... 93
Power window precautions .....96
Removed key battery
precautions .........................563
Seat belt extender
precautions ...........................84
Seat belt precautions ..............82
Seat heater precautions ........ 490
Cigarette lighter ....................... 484
Cleaning
Exterior .................................. 512
Interior ...................................515
Seat belts ..............................516
Clock (vehicles without
navigation system). ............... 479
Clock (vehicles with
navigation system)
*
Condenser ................................535
Console box ............................. 468
Cool box.................................... 475
Cooling system
Engine overheating ............... 658
Crawl Control ...........................245
Cruise control...........................210
Cup holder ................................470
Curtain shield airbags ............. 113
Customizable features............. 692Daytime running light
system .................................... 199
Defogger
Rear window ......................... 351
Side mirror ............................ 351
Dimension ................................ 666
Dinghy towing .......................... 333
Display
Crawl Control display ............ 245
Dynamic radar cruise
control ................................. 214
Intuitive parking assist
display ................................ 229
Multi-information display ....... 189
Shift position and shift
range .................................. 173
Trip information ..................... 190
Warning messages ............... 617
Do-it-yourself maintenance .... 524
Door courtesy lights
Door courtesy lights .............. 462
Wattage................................. 675
Door lock
Back door ................................ 51
Side door................................. 46
Wireless remote control key.... 44
Doors
Back door ................................ 51
Side door................................. 46
Side mirrors............................. 90
Driver’s seat belt reminder
light ......................................... 609
Driving
Break-in tips .......................... 155
Correct posture ..................... 111
Off-road precautions ............. 297
Procedures............................ 154
Winter driving tips ................. 310
Driving position memory .......... 68
Dynamic radar cruise
control .................................... 214
D

711 Alphabetical index
LC200_OM_OM60F57U_(U)
Eco driving............................... 156
Electronic key
If your electronic key
battery is discharged .. 563, 651
Emergency flashers
Switch ................................... 598
Emergency, in case of
If a warning message is
displayed ............................ 617
If the electronic key does
not operate properly ........... 651
If the engine will not start...... 647
If the shift lever cannot be
shifted from “P” .................. 649
If the vehicle has discharged
battery ............................... 654
If the warning buzzer
sounds ............................... 606
If the warning light turns on .. 606
If you have a flat tire ............ 633
If you lose your keys............. 650
If you think something is
wrong ................................. 604
If your vehicle becomes
stuck................................... 661
If your vehicle has to be
stopped in an emergency... 663
If your vehicle needs to be
towed ................................. 599
If your vehicle overheats ...... 658
Engine
Compartment........................ 528
Engine switch ....................... 166
Hood ..................................... 527
How to start the engine ........ 166
Identification number ............ 667
If the engine will not start...... 647
Ignition switch ....................... 166
Overheating .......................... 658Engine coolant
Capacity ................................670
Checking ...............................534
Preparing and checking
before winter .......................310
Engine coolant temperature
gauge ......................................179
Engine immobilizer system.....105
Engine oil
Capacity ................................669
Checking ...............................530
Preparing and checking
before winter .......................310
Engine switch ...........................166
Event data recorder ...................25
First-aid kit holder....................495
Floor mats.................................493
Fluid
Brake .....................................536
Power steering ......................538
Washer ..................................542
Fog lights
Replacing light bulbs .............581
Switch....................................201
Wattage .................................675
Four-wheel drive system .........240
Front fog lights
Replacing light bulbs .............581
Switch....................................201
Wattage .................................675
Front passenger’s seat belt
reminder light.........................609
Front seats
Adjustment ..............................57
Driving position memory..........68
Front side marker light
Replacing light bulbs .............581
Wattage .................................675E
F
*: For vehicles with a navigation system,
refer to the “Navigation System Owner’s Manual”.
