2012 HONDA CR-V Owners Manual

88
uuGauges and DisplaysuMulti-Information Display
Instrument Panel
*1: Default SettingSetup Group Customizable Features Description Selectable settings
Customize Settings
Trip Computer Setup
Adjust
Outside Temp.
DisplayAdjusts the temperature reading by a few degrees.-5°F ~ ±0°F
*1
~ +5°F (U.S.)
-3°C ~ ±0°C *1
~ +3°C
(Canada)
Trip A reset triggerChanges the setting of how to reset trip meter A,
average fuel economy A, average speed A, and elapsed time A.With Refuel/Manual only *1
/
IGN OFF
Trip B reset triggerChanges the setting of how to reset trip meter B,
average fuel economy B, average speed B, and elapsed time B.With Refuel/Manual only *1
/
IGN OFF
Fuel Efficiency
BacklightTurns the ambient meter feature on and off.On *1
/Off
Lighting Setup
Interior Light Dimming TimeChanges the length of time the interior lights stay on
after you close the doors.60sec/30sec *1
/15sec
Headlight Auto Off TimerChanges the length of time the exterior lights stay on
after you close the driver’s door.60sec/30sec/15sec *1
/0sec
Auto Light SensitivityChanges the timing for the headlights to come on.Max/High/Mid/Low/Min *1

89
uuGauges and DisplaysuMulti-Information Display
Continued
Instrument Panel
*1:Default SettingSetup Group Customizable Features Description Selectable settings
Customize
Settings
Door Setup
Auto Door
LockChanges the setting for the automatic locking
feature.Off/With Vehicle Speed
*1
/
Shift from (P
Door Lock
ModeSets up either the driver’s door or all doors to unlock
on the first operation of the remote or ignition key.Driver Door *1
/All Doors
Auto Door UnlockChanges the setting for when the doors unlock automatically.
Off/
Driver Door with Shift to (P *1
/
All Doors with Shift to (P /
Driver Door with IGN Off/
All Doors with IGN Off
Keyless Lock
AcknowledgmentLOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.On *1
/Off
Security
Relock TimerChanges the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.90sec/60sec/30sec *1
Default AllCancels/Resets all the customized settings as default.Cancel
Reset All Defaults

uuGauges and DisplaysuMulti-Information Display
90
Instrument Panel
■ Example of customizing wallpapers
You can customize the display from clock to wallpaper.
Importing wallpapers from USB
You can import up to three images, one at a time for wallpaper from a USB flash
drive.Select Import Wallpaper from Customize Settings and properly connect a USB
flash drive to store an image.
1.Connect the USB flash drive to the adapter cable.
2 USB Adapter Cable P. 151
2. Press the MENU button.
3. Select Customize Settings with the
(+ / (- button, then press the SOURCE button.
4. Select Display Setup with the (+ / (-
button, then press the SOURCE button.
1Customized Features
• When importing wallpaper files, the image must be
in the USB flash drive’s root directory. Images in a
folder cannot be imported.
• The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).
• The individual file size limit is 2 MB.
• The maximum image size is 1,680 x 936 pixels. If
the image size was less than 420 x 234 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.
• The number of files that can be selected is up to 255.
• Up to 64 characters can be displayed in the file name.

91
uuGauges and DisplaysuMulti-Information Display
Continued
Instrument Panel
5.Select Import Wallpaper with the (+ / (-
button, then press the SOURCE button.
uThe file names are displayed on the screen.
6. Press the
(- button until the file name you
want to store appears on the center of the
display, then press the SOURCE button.
7. The preview of the imported data is displayed. Press the SOURCE button if it is
OK.
8. Press the SOURCE button to save the
image file.
Save

92
uuGauges and DisplaysuMulti-Information Display
Instrument Panel
9.Select the location you want to store the
image file in with the (+ / (- button, then
press the SOURCE button.
10. Press the MENU button to exit the
customizing screen.

93
uuGauges and DisplaysuMulti-Information Display
Instrument Panel
Selecting a wallpaper1.Press the MENU button.
2. Select Customize Settings with the
(+ / (- button, then press the SOURCE button.
3. Select Display Setup with the (+ / (-
button, then press the SOURCE button.
4. Select Select Wallpaper with the
(+ / (-
button, then press the SOURCE button.
5. Select the image file you want with the
(+ / (- button, then press the SOURCE
button.
uWhen the scroll is stopped, the
thumbnail is displayed.
6. Press the MENU button to exit the
customizing screen.

94

95
Controls
This chapter explains how to operate the various controls necessary for driving.
Setting the Clock ................................ 96
Locking and Unlocking the Doors
Key Types and Functions ... ................. 97
Locking/Unlocking the Doors from the Outside ............................................ 99
Locking/Unlocking the Doors from the Inside ............................................. 101
Childproof Door Locks ..................... 102
Auto Door Locking/Unlocking .......... 103
Opening and Closing the Tailgate ... 104
Security System ................................ 106
Immobilizer System .......................... 106
Security System Alarm *
.................... 106
Opening and Closing the Windows ..... 108Opening and Closing the Moonroof*...... 110Operating the Switches Around the
Steering WheelIgnition Switch ................................. 111
Turn Signals ..................................... 112
Light Switches.................................. 112Fog Lights *
...................................... 114
Daytime Running Lights ................... 114
Wipers and Washers ........................ 115
Brightness Control ........................... 117 Rear Defogger/Heated Door Mirror *

Button ........................................... 118
ECON Button ................................... 119
Adjusting the Steering Wheel........... 119 Adjusting the Mirrors
....................... 120
Interior Rearview Mirror ................... 120
Power Door Mirrors ......................... 121
Adjusting the Seats .......................... 122
Adjusting the Seat Positions ............. 122
Interior Lights/Interior Convenience Items ................................................ 132
Interior Lights .................................. 132
Interior Convenience Items .............. 133
Heating and Cooling System *
......... 142
Using Vents, Heating and A/C.......... 142
Climate Control System *
.................. 145
Using Automatic Climate Control .... 145
Automatic Climate Control Sensors . 148
* Not available on all models
