2011 TOYOTA 4RUNNER Owners Manual

617
6-1. Specifications
6
Vehicle specifications
4RUNNER_U
How to read oil container label:
The ILSAC (International Lubric
ant Standardization and Approval
Committee) Certification Mark is added to some oil containers to help
you select the oil you should use.
CTH61AS018

618 6-1. Specifications
4RUNNER_U
Cooling system
Ignition system
Capacity
2.7 L 4-cylinder (2TR-FE) engine
8.6 qt. (8.1 L, 7.1 Imp. qt.)
4.0 L V6 (1GR-FE) engine
11.1 qt. (10.5 L, 9.2 Imp. qt.)
Coolant type
Use either of the following:• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-based non-silicate, non-amine, non-
nitrite, and non-borate coolant with long-
life hybrid organic acid technology
Do not use plain water alone.
Spark plug
Make
GapDENSO SK20HR11
0.043 in. (1.1 mm)
NOTICE
■ Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

619
6-1. Specifications
6
Vehicle specifications
4RUNNER_U
Electrical system
Transfer (4WD models)
*: “Toyota Genuine Transfer Gear oil LF” is put in your Toyota vehicle at
the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil
LF” or an equivalent of matching quality to satisfy the above specifi-
cation. Please contact your Toyo ta dealer for further details.
Battery
Open voltage* at
68 F (20 C):12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11 . 8  12.0 V Discharged
(
*: Voltage checked 20 minutes after the
engine and all the lights are turned off.)
Charging rates5 A max.
Oil capacity
Part-time 4WD models
1.1 qt. (1.0 L, 0.9 Imp. qt.)
Full-time 4WD models
1.5 qt. (1.4 L, 1.2 Imp. qt.)
Oil type*Toyota Genuine Transfer gear oil LF or
equivalent
Recommended oil viscositySAE 75W

620 6-1. Specifications
4RUNNER_U
Front differential (4WD models)
*: “Toyota Genuine Differential Gear Oil” is put in your Toyota vehicle atthe factory. Use Toyota approved “Toyota Genuine Differential Gear
Oil” or an equivalent of matchi ng quality to satisfy the above specifi-
cation. Please contact your Toyo ta dealer for further details.
Rear differential
*: “Toyota Genuine Differential Gear Oil” is put in your Toyota vehicle at
the factory. Use Toyota approved “Toyota Genuine Differential Gear
Oil” or an equivalent of matchi ng quality to satisfy the above specifi-
cation. Please contact your Toyo ta dealer for further details.
Oil capacity
Part-time 4WD models
1.6 qt. (1.55 L, 1.4 Imp. qt.)
Full-time 4WD models
1.5 qt. (1.40 L, 1.2 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
Oil capacity
Vehicles without a rear differential lock
2.9 qt. (2.70 L, 2.4 Imp. qt.)
Vehicles with a rear differential lock
2.8 qt. (2.65 L, 2.3 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent

621
6-1. Specifications
6
Vehicle specifications
4RUNNER_U
Automatic transmission
*: The fluid capacity is a reference q
uantity. If replacement is necessary,
contact your Toyota dealer.
Brakes
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50 kgf) while the engine is running.
*2: Parking brake pedal travel when depressed with a force of 67 lbf (300 N, 30kgf).
Fluid capacity*
2.7 L 4-cylinder (2TR-FE) engine
10.5 qt. (9.9 L, 8.7 Imp. qt.)
4.0 L V6 (1GR-FE) engine
11.3 qt. (10.7 L, 9.4 Imp. qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■ Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of the transmission accompanied by
vibration and, ultimately, damage to the vehicle’s transmission.
Pedal clearance *13.62 in. (92 mm) Min.
Pedal free playLess than 0.04  0.24 in. (1  6 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Parking brake pedal travel *25  7 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3

622 6-1. Specifications
4RUNNER_U
Chassis lubrication
Steering
Propeller shafts
Spider
Slide yokeLithium base chassis grease, NLGI No.2
Molybdenum-disulfide lithium base chas-
sis grease, NLGI No.2 or lithium base mul-
tipurpose grease, NLGI No.2
Free playLess than 1.2 in. (30 mm)
Power steering fluid typeAutomatic transmission fluid DEXRON® II
or III

623
6-1. Specifications
6
Vehicle specifications
4RUNNER_U
Tires and wheels
2.7 L 4-cylinder (2TR-FE) engine
4.0 L V6 (1GR-FE) engine
Tire sizeP265/70R17 113S
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Front:
33 psi (230 kPa, 2.3 kgf/cm2 or bar)
Rear:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Spare:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Wheel size17  7J
Wheel nut torque83 ft•lbf (110 N•m, 11.5 kgf•m)
Tire sizeP265/70R17 113S, P245/60R20 107H
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Front:
32 psi (220 kPa, 2.2 kgf/cm2 or bar)
Rear:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Spare:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Wheel size17  7J, 17  7 1/2J, 20  7J
Wheel nut torque83 ft•lbf (110 N•m, 11.5 kgf•m)

624 6-1. Specifications
4RUNNER_U
Light bulbs
*: If equipped
A: H11 halogen bulbs
B: HB3 halogen bulbs
C: Single end bulbs (amber)
D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber)
F: Double end bulbs
Light BulbsBulb No.WTy p e
Exterior
Headlights Low beam
High beam

55
60A
B
Front turn signal and daytime
running lights1156NA27C
Parking lights and front side
marker lights5D
Fog lights*55A
Rear turn signal lights21E
Back-up lights16D
License plate lights5D
Stop/tail and rear side marker
lights744321/5D
Outer foot lights*5D
Interior
Front personal/ front interior
lights5D
Rear interior light8F
Vanity lights8D
Door courtesy lights1685D
Luggage compartment lights8F
