2011 SUBARU IMPREZA WRX STI Owners Manual

Black plate (195,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
& Type A audio set (if equipped)
The audio set will operate only when the
ignition switch is in the “Acc”or “ON ”
position.
. Power and sound controls: refer to
page 5-8
. Radio operation: refer to page 5-12
. Satellite radio operation (if equipped):
refer to page 5-17
. CD (compact disc) player operation:
refer to page 5-23
. Auxiliary input jack: refer to page 5-34
Audio
5-5
–CONTINUED –
5

Black plate (196,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
5-6
Audio
& Type B audio set (if equipped)
The audio set will operate only when the
ignition switch is in the “Acc”or “ON ”
position.
. Power and sound controls: refer to
page 5-8
. Radio operation: refer to page 5-12
. Satellite radio operation (if equipped):
refer to page 5-17
. CD (compact disc) player operation:
refer to page 5-23
. Auxiliary input jack: refer to page 5-34

Black plate (197,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
& Type C audio set (if equipped)
The audio set will operate only when the
ignition switch is in the “Acc”or “ON ”
position.
. Power and sound controls: refer to
page 5-8
. Radio operation: refer to page 5-12
. Satellite radio operation (if equipped):
refer to page 5-17
. CD (compact disc) player operation:
refer to page 5-23
. Auxiliary input jack: refer to page 5-34
. USB storage device/iPod
®operation:
refer to page 5-37
. Hands-free system: refer to page 5-46Audio
5-7
5

Black plate (198,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
5-8
Audio
Power and sound controls& Power switch and volume
controlType A and B audioType C audio
The dial is used for both power (ON/OFF)
and volume control. The radio is turned
ON and OFF by pushing the dial, and the
volume is controlled by turning the dial.&Sound control! Tone and balance controlType A and B audio
Type C audioEach brief press of the sound control dial
changes the control modes in the follow-
ing sequence.Choose the desired level for each mode
by turning the sound control dial.
The control function returns to the tune/
track/channel control mode after approxi-
mately 5 seconds.

Black plate (199,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
! Other sound setting controlsType A and B audioType C audioEach brief press of the “MENU”button
changes the control modes in the follow-
ing sequence. Type A audio:
Type B audio:Type C audio:Choose the desired settings for each
mode by turning the sound control dial.
The control function returns to the tune/
track/channel control mode after approxi-
mately 5 seconds.
!
SPEED VOLUME setting
SPEED VOLUME CONTROL is a function
that automatically adjusts the volume
according to the vehicle speed. As the
vehicle speed increases, the audio vo-
lume automatically increases to match the
vehicle speed, in order to create a
pleasant listening environment even as
the driving noise increases. The amount of this automatic volume change can be set
in the range from OFF to 2. The initial
setting is OFF.
!
BEEP setting
A beep sound (operation sound) that
occurs when the audio system is operated
can be set ON/OFF. The initial setting is
ON.
! SRS CS Auto setting (type B audio)
SRS CS Auto can be set ON/OFF. When
this setting is ON, “
”is displayed on the
screen.
NOTESRS CS Auto creates a 5.1ch equiva-
lent surround field using 10 speakers
that are installed in the vehicle.
SRS CS Auto features:
1) Sound originating from door mount
speakers can be heard at ear level
(built in SRS FOCUS effect).
2) Ultra rich bass sound can be ob-
tained from standard door mount
speakers (built in SRS TruBass effect).
3) Surround sound can be obtained
from 2-channel stereo sources such as
CD, MP3 and FM (built in SRS Circle
Surround II effect).
4) SRS CS Auto can position the
center channel image in the center of
the vehicle ’s windshield. This elimi-
Audio
5-9
– CONTINUED –
5

Black plate (200,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
5-10
Audio
nates the need for a center speaker
(built in SRS Circle Surround II phan-
tom center and SRS FOCUS effects).
CS Auto, TruBass, FOCUS, Circle Sur-
round-II, SRS and “
”symbol are
trademarks of SRS Labs, Inc.
CS Auto technology is incorporated
under license from SRS Labs, inc.

Black plate (201,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
& Adjustable level of each modeMode Range of levels
(displayed)Initial setting Turn counterclockwise Turn clockwise
Volume Volume control 0 to 4015For less volume For more volume
AUX volume control* 0 to 40 15For less volume For more volume
Tone and balance Bass control 8 to +8 0For less bass sound For more bass sound
Midrange control 8 to +8 0 For less midrange sound For more midrange sound
Treble control 8 to +8 0 For less treble sound For more treble sound
Balance L9 to R9 0 Right channel attenuated Left channel attenuated
Fader R9 to F9 0 Front attenuatedRear attenuated
Other settings SPEED VOLUME OFF to 2 OFF For less auto volume change For more auto volume change
BEEP OFF to ON ON OFFON
CS Auto (Type B audio) OFF to ON OFF OFFON
*: For type A and B audio, AUX volume can be adjusted only when an AUX audio product is connected. Audio
5-11
5

Black plate (202,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
5-12
Audio
FM/AM radio operation& FM/AM selectionType A and B audioType C audioPush the “FM/AM”button when the radio is off to turn on the radio.
Push the
“FM/AM”button when the radio
is on to select FM1, FM2, FM3 or AM
reception.
Each brief press of the “FM/AM”button
changes the radio in the following se-
quence starting from the last radio band
with you selected.
& Tuning! Manual tuningType A and B audio
Type C audioTurn the “TUNE/TRACK/CH ”dial clock-
wise to increase the tuning frequency and
turn the “TUNE/TRACK/CH ”dial counter-
clockwise to decrease it.
Each time the dial is turned, the frequency
interval can be changed between 10 kHz
in the AM mode and 0.2 MHz in the FM
mode.
! Stereo indicator
The stereo indicator “ST”will illuminate
when an FM stereo broadcast is received.
