2012 Citroen C5 display

II
46
MULTIFUNCTION SCREENS

Defi ne vehicle parameters *
This menu allows you to activate or
deactivate certain driving and com-
fort systems, listed by category:


- Parking help


- Screen wiper functions



●
Engage rear wiper when in re-
verse (Rear wiper coupled to
reverse; see "Visibility"),

-

Confi gure lighting (see "Visibility"):



●
Duration of guide-me-home
lighting,

●
Directional headlamps function,

●

Daytime running lamps function ** .




Alert log
It lists the active alerts by displaying
the various associated messages in
turn.

Select language
This menu allows you to select the
language used by the screen display:
(Français, English, Italien, Portugais,
Espagnol, Allemand, Néerlandais,
Turc, Polonais, Russe).
Display confi guration
This menu allows you to choose a
colour scheme for the screen, adjust
the brightness, set the date and time
and choose the units for distance
(km or miles), fuel consumption
(l/100 km, mpg or km/l) and tempe-
rature (°Celsius or °Fahrenheit).
Speech synthesis setting

This menu allows you to set the volume
for navigation instructions and to chooses
the type of voice (male or female).


When setting the time, you can
choose to "Synchronise minutes
with GPS"
, so that the minutes
are set automatically by satellite
reception.

* Depending on country.

** Depending on country of sale.

III
49
COMFORT
DIGITAL AIR CONDITIONING (MONO-ZONE)
This is the normal sys-
tem operating mode.
In accordance with the
level of comfort chosen,
pressing this control,
confi rmed illumination
of indicator lamp A
, permits automatic
and simultaneous control of all of the
following functions:


- Air fl ow.

- Temperature in the passenger
compartment.

- Air distribution.

- Air intake.

- Air conditioning.
1. Automatic operation
It is advisable to leave all of the
vents open.
Simply pressing one of the controls,
with the exception of control 2
, switch-
es the system to manual mode.
Indicator lamp A
goes off.
2. Temperature adjustment

Turn control 2
to change
the temperature:


- Clockwise to in-
crease the temper-
ature.
The air conditioning system operates
with the engine running.

Mono-zone:
this is the overall regu-
lation of the temperature, distribution
and fl ow of air in the passenger com-
partment.
The symbols and messages associ-
ated with the digital air conditioning
controls appear in the multifunction
screen.


1.
Automatic operation

2.
Temperature adjustment

3.
Air distribution adjustment

4.
Activation/deactivation of the air
conditioning

5.
Air fl ow adjustment

6.
Front demisting - defrosting

7.
Rear demisting - defrosting

8.
Air recirculation - intake of exterior
air

9.
Screen

- Anticlockwise to reduce the tem-
perature.
The setting required is displayed.
The value indicated in the screen
corresponds to a level of comfort
and not to a temperature in degrees
Celsius or Fahrenheit, depending on
the screen confi guration.
A setting around the value 21
usually
provides optimum comfort. However,
depending on your requirements, a
setting between 18 and 24 is normal.
On entering the vehicle, the interior
temperature may be much colder (or
warmer) than is comfortable. There
is no need to change the tempera-
ture displayed to obtain rapidly the
level of comfort required.
The automatic regulation of the air
conditioning will use its maximum
performance settings to correct the
temperature difference as quickly as
possible.

III
50
COMFORT

Control via the manual controls
It is possible to adjust one or more
functions manually, while leaving the
other functions in automatic mode.


)
Press one of the controls, with
the exception of that which regu-
lates the temperature 2
. Indicator
lamp A
goes off.
Switching to manual mode may result
in discomfort (temperature, humidity,
odour, condensation) and may not
provide optimum comfort.
To return to automatic mode, press
the "AUTO"
control.

3. Air distribution adjustment


)
Press the controls 3

to change the distri-
bution of the air fl ow.
4. Air conditioning
The air conditioning will only oper-
ate when the engine is running. The
air blower control (air fl ow adjust-
ment) must be active to obtain air
conditioning.
Switching off the ventilation


)
Turn control 5
to the
left until the fl ow of
air stops.
)

Press control 4
. Indicator
lamp B
comes on.


5. Air fl ow adjustment
)
Turn control 5
to the
right to increase the
air fl ow or to the left
to reduce it.

6. Front demisting - defrosting
In certain cases, the
"AUTO"
mode may not
be suffi cient to demist or
defrost the windows (hu-
midity, several passen-
gers, ice).


)
Press control 6
to clear the win-
dows quickly. The indicator lamp
comes on. The "OFF"
symbol is displayed in
the multifunction screen.
This action switches off the screen
and the indicator lamps.
It deactivates all of the system's
functions, with the exception of the
rear screen demisting.
The temperature-related comfort is
no longer controlled (temperature,
humidity, odour, condensation).
Avoid driving for too long with the air
conditioning off. In order to be effective, the air condi-
tioning must be used with the windows
closed.
Deactivating the air conditioning may
result in discomfort (temperature,
humidity, odour, condensation).
The indicator lamps corresponding
to the distribution chosen come on:


- Windscreen and front side win-
dows.

- Front ventilation (central and
side vents and air diffusion grille
if open) and rear ventilation.

- Front and rear footwells.
Simultaneous display of the distribu-
tion of air to the windscreen and side
windows and of front and rear ventila-
tion is not possible. The air fl ow level is indicated by the
progressive illumination of the bars
in the control panel screen 9
.
To prevent condensation and dete-
rioration of the quality of the air in
the passenger compartment, ensure
that an adequate fl ow of air is main-
tained.
To reactivate the air conditioning:


)
Press control 1
.

III
51
COMFORT
The "Demisting" mode controls the
temperature, air fl ow and intake
and distributes the ventilation to the
windscreen and front side windows.
Resuming manual control exits from
"Demisting" mode. It must be can-
celled to permit renewal of the air
in the passenger compartment and
demisting.
Once the screen is clear, press-
ing control 1
returns the system to
"AUTO"
mode.


)
Press control 7
, with
the engine running,
to demist the rear
screen and the door
mirrors. The indica-
tor lamp comes on.
7. Rear demisting - defrosting
The heated rear screen operates in-
dependently of the air conditioning
system.
8. Intake of exterior air /
Recirculation of interior air
This function enables you to isolate
the passenger compartment from
exterior fumes and odours.


- When starting with the engine
cold, the fl ow will reach its
optimum level gradually to
prevent an excessive distribu-
tion of cold air.

- When entering the vehicle af-
ter it has been parked for a
fairly long period, if the inte-
rior temperature is very differ-
ent from your comfort setting
there is no need to change
the temperature displayed
in order to quickly reach the
level of comfort required. The
system automatically uses its
maximum performance to cor-
rect the difference in tempera-
ture as quickly as possible.

- The water resulting from the
air conditioning condensation
is discharged via an open-
ing provided for this purpose;
therefore, a puddle of water
may form underneath the ve-
hicle when stationary.

- In all seasons, if the weather
is cool, the air conditioning
is useful as it removes the
humidity from the air and the
condensation. Avoid driving
for prolonged periods with the
air conditioning switched off.

However, demisting resumes when
the engine is switched on again.
Switch off the rear screen and door
mirrors demisting when you consider
this necessary as low current con-
sumption reduces fuel consumption.
)
Press control 8
to set
the air intake mode,
the indicator lamp
comes on.






With Stop & Start, when demist-
ing has been activated, the STOP
mode is not available.

Demisting is switched off automatically
to prevent an excessive consumption
of current and in relation to the ambient
temperature.
It may be stopped by pressing con-
trol 7
again or when the engine is
switched off.
It must be cancelled as soon as
possible to permit renewal of the
air in the passenger compartment
and demisting.



You can store the air condition-
ing settings. Refer to the "Storing
driving positions" section.

III
53
COMFORT

2a-2b. Temperature adjustment
Control via the manual controls


)
Press one of the controls, with
the exception of temperature
regulation 2a
and 2b
. The indi-
cator lamps A
in the "AUTO"

controls go off.
It is possible to adjust one or more
functions manually while leaving the
other functions in automatic mode.
Switching to manual mode may re-
sult in discomfort (temperature, hu-
midity, odour, condensation) and
may not provide optimum comfort.
To return to "AUTO"
mode, press
controls 1a
and 1b
. The indicator
lamps A
come on.
3a-3b. Air distribution adjustment

)
Press control 3b
to change the
distribution of the air fl ow on the
passenger's side.
The indicator lamps corresponding
to the distribution chosen come on:


- Windscreen and front side win-
dows.

- Front ventilation (central and
side vents and air diffusion grille
if open) and rear ventilation.

- Front and rear footwells.
Simultaneous display of the distribu-
tion of air to the windscreen and side
windows and of front and rear venti-
lation is not possible.

)
Turn control 2a
to change the
temperature on the driver's side
and control 2b
to change the
temperature on the passenger's
side: to the right to increase the
temperature or to the left to re-
duce it.
The setting required is displayed.
The value indicated on the display
corresponds to a level of comfort
and not to a temperature in degrees
Celsius or Fahrenheit, depending on
the screen confi guration.
A setting around the value 21
usually
provides optimum comfort. However,
depending on your requirements, a
setting between 18 and 24 is normal.
On entering the vehicle, the interior
temperature may be much colder (or
warmer) than is comfortable. There
is no need to change the tempera-
ture displayed in order to quickly ob-
tain the level of comfort required.
The automatic regulation of the air
conditioning will use its maximum
performance settings to correct the
temperature difference as quickly as
possible.

)
Press control

3a
to change
the distribu-
tion of the air
fl ow on the
driver's side.

III
55
COMFORT
When starting with the engine
cold, air fl ow will reach its opti-
mum level gradually to prevent an
excessive distribution of cold air.
When entering the vehicle after it
has been parked for a fairly long
period, if the interior temperature
is very different from your comfort
setting there is no need to change
the temperature displayed in or-
der to quickly reach the level of
comfort required. The system
automatically uses its maximum
performance to correct the differ-
ence in temperature as quickly as
possible.
The water resulting from the air
conditioning condensation is dis-
charged via an opening provided
for this purpose; therefore, a pud-
dle of water may form underneath
the vehicle when stationary.
In all seasons, if the weather is
cool, the air conditioning is use-
ful as it removes the humidity
from the air and the condensa-
tion. Avoid driving for prolonged
periods with the air conditioning
switched off.
9. Front demisting - defrosting
In certain cases, the
"AUTO"
mode may not
be suffi cient to demist
or defrost the windows
(humidity, several pas-
sengers, ice).


)
Press control 9
to clear the win-
dows quickly. The indicator lamp
comes on.
This system controls the temperature,
air fl ow and intake and distributes the
ventilation to the windscreen and front
side windows.
Resuming manual control exits from
the "Demisting" mode. It must be
cancelled as soon as possible to
permit renewal of the air in the pas-
senger compartment and demisting.
Pressing one of the controls 1a

and 1b
returns the system to the
"AUTO"
mode.
8. Rear demisting - defrosting

Switch off the rear screen and exterior
mirrors demisting when you consider
this necessary as low current consump-
tion reduces fuel consumption.

The heated rear screen
operates independently
of the air conditioning
system.


)
Press control 8
, with the en-
gine running, to demist the rear
screen and the mirrors. The indi-
cator lamp comes on.
Demisting is switched off automatical-
ly to avoid excessive consumption of
current and depending on the exterior
temperature.
It may be stopped by pressing
control 8
again or when the engine
is switched off.
In this latter case, the demisting re-
sumes if the engine is switched on
again within one minute.






With Stop & Start, when demisting
has been activated, the STOP mode
is not available.

III
56
COMFORT
PROGRAMMABLE HEATING

The programmable heating operates
independently of the engine.
When the engine is off, it pre-heats
the coolant circuit in order to benefi t
from an optimum engine operating
temperature from the time the en-
gine is switched on.
The programmable heating system
is switched on using the long range
remote control. Activation can be im-
mediate or deferred by means of a
programming function.

Programming remote control

The heating system programming
remote control consists of the fol-
lowing buttons and displays:


1.
Scrolling functions menu but-
tons.

2.
Function indicators: clock, tem-
perature, operating time, pro-
grammed time, heater operation,
heating management symbols.

3.
Digital displays: time, tempera-
ture, duration of operation, pro-
grammed time or level of heating.

4.
Off button.

5.
On button.



Displays on the remote
control screen

Press the buttons 1
in succession to
display the functions.
The fi rst press of the left-hand or
right-hand button displays the time.
Next, the left-hand button permits
access to the programming time then
to the level of heating (C1 to C5).
The right-hand button permits ac-
cess to the passenger compartment
temperature then to the duration of
operation of the heater if it is to be
switched on immediately.

If a malfunction of the program-
mable heating system occurs,
contact a CITROËN dealer
or a

qualifi ed workshop

.




Displaying the functions


The passenger compartment tem-
perature information is only avail-
able when the engine is off.

III
57
COMFORT

Setting the time

Once the time has been displayed,
by means of the buttons 1
, press
buttons 4
and 5
simultaneously with-
in 10 seconds.

Immediate activation

Press button 5
(ON) until the mes-
sage "OK"
appears.
When the signal has been received,
the message "OK"
is displayed
along with the duration of operation. Press the buttons 1
to display the
duration of operation.
This symbol fl ashes.
Set the time using the buttons 1
.
Press buttons 4
and 5
simultane-
ously to save it.
This symbol is displayed (fi xed).

The heater starts and this
symbol is displayed.
To deactivate the function, press
button 4
(OFF) until the message
"OK"
appears.
This symbol is switched off.

When carrying out these opera-
tions, if the message "FAIL"
ap-
pears, the signal has not been
received. Repeat the procedure
after changing your location.



Setting the duration of
operation
This symbol is displayed.
Once the duration of operation has
been displayed, press buttons 4
and 5

simultaneously within 10 seconds.
This symbol fl ashes.
Set the duration by pressing the
buttons 1
(adjustment in steps of
10 mins and max value 30 mins).
Press buttons 4
and 5
simultaneous-
ly to save the duration of operation.
This symbol is displayed (fi xed).


The factory setting value is 30 minutes.
