2012 NISSAN LEAF Owners Manual

.Check by using a cellular phone, smart
phone or personal computer. See LEAF
Navigation System Owner’s Manual.
. Check by using the charging status indicator
light. See “Charging status indicator lights”
later in this section.
NOTE:
. During the charge operation, charge
continues when the power switch is
placed in the ON position.
. The Li-ion battery cannot be charged if
the quick charge connector and the
normal charge connector are con-
nected at the same time. If another
charge connector is connected mid-
charge, charging will stop.
. For safety reasons, it is not possible to
switch to the READY to drive position
while a charge connector is connected.
. During charging, it is possible that the
radio may be inaudible due to noise by
the electromagnetic wave.HOW TO NORMAL CHARGE
WARNING
.If you use any medical electric
devices, such as an implantable
cardiac pacemaker or an implanta-
ble cardiovascular defibrillator,
check with the electric medical de-
vice manufacturer concerning the
effects that charging may have on
implanted devices before starting
the charge operation. Charging
may affect the operation.
. If you have an implantable cardiac
pacemaker or an implantable cardi-
ovascular defibrillator, while the Li-
ion battery is charging:
— Do not stay inside the vehicle.
— Do not go inside the vehicle, for
example to remove or place an
item in the passenger compart-
ment.
— Do not open the rear hatch, for example to remove or place an
item in the cargo area.
Charging may affect the operation
of electric medical device and result in serious personal injury or death.
. Be sure to follow the precautions
for using the charger that can be
installed in your home. Failing to do
so could result in serious injury or
death.

HOW TO TRICKLE CHARGE
WARNING
.If you use any medical electric
devices, such as an implantable
cardiac pacemaker or an implanta-
ble cardiovascular defibrillator,
check with the electric medical de-
vice manufacturer concerning the
effects that charging may have on
implanted devices before starting
the charge operation. Charging
may affect the operation.
. If you have an implantable cardiac
pacemaker or an implantable cardi-
ovascular defibrillator, while the Li-
ion battery is charging:
— Do not stay inside the vehicle.
— Do not go inside the vehicle, for
example to remove or place an
item in the passenger compart-
ment.
— Do not open the rear hatch, for example to remove or place an
item in the cargo area.
Charging may affect the operation
of electric medical device and result in serious personal injury or death.
. In order to avoid an electric shock or
fire due to a short circuit, connect to
GFI (Ground Fault Interrupter) cir-
cuit breaker and use a waterproof
electrical ground socket.
. The NISSAN Genuine EVSE (Electric
Vehicle Supply Equipment) charging
device provided with your vehicle
draws 12amps continuously while
charging the Li-ion battery. Do not
plug in to any electrical circuit un-
less it is inspected by a licensed
electrician to confirm that the elec-
trical circuit can accept a 12 amp
draw. Any electrical circuit has a
much higher likelihood of being
compromised in the following con-
ditions listed below.
— Improper use of the charger may
result in a fire and serious injury
or death.
— Do not use this charger in struc- tures more than 40 years old.
— Do not use this charger in struc- tures using fuse-based circuit
protection. Use only with elec-
trical circuits protected by circuit breakers.
— Do not use this charger on electrical circuits with two-prong
outlets.
— Do not use charger if outlet appears damaged or will not
hold plug firmly.
— Discontinue charger use imme- diately if plug or outlet becomes
hot to the touch or if you notice
any unusual odors.
— Do not use charger if other devices are plugged into the
same circuit.
— Never use extension cords or plug adapters with charger.
— Do not operate with a damaged cord.
— Always unplug the charger when not in use.
— When unplugging, be sure to pull by the plug and not the cord.
— The device has parts that may spark inside. Do not use it where
gasoline, paint, or flammable
liquids are used or stored.
ChargingCH-11

— Do not use if a malfunctionoccurs or if charger has been
damaged in any manner. Return
to a NISSAN certified LEAF deal-
er for replacement.
— The charger contains no user serviceable parts. Do not at-
tempt to repair the charger,
doing so will void your warranty.
CAUTION
. Only charge using a standard 110 -
120 volt, 15A dedicated electrical
outlet (For example do not use an
electric generator) . Failure to do so
may cause charging to fail and could
cause damage to the Li-ion battery
charging equipment due to power
surges.
. NISSAN recommends using genuine
NISSAN charging equipment to
charge the vehicle. Using non-
NISSAN equipment could cause
the Li-ion battery to not charge
correctly and may damage the Li-
ion battery.
. Trickle charging is performed using an AC
110 - 120 volt, 15A dedicated electrical
outlet using the EVSE (Electric Vehicle
Supply Equipment) provided with the vehi-
cle.
. The genuine NISSAN EVSE (Electric Vehi-
cle Supply Equipment) charging equipment or trickle charge cable performs a commu-
nication function with the vehicle before Li-
ion charging starts. If this communication
does not occur because other equipment is
used, the Li-ion battery will not charge.
. Immediate charge, charging timer and re-
mote charge can be performed in the trickle
charge mode. See “Charging timer” and
“Charging related remote function” later in
this section.
