Page 12 of 1062

NISSAN LEAF 2012 Owners Manual high enough to cause severe or
possibly fatal injuries to people or
animals.
NOTE:
. To check the Li-ion battery charging
status using an internet enabled smart
phone or personal computer.
—The vehi

high enough to cause severe or
possibly fatal injuries to people or
animals.
NOTE:
. To check the Li-ion battery charging
status using an internet enabled smart
phone or personal computer.
—The vehicle must be located in a
cellular phone coverage area.
— The cellular phone must be located
in an area with cellular phone
coverage.
— The computer must be connected to
the internet.
. Some cellular phones are not compa-
tible with this system and cannot be
used to check the Li-ion battery char-
ging status. Confirm this beforehand.
Operating tips
.When the charge connector is connected,
the climate control operates using electric
power. When the charge connector is
disconnected from the vehicle, the climate
control operates using vehicle battery elec-
tric power. .
The climate control can be operated for a
maximum of 2 hours when the charge
connector is connected to the vehicle, or a
maximum of 15 minutes when the charge
connector is disconnected.
. The remote climate control will only start to
operate when the power switch is in the
OFF position. Be sure to check that the
power switch is in the OFF position.
. Remote climate control operation is not
available when the vehicle is in an area of
cellular communication range.
. Communication becomes unavailable when
the vehicle is not used for two weeks or
more. When the power switch is placed in
the ON position, communication with the
NISSAN CARWINGS Data Center can be
restored.
. Air conditioning is limited to the capacity of
the electric power when the charge con-
nector is connected to the vehicle. There-
fore, the temperature may not reach a
comfortable level due to performance of
the air conditioning being limited, if the
outside temperature is excessively high or
low, or if the charge connector is connected
to a 120V outlet. .
If the power switch is in the ON position or
the charge connector is disconnected, while
the remote climate control is being oper-
ated, remote climate control operation is
automatically stopped and an e-mail is sent.
. If remote climate control operation is started
while the vehicle is in normal charge mode,
the climate control operates in climate
control priority mode and charging is con-
tinued.
. If remote climate control operation is started
and charging is stopped while the vehicle is
in quick charge mode, climate control
operation is also stopped.
. If the quick charge connector is connected
and charging is not performed, remote
climate control operation starts using the
battery electric power of the vehicle.

Page 18 of 1062

NISSAN LEAF 2012 Owners Manual .Do not place metalized film or any
metal parts (antenna, etc.) on the
windows. This may cause poor re-
ception of the signals from the tire
pressure sensors, and the TPMS will
not function properly.

.Do not place metalized film or any
metal parts (antenna, etc.) on the
windows. This may cause poor re-
ception of the signals from the tire
pressure sensors, and the TPMS will
not function properly.
Some devices and transmitters may temporarily
interfere with the operation of the TPMS and
cause the low tire pressure warning light to
illuminate. Some examples are:
. Facilities or electric devices using similar
radio frequencies that are near the vehicle.
. If a transmitter set to similar frequencies is
being used in or near the vehicle.
. If a computer (or similar equipment) or a DC/
AC converter is being used in or near the
vehicle.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation. NOTE:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
TPMS with Easy Fill Tire Alert
When tire pressure is low, the low tire pressure
warning light illuminates.
This vehicle provides visual and audible signals
to help you inflate the tires to the recommended
COLD tire pressure.
Vehicle set-up:
1. Park the vehicle in a safe and level place.
2. Apply the parking brake and push the P
position switch on the selector lever.
3. Place the power switch in the ON position. Do not place in the READY to drive mode. Operation:
1. Add air to the tire.
2. After a few seconds, the hazard indicators
will start flashing.
3. When the designated pressure is reached, the horn beeps once and the hazard
indicators stop flashing.
4. Perform the above steps for each tire.
. If the tire is over-inflated more than approxi-
mately 4 psi (30 kPa), the horn beeps and
the hazard indicators flash 3 times. To
correct the pressure, push the core of the
valve stem on the tire briefly to release
pressure. When the pressure reaches the
designated pressure, the horn beeps once.
. If the hazard indicator does not flash within
approximately 15 seconds after starting to
inflate the tire, it indicates that the Easy Fill
Tire Alert is not operating.
. The TPMS will not activate the Easy Fill Tire
Alert under the following conditions:
— If there is interference from an external
device or transmitter.
— The air pressure from the inflation device is not sufficient to inflate the tire such as
those using a power socket.

Page 23 of 1062

NISSAN LEAF 2012 Owners Manual 10 Index
A
ABS (Anti-lock Braking System) ............................ 5-23
Advanced air bag system ......................................... 1-42
Air bag systemAdvanced air bag system ...............

10 Index
A
ABS (Anti-lock Braking System) ............................ 5-23
Advanced air bag system ......................................... 1-42
Air bag systemAdvanced air bag system .................................. 1-42
Front passenger air bag and status light....... 1-44
Front-seat mounted side-impact supplemental
air bag system....................................................... 1-47
Roof-mounted curtain side-impact
supplemental air bag system ............................ 1-47
Air bag warning labels............................................... 1-50
Air bag warning light...................................... 1-50, 2-18
Air conditioner Air conditioner specification label....................... 9-8
Air conditioning system refrigerant and
lubricant recommendations................................... 9-3
Alarm, How to stop alarm (see vehicle
security system)........................................................... 2-36
Alcohol, drugs and driving.......................................... 5-6
Anti-lock Braking System (ABS) ............................ 5-23
Anti-lock braking system (ABS) warning light..... 2-14
Appearance care Exterior appearance care ...................................... 7-2
Interior appearance care ....................................... 7-4
Audible reminders....................................................... 2-21
Autolight system.......................................................... 2-42
Automatic Door locks................................................................. 3-5
Automatic climate control ........................................... 4-6
Avoiding collision and rollover ................................... 5-5
B
Battery 12-volt battery....................................................... 8-11
Battery saver system........................................... 2-43
Intelligent Key battery.......................................... 8-18
Li-ion battery.......................................................... EV-2
Li-ion battery temperature gauge........................ 2-7
Before starting system............................................... 5-10
Booster seats............................................................... 1-33
Brake Anti-lock Braking System (ABS) ..................... 5-23
Brake fluid................................................................. 8-9
Brake system......................................................... 5-21
BRAKE system warning light (yellow) ............ 2-14
BRAKE warning light (red) ................................ 2-15
Brakes..................................................................... 8-15
Electric parking brake operation ...................... 5-15
BRAKE system warning light (yellow) ................... 2-14
BRAKE warning light (red) ....................................... 2-15
Bulb replacement........................................................ 8-20
C
Cabin air filter............................................................... 4-13
Capacities and recommended lubricants ............... 9-2
Cargo cover.................................................................. 2-51
Ceiling light................................................................... 2-57
Charging Charge port lid...................................................... 3-17
Charging related indicator light.................... CH-26
Charging timer .................................................. CH-19
Cleaning .................................................................... 7-6
Normal charge ..................................................... CH-9
Precautions on charging ................................... CH-2 Quick charge..................................................... CH-16
Specifications........................................................... 9-4
Tricklle charge................................................... CH-11
Charging methods .................................................. CH-19
Charging related indicator light........................... CH-26
Charging related remote function....................... CH-25
Charging status indicator light ............................ CH-26
Charging timer ......................................................... CH-19
Charging troubleshooting guide.......................... CH-30
Checking Checking bulbs..................................................... 2-13
Checking coolant level .......................................... 8-8
Child restraints............................................................. 1-19 Booster seats........................................................ 1-33
Precautions on child restraints......................... 1-19
Top tether strap.................................................... 1-22
Child safety................................................................... 1-17
Child safety rear door lock ......................................... 3-6
Circuit breaker, Fusible link...................................... 8-17
Cleaning exterior and interior............................ 7-2, 7-4
Climate control Climate control service....................................... 4-14
Climate control system refrigerant and
lubricant recommendations................................ 4-14
In-cabin microfilter ............................................... 4-13
Climate control system Climate control operation...................................... 4-3
Climate Ctrl. Timer........................................................ 4-7
Clock.............................................................................. 2-11
Cockpit ............................................................................ 2-3
Cold weather driving.................................................. 5-26
Console box ................................................................. 2-51
Coolant Capacities and recommended lubricants ......... 9-2
Changing coolant.................................................... 8-8

Page 26 of 1062

NISSAN LEAF 2012 Owners Manual Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock......................................................

Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock...................................................... 3-4
Power windows .................................................... 2-53
Power economy........................................................... 5-19
Power meter ................................................................... 2-7
Power outlet ................................................................. 2-48
Power switch......................................................... 5-7, 5-8
Precautions Braking precautions............................................. 5-21
Charging................................................................ CH-2
Child restraints...................................................... 1-19
Cruise control........................................................ 5-17
High voltage precautions ................................... EV-7
Maintenance ............................................................. 8-4
Road accident precautions................................ EV-8
Seat belt usage .................................................... 1-10
Supplemental restraint system.......................... 1-36
When starting and driving .................................... 5-2
Push starting ................................................................ 6-12
Q
Quick charge............................................................ CH-16
R
Rapid air pressure loss................................................ 5-5
Rear center seat belt ................................................. 1-16
Rear door lock, Child safety rear door lock........... 3-6
Rear hatch..................................................................... 3-17
Rear seats....................................................................... 1-4
Rear window and outside mirror
defroster switch........................................................... 2-40
Rear window wiper and washer switch ............... 2-39
Reduction gear fluid..................................................... 8-9 Remote charge ........................................................ CH-25
Remote climate control.............................................. 4-11
Remote keyless entry function, For Intelligent
Key system.................................................................... 3-13
Repairing flat tire........................................................... 6-3
Repairing tire.................................................................. 6-5
Reporting safety defects........................................... 9-15
Road accident precautions....................................... EV-8
Roadside assistance program ................................... 6-2
Rollover............................................................................ 5-5
S
Safety Child seat belts .................................................... 1-17
Reporting safety defects.................................... 9-15
Scene guide At home after driving......................................... EV-21
Before driving your vehicle .............................. EV-13
Charging the Li-ion battery.............................. EV-10
Driving the vehicle.............................................. EV-17
Parking the vehicle............................................. EV-20
Starting your vehicle.......................................... EV-16
Seat adjustment Front manual seat adjustment.............................. 1-3
Front seats................................................................ 1-3
Seat belt(s) Child safety............................................................ 1-17
Infants...................................................................... 1-17
Injured persons..................................................... 1-12
Larger children...................................................... 1-18
Precautions on seat belt usage........................ 1-10
Pregnant women .................................................. 1-12
Rear center seat belt .......................................... 1-16
Seat belt cleaning................................................... 7-6
Seat belt extenders.............................................. 1-16
Seat belt hooks .................................................... 1-15 Seat belt maintenance........................................ 1-16
Seat belt warning light........................................ 2-18
Seat belts............................................................... 1-10
Seat belts with pretensioners........................... 1-49
Shoulder belt height adjustment...................... 1-15
Small children........................................................ 1-18
Three-point type................................................... 1-12
Seat(s) , Seats................................................................ 1-2 Heated seats......................................................... 2-46
Security system (NISSAN Vehicle Immobilizer
System) , EV system start.......................................... 2-36
Servicing climate control........................................... 4-14
Shifting Electric shift control system .............................. 5-11
Shoulder belt height adjustment, For
front seats..................................................................... 1-15
Soft bottle holders...................................................... 2-50
Solar cell module .......................................................... 7-3
Speedometer.................................................................. 2-6
Starting .......................................................................... 5-11 Before starting system........................................ 5-10
Jump starting............................................................ 6-9
Precautions when starting and driving .............. 5-2
Push starting ......................................................... 6-12
Status light, Front passenger air bag .................... 1-44
Steering Electric power steering system ........................ 5-21
Heated steering wheel........................................ 2-45
Tilting steering column........................................ 3-19
Stopping the vehicle .................................................... 6-4
Storage .......................................................................... 2-49
Stowing golf bags....................................................... 2-53
Sun visors ..................................................................... 3-20
Supplemental air bag warning labels..................... 1-50
Supplemental air bag warning light............ 1-50, 2-18
Supplemental restraint system................................. 1-36

Page 126 of 1062

Page 129 of 1062

Page 260 of 1062

NISSAN LEAF 2012 Owners Manual WARNING
.If you use any medical electric
devices, such as an implantable
cardiac pacemaker or an implanta-
ble cardiovascular defibrillator,
check with the electric medical de-
vice manufacturer conce

WARNING
.If you use any medical electric
devices, such as an implantable
cardiac pacemaker or an implanta-
ble cardiovascular defibrillator,
check with the electric medical de-
vice manufacturer concerning the
effects that charging may have on
implanted devices before starting
the charge operation. Charging
may affect the operation.
. If you have an implantable cardiac
pacemaker or an implantable cardi-
ovascular defibrillator, while the Li-
ion battery is charging:
— Do not stay inside the vehicle.
— Do not go inside the vehicle, for
example to remove or place an
item in the passenger compart-
ment.
— Do not open the rear hatch, for example to remove or place an
item in the cargo area.
Charging may affect the operation
of electric medical device and result
in serious personal injury or death. .
Make sure there is no water or
foreign materials in the charge port,
charge connector or electrical plug,
and that they are not damaged or
affected by rust or corrosion. If any
of these conditions are noticeable,
do not charge the Li-ion battery.
This may result in a short circuit or
electric shock and could cause a fire
which may result in serious perso-
nal injury or death.
. To avoid serious personal injury or
death when the Li-ion battery is
charging, be aware of the following
precautions.
— Do not touch the metal contacts
of the charge port, charge con-
nector or electrical plug.
— Do not touch the vehicle and charger when there is lightning.
A lightning strike may back feed
into the charger causing da-
mage and possible personal in-
jury or death.
. Make sure the charge connector is
removed from the charge port be-
fore starting your vehicle. If the
charge connector is only partially engaged and the connector latch is
unlocked, it is possible to place the
EV (Electric Vehicle) in the READY
to drive position.
. Do not plug in or unplug the plug
with wet hands and do not stand in
water, liquid or snow. This may
cause an electric shock which may
result in serious personal injury or
death.
. Do not disassemble or modify the
charge port or the EVSE (Electric
Vehicle Supply Equipment) . This
may cause a fire.
. If you notice an unusual odor or
smoke coming from the vehicle,
stop charging immediately.
. Be careful not to allow your hands,
hair, jewelry or clothing to come into
contact with, or get caught in, the
traction motor cooling fan. The cool-
ing fan can start at any time during
charging.
PRECAUTIONS ON CHARGING

Page 267 of 1062

NISSAN LEAF 2012 Owners Manual .Check by using a cellular phone, smart
phone or personal computer. See LEAF
Navigation System Owner’s Manual.
. Check by using the charging status indicator
light. See “Charging status indicator

Load next 8 pages

Page: 1-8 9-16 17-24 25-32 32 next >

radio antenna turn signal bulb alternator belt heating ABS headrest
