Page 97 of 628
961-3. Theft deterrent system
IS300h_EE(OM53B95E)
The alarm uses light and sound to give an alert when an intrusion is
detected.
The alarm is triggered in the following situations when the alarm is set:
A locked door or trunk is unlocked or opened in any way other than
using the entry function or wireless remote control. (The door will lock
again automatically.)
The hood is opened.
The intrusion sensor detects something moving inside the vehicle. (An
intruder gets in the vehicle.) (if equipped)
The tilt sensor detects a change of vehicle inclination. (if equipped)
Close the doors, trunk and hood,
and lock all the doors using the
entry function or wireless remote
control. The system will be set auto-
matically after 30 seconds.
The indicator light changes from
being on to flashing when the system
is set.
Alarm
: If equipped
The alarm
Setting the alarm system
Page 98 of 628
971-3. Theft deterrent system
1
For safety and security
IS300h_EE(OM53B95E)
Do one of the following to deactivate or stop the alarm:
Unlock the doors or open the trunk using the entry function or wireless
remote control.
Start the hybrid system. (The alarm will be deactivated or stopped after
a few seconds.)
System maintenance
The vehicle has a maintenance-free type alarm system.
Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the
following:
Nobody is in the vehicle.
The windows and moon roof (if equipped) are closed before the alarm is set.
No valuables or other personal items are left in the vehicle.
Deactivating or stopping the alarm
Page 99 of 628
981-3. Theft deterrent system
IS300h_EE(OM53B95E)
Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
Alarm-operated door lock
In the following situations, the doors are locked automatically to prevent intrud-
ers:
The doors are unlocked manually without the mechanical key and the alarm is
triggered.
While the alarm is operating, the doors are unlocked manually without the
mechanical key.
The doors or trunk are unlocked using the
mechanical key.
A person inside the vehicle opens a door,
the trunk or hood, or unlocks the vehicle
using a inside lock button.
The 12-volt battery is recharged or
replaced when the vehicle is locked. (P.
552)
NOTICE
To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper oper-
ation of the system cannot be guaranteed.
Page 100 of 628

991-3. Theft deterrent system
1
For safety and security
IS300h_EE(OM53B95E)
The intrusion sensor detects intruders or movement in the vehicle.
The tilt sensor detects changes in vehicle inclination, such as when the
vehicle is towed away.
This system is designed to deter and prevent vehicle theft but does not
guarantee absolute security against all intrusions.
Setting the intrusion sensor and tilt sensor
The intrusion sensor and tilt sensor will be set automatically when the
alarm is set. (P. 9 6 )
Canceling the intrusion sensor and tilt sensor
If you are leaving pets or other moving things inside the vehicle, make
sure to disable the intrusion sensor and tilt sensor before setting the
alarm, as they will respond to movement inside the vehicle.
Turn the power switch off.
Press the intrusion sensor and
tilt sensor cancel switch.
Press the switch again to re-
enable the intrusion sensor and
tilt sensor.
Each time the intrusion sensor is
canceled/set, a message will be
shown on the multi-information
display in the instrument cluster.
Intrusion sensor and tilt sensor (if equipped)
1
2
Page 101 of 628

1001-3. Theft deterrent system
IS300h_EE(OM53B95E)
Canceling and automatic re-enabling of the intrusion sensor and tilt sensor
The alarm will still be set even when the intrusion sensor and tilt sensor are can-
celed.
After the intrusion sensor and tilt sensor are canceled, pressing the power
switch or unlocking the doors using the entry function or wireless remote con-
trol will re-enable the intrusion sensor and tilt sensor.
The intrusion sensor and tilt sensor will automatically be re-enabled when the
alarm system is deactivated.
Intrusion sensor detection considerations
The sensor may trigger the alarm in the following situations:
Places with extreme vibrations or noises, or situations in which the vehicle is
subject to repeated impacts or vibrations:
• When parked in a parking garage
• When the vehicle is transported on a ferry, trailer, train, etc.
• When ice adhering to the vehicle is removed
• When the vehicle is in an automatic or high-pressure car wash
• When in a hail or lightning storm
A window or the moon roof is open.
In this case, the sensor may detect the fol-
lowing:
• Wind or the movement of objects such
as leaves and insects inside the vehicle
• Ultrasonic waves emitted from devices
such as the intrusion sensors of other
vehicles
• The movement of people outside the
vehicle
Unstable items, such as dangling accesso-
ries or clothes hanging on the coat hooks,
are in the vehicle.
Page 102 of 628
1011-3. Theft deterrent system
1
For safety and security
IS300h_EE(OM53B95E)
Tilt sensor detection considerations (if equipped)
The sensor may trigger the alarm in the following situations:
The vehicle is transported by a ferry, trailer, train, etc.
The vehicle is parked in a parking garage.
The vehicle is inside a car wash that moves the vehicle.
Any of the tires loses air pressure.
The vehicle is jacked up.
An earthquake occurs or the road caves in.
NOTICE
To ensure the intrusion sensor function correctly
Installing accessories other than genuine Lexus parts or leaving objects
between the driver’s seat and front passenger’s seat may reduce the detection
performance.
To ensure that the sensors operate prop-
erly, do not touch or cover them.
Do not spray air fresheners or other prod-
ucts directly into the sensor holes.
Page 103 of 628
1021-3. Theft deterrent system
IS300h_EE(OM53B95E)
