locking the doors .................................. (up to the end of the DU)
emergency key ..................................... (up to the end of the DU)
child safety ............................................................. (current page)
children (safety) ..................................................... (current page)
RENAULT card use .................................................. (up to the end of the DU)
1.2
ENG_UD19761_2
Cartes RENAULT : généralités (X91 - D91 - Renault)
ENG_NU_939-3_D91_Renault_1
Jaune NoirNoir texte
RENAULT cards: General information, use, deadlocking
RENAULT cARds: general information (1/2)
1 Unlocking the doors and tailgate.
2 Locking all doors and tailgate.
3 Switching on the lighting remotely.
4 Unlocking/locking the tailgate
5 Integrated key.
special note
The RENAULT “SERVICE” card, for ve-
hicles equipped with it, can be identi -
fied by the word “SERVICE” engraved
on the card. Refer to the information
on the “RENAULT “SERVICE” card” in
Section 1.
The RENAULT card is used
for:
– locking/unlocking the opening ele -
ments (doors and luggage compart-
ment) and the fuel filler flap (refer to
the following pages);
– depending on the vehicle, for remote
automatic closing of the electric win-
dows, refer to “One touch window:
remote closing of the windows” in
Section 3;
– switching on the vehicle lighting re -
motely (refer to the following pages);
– starting the engine; refer to the in -
formation on “Starting the engine” in
Section 2.
Battery lifeMake sure that the correct battery type
is being used, and that the battery is in
good condition and inserted correctly.
Its service life is approximately two
years: replace it when the message
“Low card battery” appears on the in -
strument panel (refer to the informa -
tion on the “RENAULT card: Battery” in
Section 5).driver’s responsibility
Never leave your vehicle
with the Renault card inside
and never leave a child
(or a pet) unsupervised, even for a
short while.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or by locking the
doors.
Risk of serious injury.
4
5
1
2
RENAULT card operating
range
This varies according to the surround -
ings. It is important to make sure when
handling the RENAULT card that you
do not lock or unlock the doors by inad -
vertently pressing the buttons.
3
When the battery is flat, you can
still lock/unlock and start your ve -
hicle. Refer to the information on
“Locking/unlocking the doors” in
Section 1 and “Starting the engine”
in Section 2.

child safety............................................................. (current page)
children (safety) ..................................................... (current page)
1.6
ENG_UD29085_5
Carte RENAULT mains libres : utilisation (X91 - D91 - Renault)
ENG_NU_939-3_D91_Renault_1
Jaune NoirNoir texte
“HANds-fREE” RENAULT cARd: use (2/3)
Locking the vehicle
There are three ways to lock the vehi-
cle: remotely, using button 4 , or using
the RENAULT card.
Remote locking
With the RENAULT card on you, and
doors and tailgate closed, move away
from the vehicle: it will lock automati -
cally once you have left one of the
zones 1.
Note: the distance at which the vehicle
locks depends on the surroundings. The hazard warning lights
flash twice
and a beep sounds to indicate that the
doors have locked.
This beep can be changed or switched
off. Consult an approved dealer.
If a door or the tailgate is open or not
properly shut, or a card is in the passen-
ger compartment (or the card reader)
the vehicle will not lock. In this situa -
tion, no beep sounds and the hazard
warning lights do not flash.
24
Locking using button 4
With the doors and tailgate closed,
press button 4 on the driver ’s door
handle. The vehicle will lock. If a door
or the tailgate is open or not closed
properly, the vehicle will quickly lock/
unlock.
Note: the RENAULT card must be
within one of the vehicle's access
zones 1 to be able to use the button for
locking.
special note
If you wish to check that the doors are
locked after locking using button 4, you
have approximately three seconds to
try the door handles without unlocking
them.
After this time, the “hands-free” mode
is activated once again and any move-
ment of a handle will unlock the vehicle.
1
11
If the vehicle is fitted with remote window closing, locking the doors using button 4
also causes all the windows to close (please see the information on “Electric win-
dows; Electric sunroof” in Section 3).

central door locking .............................. (up to the end of the DU)
doors/tailgate ........................................ (up to the end of the DU)
locking the doors .................................. (up to the end of the DU)
RENAULT card use .................................................. (up to the end of the DU)
deadlocking the doors ........................................... (current page)
1.8
ENG_UD9819_2
Cartes RENAULT : super-condamnation (X91 - D91 - Renault)
ENG_NU_939-3_D91_Renault_1
To deactivate deadlocking
Unlock the vehicle using button 1 on
the RENAULT card.
The hazard warning lights flash once to
indicate that the doors have been un -
locked.
Never use deadlocking if
someone is still inside the
vehicle.
To activate deadlocking
You can choose between two deadlock -
ing activation modes:
– press button 2 twice in quick succes-
sion;
– or, press the button on the driver’s
door handle 3 twice in quick succes-
sion.
The hazard warning lights flash five
times to indicate locking.
If the vehicle is equipped with a dead
-
locking function, this allows you to lock
the opening elements and to prevent
the doors from being unlocked using
the interior handles (for example, by
breaking the window and then trying to
open the door from the inside).
RENAULT cARd: deadlocking
2
On equipped vehicles, activating
deadlocking also activates remote
electric window closing.
After activating the deadlocking
function using button 2 , remote
locking and unlocking in hands-free
mode are deactivated.
To reactivate the “hands-free” mode:
restart the vehicle.
3
1

warning buzzer ...................................................... (current page)
doors ..................................................... (up to the end of the DU)
locking the doors .................................. (up to the end of the DU)
opening the doors .................................................. (current page)
1.10
ENG_UD22175_6
Ouverture et fermeture des portes (X91 - D91 - Renault)
ENG_NU_939-3_D91_Renault_1
Jaune NoirNoir texte
door/tailgate open buzzerIf a door (or tailgate) is open or not
properly closed, as soon as the vehi -
cle reaches a speed of approximately
6 mph (10 km/h), the message “tailgate
open” or “door open” (depending on
which is open) will appear on the instru-
ment panel accompanied by a warning
light.
Lights-on reminder buzzerIf you have switched off the ignition
and left the lights switched on, a warn-
ing buzzer will sound when a door is
opened.
Doors
OpENINg ANd cLOsINg THE dOORs (1/2)
Opening the doors from the
outside
With the doors unlocked or the hands -
free RENAULT card on you, pull
handle 1.
In some cases, it may be necessary to
pull the handle twice to open the door.
Opening from the insidePull on the handle 2.
Note: the lights and accessories (radio
etc.) continue to work after the engine
is switched off. They stop as soon as
the driver’s door is opened.
1
2
Every time one of the doors is opened, the window lowers by a few centimetres
to facilitate door movement. The window closes as soon as the door is closed.
If there is any ice or snow preventing the window from lowering when one of the
doors is opened, this ice or snow must be removed to free the window before the
door is closed.
If you need to disconnect the battery (breakdown etc.), lower the windows to
make handling the doors easier whilst the battery is disconnected.
If you pull the handle 1 with-
out opening the door, the
window lowers by a few
centimetres then closes
after approximately 20 seconds.
Do not place your fingers over the
window.
Risk of injury.

closing the doors ................................................... (current page)
child safety ............................................................. (current page)
JauneNoirNoir texte
1.11
ENG_UD22175_6
Ouverture et fermeture des portes (X91 - D91 - Renault)
ENG_NU_939-3_D91_Renault_1
In the event of a fault with the
electric windows
The window does not lower when the
door is opened and does not close
when the door is closed. In this case,
pull the electric window button in ques-
tion six times in succession to close
the window completely.
To close the door, proceed as described
in the section entitled “In the event of a
battery fault”.
card reminder buzzer
A beep will let you know if you have left
the card in the reader when you open
the driver ’s door, and the “Remove
card” message will appear on the in -
strument panel.
OpENINg ANd cLOsINg THE dOORs (2/2)
Do not close the door by
holding the window.
Make sure you do not place
your fingers too high up in
zone 4.
Risk of injury.
43
Operating faults
In the event of a battery fault:
– to open the door: pull handle 5 then
gently open the door to avoid dam -
aging seal 3;
– to close the door : push the top of
the window (zone 4 ) whilst holding
the door using handle 5 to enable it
to pass under seal 3, then close the
door without slamming it.
5
Door locking is accompa -
nied by the windows clos -
ing.
Risk of serious injury.
As a safety precaution,
the doors should only be
opened or closed when the
vehicle is stationary.
driver’s responsibility when parking or stopping the vehicle
Never leave an animal, child or adult who is not self-sufficient alone on
your vehicle, even for a short time.
They may pose a risk to themselves or to others by starting the engine,
activating equipment such as the electric windows or by locking the door\
s.
Also, in hot and/or sunny weather, please remember that the temperature inside
the passenger compartment increases very quickly.
RIsK Of dEATH OR sERIOUs INJURY.

air bag................................................... (up to the end of the DU)
additional methods of restraint side protection ................................ (up to the end of the DU)
methods of restraint in addition to the seat belts
(up to the end of the DU)
seat belts .............................................. (up to the end of the DU)
air bag ................................................... (up to the end of the DU)
side protection devices ......................... (up to the end of the DU)
1.28
ENG_UD17009_2
Dispositifs de protection latérale (D91 - X95 - B95 - D95 - Renault)\
ENG_NU_939-3_D91_Renault_1
side protection
sIdE pROTEcTION dEvIcEs
Warnings concerning the side air bag
– f itting seat covers: seats equipped with an air bag require covers
specifically designed for your vehicle. Contact an approved Dealer to find
out if these covers are available. The use of any covers other than those
designed for your vehicle (and including those designed for another vehicle)
may affect the operation of the air bags and reduce your protection.
– Do not place any accessories, objects or even pets between the seatback, the
door and the internal fittings. Do not cover the seatback with any items such as
clothes or accessories. This may prevent the air bag from operating correctly
or cause injury when the air bag is deployed.
– No work or modification whatsoever may be carried out on the seat or internal
fittings, except by qualified personnel from an approved dealer.
– The area between the rear bench seatback and the trim is the area of air bag
operation: no objects must be placed here.
side air bags
These air bags are fitted to the front
seats and are activated at the sides of
the seats (door side) to protect the oc-
cupants in the event of a severe side
impact.
curtain air bags
These are air bags fitted along the sides
of the vehicle in the ceiling which trigger
along the front and rear side windows
to protect the passengers in case of a
severe side impact.

child safety............................................ (up to the end of the DU)
child restraint/seat ................................ (up to the end of the DU)
child restraint/seat ................................ (up to the end of the DU)
child restraint/seat ................................ (up to the end of the DU)
child seats ............................................. (up to the end of the DU)
transporting children ............................. (up to the end of the DU)
children ................................................. (up to the end of the DU)
1.30
ENG_UD20057_3
Sécurité enfants : généralités (X91 - D91 - X95 - E95 - \
Renault)
ENG_NU_939-3_D91_Renault_1
Jaune NoirNoir texte
Child safety: general information
cHILd sAfETY : general information (1/2)
carrying children
Children, and adults, must be correctly
seated and strapped in for all journeys.
The children being carried in your vehi-
cle are your responsibility.
A child is not a miniature adult. Children
are at risk of specific injuries as their
muscles and bones have not yet fin -
ished growing. The seat belt alone
would not provide suitable protection.
Use an approved child seat and ensure
you use it correctly.
driver’s responsibility
when parking or stopping
the vehicle
Never leave an animal,
child or adult who is not self-suffi -
cient alone on your vehicle, even for
a short time.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or locking the
doors.
Also, in hot and/or sunny weather,
please remember that the tempera-
ture inside the passenger compart-
ment increases very quickly.
RI sK O f d EATH OR sERIOU s
INJURY.
A collision at 30 mph
(50 km/h) is the same as fall-
ing a distance of 10 metres.
Transporting a child without
a restraint is the equivalent of allow-
ing him or her to play on a fourth -
floor balcony without railings.
Never travel with a child held in your
arms. In the event of an accident,
you will not be able to keep hold of
the child, even if you yourself are
wearing a seat belt.
If your vehicle has been involved in
a road accident, replace the child
seat and have the seat belts and
ISOFIX anchorage points checked.

towing rings .......................................... (up to the end of the DU)
Isofix ..................................................... (up to the end of the DU)
JauneNoirNoir texte
1.31
ENG_UD20057_3
Sécurité enfants : généralités (X91 - D91 - X95 - E95 - \
Renault)
ENG_NU_939-3_D91_Renault_1
cHILd sAfETY : general information (2/2)
Using a child seat
The level of protection offered by the
child seat depends on its ability to re -
strain your child and on its installation.
Incorrect installation compromises the
protection it offers the child in the event
of harsh braking or an impact.
Before purchasing a child seat, check
that it complies with the regulations for
the country you are in and that it can
be fitted in your vehicle. Consult an ap-
proved dealer to find out which seats
are recommended for your vehicle.
Before fitting a child seat, read the
manual and respect its instructions. If
you experience any difficulties during
installation, contact the manufacturer
of the equipment. Keep the instructions
with the seat.
Never leave a child unat -
tended in the vehicle.
Check that your child is
always strapped in and that
the belt or safety harness used is
correctly set and adjusted. Avoid
wearing bulky clothing which could
cause the belts to slacken.
Never let your child put their head or
arms out of the window.
Check that the child is in the correct
position for the entire journey, espe-
cially if asleep.
Set a good example by always fas-
tening your seat belt and teaching
your child:
– to strap themselves in correctly.
– to always get in and out of the car
at the kerb, away from busy traf-
fic.
Do not use a second-hand child
seat or one without an instruction
manual.
Check that there are no objects in
the vicinity of the child seat which
could impede its operation.
