2011 INFINITI QX56 sensor

DAS
C1A14 ECMDAS-355
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A14 ECM
DTC LogicINFOID:0000000006228195
DTC DETECTION LOGIC
NOTE:
If DTC “C1A14” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Operate the ICC system and drive. CAUTION:
Always drive safely.
3. Stop the vehicle.
4. Perform “All DTC Readi ng” with CONSULT-III.
5. Check if the “C1A14” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A14” detected as the current malfunction?
YES >> Refer to DAS-355, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228196
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A14” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.PERFORM SELF-DIAGNOSIS OF ECM
Check if any DTC is detected in “S elf Diagnostic Result” of “ENGINE”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
EC-98, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A14 (14) ECM CIRCUIT If ECM is malfunctioning  Accelerator pedal position sensor
ECM
 ADAS control unit
Revision: 2010 May2011 QX56

DAS-356
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A15 GEAR POSITION
C1A15 GEAR POSITION
DescriptionINFOID:0000000006228197
ADAS control unit judges the gear pos
ition based on the following signals.
 Current gear position signal transmitt ed from TCM via CAN communication.
 Value of gear ratio calculated from input speed signal transmitted from TCM via CAN communication.
 Value of gear ratio calculated from the vehicle speed signal transmitted from ABS actuator and electric unit
(control unit) via CAN communication.
DTC LogicINFOID:0000000006228198
DTC DETECTION LOGIC
NOTE:
If DTC “C1A15” is detected along with DTC “U1000”, “C1A03”, or “C1A04”, first diagnose the DTC “U1000”,
“C1A03”, or “C1A04”.
 Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic" for DTC “U1000”.
 Refer to DAS-347, "
DTC Logic" for DTC “C1A03”.
 Refer to DAS-348, "
DTC Logic" for DTC “C1A04”.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Drive the vehicle at 10 km/h (6 MPH) or faster for approximately 15 minutes or more.
CAUTION:
Always drive safely.
4. Stop the vehicle.
5. Perform “All DTC Reading” with CONSULT-III.
6. Check if “C1A15” is detected as the current malf unction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A15” detected as the current malfunction?
YES >> Refer to DAS-356, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228199
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “C1A03”, “C1A04”, or “U1000” is detected ot her than “C1A15” in “Self Diagnostic Result” of “ICC/
ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-310, "
DTC Index".
NO >> GO TO 2.
2.CHECK VEHICLE SPEED SIGNAL
Check that “VHCL SPEED SE” operates norma lly in “DATA MONITOR” of “ICC/ADAS”.
CAUTION:
Be careful of the vehicle speed.
Is the inspection result normal?
DTC
(On board dis- play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A15 (15) GEAR POSITION A mismatch between an current gear posi-
tion signal transmitted from TCM via CAN
communication and a gear position calculat-
ed by the ADAS control unit continues for
approximately 11 minutes or more  Input speed sensor
 Vehicle speed sensor A/T (output speed
sensor)
TCM
Revision: 2010 May2011 QX56

DAS
C1A15 GEAR POSITIONDAS-357
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
YES >> GO TO 3.
NO >> GO TO 7.
3.CHECK GEAR POSITION
Check that “GEAR” operates normally in “DATA MONITOR” of “ICC/ADAS”.
CAUTION:
Be careful of the vehicle speed.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.CHECK GEAR POSITION SIGNAL
Check that “GEAR” operates normally in “DATA MONITOR” of “TRANSMISSION”.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHECK INPUT SPEED SENSOR SIGNAL
Check that “INPUT SPEED” operates normally in “DATA MONITOR” of “TRANSMISSION”.
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> GO TO 6.
6.CHECK TCM SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Reading”.
2. Check if any DTC is detected in “Sel f Diagnostic Result” of “TRANSMISSION”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
TM-78, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
7.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Reading”.
2. Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
Revision: 2010 May2011 QX56

DAS-368
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
U0126 STRG SEN CAN 1
U0126 STRG SEN CAN 1
DTC LogicINFOID:0000000006223779
DTC DETECTION LOGIC
NOTE:
If DTC “U0126” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “U0126” is detected as the current malfunction in “Self Diagnostic Result” of “LANE CAM-
ERA”.
Is
“U0126” detected as the current malfunction?
YES >> Refer to DAS-368, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223780
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “U0126” in “Self Diagnostic Result” of “LANE CAMERA”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
LANE CAMERA UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ADAS CONTROL UNIT SE LF-DIAGNOSIS RESULTS
Check if any DTC is detected in “S elf Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-310, "
DTC Index".
NO >> Replace the lane camera unit. Refer to DAS-403, "
Removal and Installation".
DTC Trouble diagnosis name DTC detecting condition Possible causes
U0126 STRG SEN CAN CIR1 If lane camera unit detects an error signal that
is received from steering angle sensor via
ADAS control unit Steering angle sensor
Revision: 2010 May2011 QX56

DAS
U0428 STRG SEN CAN 2DAS-373
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
U0428 STRG SEN CAN 2
DTC LogicINFOID:0000000006223789
DTC DETECTION LOGIC
NOTE:
If DTC “U0428” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “U0428” is detected as the current malfunction in “Self Diagnostic Result” of “LANE CAM-
ERA”.
Is
“U0428” detected as the current malfunction?
YES >> Refer to DAS-373, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223790
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “U0428” in “Self Diagnostic Result” of “LANE CAMERA”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
LANE CAMERA UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “S elf Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-310, "
DTC Index".
NO >> Replace the lane camera unit. Refer to DAS-403, "
Removal and Installation".
DTC Trouble diagnosis name DTC detecting condition Possible causes
U0428 STRG SEN CAN CIR2 If lane camera unit detects an error signal that
is received from steering angle sensor via
ADAS control unit Steering angle sensor
Revision: 2010 May2011 QX56

DAS
PRECAUTIONSDAS-407
< PRECAUTION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006223847
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
 To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
 Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
 When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Precaution for BSW System ServiceINFOID:0000000006223848
WARNING:
Be careful of traffic conditions and safety aro und the vehicle when performing road test.
CAUTION:
 Never perform the active test while driving.
 Never change BSW initial state ON ⇒ OFF without the consent of the customer.
TO KEEP THE BSW SYSTEM OPERATING PROPERLY, BE SURE TO OBSERVE THE FOLLOW-
ING ITEMS:
System Maintenance
The two side radar for the BSW system are located near the rear bumper.
 Always keep the area near the side radar clean.
 Do not attach stickers (including transparent material ), install accessories or apply additional paint near the
side radar.
 Do not strike or damage the area around the side radar.
Revision: 2010 May2011 QX56

DAS-420
< SYSTEM DESCRIPTION >[BSW]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
NOTE:
 Causes of the maximum five cancella
tions (system cancel) are displayed.
 The displayed cancellation causes display the number of the ignition switch ON/OFF up to 254. It is fixed to
254 if it is over 254. It returns to 0 when the same cancellation cause is detected again.
Display Items for The Cause of Automatic Cancellation 1
Work support items Description
CAUSE OF AUTO-CANCEL 1 Displays causes of automatic system cancellation occurred during control of the following sys-
tems
 Vehicle-to-vehicle distance control mode
 Conventional (fixed speed) cruise control mode
 Distance Control Assist (DCA)
CAUSE OF AUTO-CANCEL 2 Displays causes of automatic system cancellation occurred during control of the Lane Depar-
ture Prevention (LDP) system
Cause of cancellation
Vehicle-to-vehicle distance control mode
Conventional (fixed speed) cruise control mode Distance Control Assist
Description
OPERATING WIPER ×The wiper operates at HI (it includes when the wiper is operated at
HI with the wiper switch AUTO position)
OPERATING ABS ××ABS function was operated
OPERATING TCS ×××TCS function was operated
OPERATING VDC ×××VDC function was operated
ECM CIRCUIT ××ECM did not permit ICC operation
OPE SW VOLT CIRC ×××The ICC steering switch input voltage is not within standard range
LASER SUNBEAM ××Intense light such as sunlight entered ICC sensor light sensing part
LASER TEMP ××Temperature around ICC sensor became low
SNOW MODE SW ××SNOW mode switch was pressed
OP SW DOUBLE
TOUCH ××
ICC steering switches were pressed at the same time
VHCL SPD DOWN ×××Vehicle speed lower than the speed as follows
 Vehicle-to-vehicle distance control mode is 24 km/h (15 MPH)
 Conventional (fixed speed) cruise control mode is 32 km/h (20
MPH)
WHL SPD ELEC NOISE ×××Wheel speed sensor signal caught electromagnetic noise
VDC/TCS OFF SW ××VDC OFF switch was pressed
VHCL SPD UNMATCH ×××Wheel speed became different from A/T vehicle speed
TIRE SLIP ××Wheel slipped
IGN LOW VOLT ×××Decrease in ADAS control unit IGN voltage
PARKING BRAKE ON ××The parking brake is operating
WHEEL SPD UNMATCH ×××The wheel speeds of 4 wheels are out of the specified values
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-421
< SYSTEM DESCRIPTION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
Display Items for The Cause of Automatic Cancellation 2
SELF DIAGNOSTIC RESULT
Refer to DAS-38, "DTC Index".
DATA MONITOR
INCHING LOST ×A vehicle ahead is not detected during the following driving when
the vehicle speed is approximately 24 km/h (15 MPH) or less
CAN COMM ERROR ×××ADAS control unit received an abnormal signal with CAN commu-
nication
ABS/TCS/VDC CIRC ×××An abnormal condition occurs in VDC/TCS/ABS system
ECD CIRCUIT ×××An abnormal condition occurs in ECD system
ASCD VHCL SPD DTAC ×Vehicle speed is detached from set vehicle speed
ASCD DOUBLE COMD ×Cancel switch and operation switch are detected simultaneously
APA HI TEMP ×The accelerator pedal actuator integrated motor temperature is
high
ICC SENSOR CAN
COMM ERR ××Communication error between ADAS control unit and the ICC sen-
sor
4WD LOCK MODE ×××Shifting of the 4WD shift switch to 4H or 4L
ABS WARNING LAMP ××ABS warning lamp ON
NO RECORD ××× —
Cause of cancellation Description
OPE VDC/TCS/ABS 1 The activation of VDC, TCS, or ABS during LDP system control
Vehicle dynamics Vehicle behavior exceeds specified value
Steering speed Steering speed was more than the specified value in evasive direction
End by yaw angle Yaw angle was the end of LDP control
Departure yaw large Detected more than the specified value of yaw angle in departure direction
ICC WARNING Target approach warning of ICC system, IBA system or FCW system was activated
CURVATURE Road curve was more than the specified value
Steering angle large Steering angle was more than the specified value
Brake is operated Brake pedal was operated
IGN LOW VOLT Decrease in ADAS control unit IGN voltage
Lateral offset Distance of vehicle and lane was detached in lateral direction more than the specified value
Lane marker lost Lane camera unit lost the trace of lane marker
Lane marker unclear Detected lane marker was unclear
Yaw acceleration Detected yawing speed was more than the specified value
Deceleration large Deceleration in a longitudinal direction was more than the specified value
Accel is operated Accelerator pedal was depressed
Departure steering Steering wheel was steered more than the specified value in departure direction
Evasive steering Steering wheel was steered more than the specified value in the evasive direction
R range Selector lever was operated to R range
Parking brake drift Rear wheels lock was detected
Not operating condition Did not meet the operating condition (vehicle speed, turn signal operation, etc)
SNOW MODE SW SNOW mo de switch was pressed
VDC OFF SW VDC OFF switch was pressed
OPE VDC/ABS 2 The activation of VDC or ABS duri ng a standby time of LDP system control
4WD LOCK MODE Shifting of the 4WD shift switch to 4H or 4L
NO RECORD —
Revision: 2010 May2011 QX56
