2012 NISSAN LEAF Owners Manual

Pulling up the wiper arm
The wiper arm should be in the up position when
replacing the wiper.
Pull up the wiper arm manually or using the
wiper rise-up function.

Replacing
1. Push the release tab*A, and move the
wiper blade down the wiper arm
*1while
pushing the release tab to remove.
2. Insert the new wiper blade onto the wiper arm until a click sounds.
3. Rotate the wiper blade so that the dimple is in the groove.

Fusible links
If any electrical equipment does not operate and
the fuses are in good condition, check the
fusible links in the holders
*1,*2and*3. If any
of these fusible links are melted, replace only
with genuine NISSAN parts.
For checking and replacing the fusible links in
the holders
*1,*2and*3, contact a NISSAN
certified LEAF dealer.

5. If the fuse is open*A, replace it with a new
fuse
*B.
6. If a new fuse also opens, have the electrical system checked, and if necessary repaired,
by a NISSAN certified LEAF dealer.
