DAS-24
< SYSTEM DESCRIPTION >[ADAS CONTROL UNIT]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
Monitored item
[Unit]
ALL SIG(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
MAIN SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
SET/COAST SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CANCEL SW
[On/Off] ××
Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
RESUME/ACC SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
DISTANCE SW
[On/Off] × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CRUISE OPE
[On/Off] ××
Indicates whether controlling or not (ON means “controlling”)
BRAKE SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC brake switch signal (ECM transmits
ICC brake switch signal through CAN communication)
STOP LAMP SW
[On/Off] ×× × × Indicates [On/Off] status as judged from stop lamp switch signal (ECM transmits
stop lamp switch signal through CAN communication)
IDLE SW
[On/Off] ×
Indicates [On/Off] status of idle switch read from ADAS control unit through CAN
communication (ECM transmits On/Off status through CAN communication)
SET DISTANCE
[Short/Mid/Long] ××
Indicates set distance memorized in ADAS control unit
CRUISE LAMP
[On/Off] ××
Indicates [On/Off] status of MAIN switch indicator output
OWN VHCL
[On/Off] ×
Indicates [On/Off] status of own vehicle indicator output
VHCL AHEAD
[On/Off] ×
Indicates [On/Off] status of vehicle ahead detection indicator output
ICC WARNING
[On/Off] ×
Indicates [On/Off] status of ICC system warning lamp output
VHCL SPEED SE
[km/h] or [mph] ×× × × Indicates vehicle speed calculated from ADAS control unit through CAN commu-
nication [ABS actuator and electric unit (c
ontrol unit) transmits vehicle speed sig-
nal (wheel speed) through CAN communication]
SET VHCL SPD
[km/h] or [mph] ××
Indicates set vehicle speed memorized in ADAS control unit
BUZZER O/P
[On/Off] ×
Indicates [On/Off] status of ICC warning chime output
THRTL SENSOR
[deg] ××
NOTE:
The item is displayed, but it is not monitored
ENGINE RPM
[rpm] × Indicates engine speed read from ADAS control unit through CAN communication
(ECM transmits engine speed signal through CAN communication)
WIPER SW
[OFF/LOW/HIGH] × Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front wiper request sig-
nal through CAN communication)
YAW R AT E
[deg/s] ×
NOTE:
The item is displayed, but it is not monitored
BA WARNING
[On/Off] ×
Indicates [On/Off] status of IBA OFF indicator lamp output
STP LMP DRIVE
[On/Off] ××
Indicates [On/Off] status of ICC brake hold relay drive output
D RANGE SW
[On/Off] × Indicates [On/Off] status of “D” or “M” positions read from ADAS control unit
through CAN communication; ON when position “D” or “M” (TCM transmits shift
position signal through CAN communication).
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-25
< SYSTEM DESCRIPTION > [ADAS CONTROL UNIT]
C
D
E
F
G H
I
J
K L
M B
N P A
NP RANGE SW
[On/Off] × Indicates shift position signal read from ADAS control unit through CAN commu-
nication (TCM transmits shift position signal through CAN communication)
PKB SW
[On/Off] × Parking brake switch status [On/Off] judged from the parking brake switch signal
that ADAS control unit readout via CAN communication is displayed (Combination
meter transmits the parking brake switch signal via CAN communication)
PWR SUP MONI
[V] ××
Indicates IGN voltage input by ADAS control unit
VHCL SPD AT
[km/h] or [mph] × Indicates vehicle speed calculated from A/T vehicle speed sensor read from
ADAS control unit through CAN communication (TCM transmits A/T vehicle speed
sensor signal through CAN communication)
THRTL OPENING
[%] ×× Indicates throttle position read from ADAS control unit through CAN communica-
tion (ECM transmits accelerator pedal position signal through CAN communica-
tion).
GEAR
[1, 2, 3, 4, 5, 6, 7] × Indicates A/T gear position read from ADAS control unit through CAN communi-
cation (TCM transmits current gear position signal through CAN communication)
MODE SIG
[OFF, ICC, ASCD] × Indicates the active mode from ICC or ASCD [conventional (fixed speed) cruise
control mode]
SET DISP IND
[On/Off] ×
Indicates [On/Off] status of SET switch indicator output
DISTANCE
[m] ×
Indicates the distance from the vehicle ahead
RELATIVE SPD
[m/s] ×
Indicates the relative speed of the vehicle ahead
DYNA ASIST SW
[On/Off] ×× ×
Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
DCA ON IND
[On/Off] ×
The status [ON/OFF] of DCA system switch indicator output is displayed
DCA VHL AHED
[On/Off] × The status [ON/OFF] of vehicle ahead detection indicator output in DCA system
is displayed
IBA SW
[On/Off] ××
Indicates [On/Off] status of IBA OFF switch
FCW SYSTEM ON
[On/Off] ××
Indicates [On/Off] status of FCW system
APA TEMP
[ ° C] × Accelerator pedal actuator integrated motor temperature that the ADAS control
unit readout via ITS communication is displayed (Accelerator pedal actuator trans-
mits the integrated motor temperature via ITS communication)
APA PWR
[V] × Accelerator pedal actuator power supply voltage that the ADAS control unit read-
out via ITS communication is displayed (Accelerator pedal actuator transmits the
power supply voltage via ITS communication)
LDW SYSTEM ON
[On/Off] ×
Indicates [On/Off] status of LDW system
LDW ON LAMP
[On/Off] ×
Indicates [On/Off] status of waning systems ON indicator output
LDP ON IND
[On/Off] ×
Indicates [On/Off] status of LDP ON indicator lamp (Green) output
LANE DPRT W/L
[On/Off] ×
Indicates [On/Off] status of lane departure warning lamp (Yellow) output
LDW BUZER OUT-
PUT
[On/Off] ×
Indicates [On/Off] status of warning buzzer output
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Revision: 2010 May2011 QX56

DAS-26
< SYSTEM DESCRIPTION >[ADAS CONTROL UNIT]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
LDP SYSTEM ON
[On/Off]×
Indicates [On/Off] status of LDP system
WARN REQ
[On/Off] ×
Indicates an ADAS control unit judged warning state (ON/OFF) of LDP system
READY signal
[On/Off] ×
Indicates LDP system settings
Camera lost
[Detect/Deviate/Both] ××Indicates a lane marker detection state judged from a lane marker detection signal
read by the ADAS control unit via ITS communication
(Lane camera unit transmits a lane marker signal via ITS communication)
Shift position
[Off, P, R, N, D, M/T1 -
7] ××
Indicates shift position read from ADAS control unit through CAN communication
(TCM transmits shift position signal through CAN communication)
Turn signal
[OFF/LH/RH/LH&RH] ××Indicates turn signal operation status read from ADAS control unit through CAN
communication (BCM transmits turn indicator signal through CAN communica-
tion)
SIDE G
[G] ××Indicates lateral G acting on the vehicle. This lateral G is judged from a side G
sensor signal read by ADAS control unit via CAN communication
(The ABS actuator and electric unit (control unit) transmits a side G sensor signal
via CAN communication)
STATUS signal
[Stnby/Warn/Cancl/
Off] ×
Indicates a control state of LDP system
Lane unclear
[On/Off] ××Indicates an ON/OFF state of the lane marker. The ON/OFF state is judged from
a detected lane condition signal read by the ADAS control unit via ITS communi-
cation
(The lane camera unit transmits a detected lane condition signal via ITS commu-
nication)
FUNC ITEM
[FUNC1] ×× × × Indicates systems which can be set to ON/OFF by selecting “Driver Assistance”
⇒
“Dynamic Assistance Settings” of the navigation system
FUNC1: Distance Control Assist (DCA), Lane Departure Prevention (LDP)
FUNC ITEM (NV-ICC)
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
FUNC ITEM (NV-
DCA)
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
DCA SELECT
[On/Off] ×× × × Indicates an ON/OFF state of the DCA system. The DCA system can be set to
ON/OFF by selecting
“Driver Assistance” ⇒ “Dynamic Assistance Settings” of the
navigation system
LDP SELECT
[On/Off] ×× × × Indicates an ON/OFF state of LDP system. LDP system can be set to ON/OFF by
selecting “Driver Assistance”
⇒ “Dynamic Assistance Settings” of the navigation
system
BSI SELECT
[On/Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI ICC SELECT
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI DCA SELECT
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
SYS SELECTABILITY
[On/Off] ×× × × Indicates the availability of ON/OFF switching for “Driver Assistance” items re-
ceived from the AV control unit via CAN communication
WARN SYS SW
[On/Off] ×× × ×
Indicates [On/Off] status of warning systems switch
BSW/BSI WARN LMP
[On/Off] ×
Indicates [On/Off] status of BSW warning lamp output
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Revision: 2010 May2011 QX56

DAS-32
< ECU DIAGNOSIS INFORMATION >[ADAS CONTROL UNIT]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed is set Displays the set
vehicle speed
BUZZER O/P Engine running When the buzzer of the following system operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system
On
When the buzzer of the following system not operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system Off
THRTL SENSOR NOTE:
The item is indicated, but not monitored
0.0
ENGINE RPM Engine running Equivalent to ta-
chometer read- ing
WIPER SW Ignition switch ON Wiper not operating Off
Wiper LO operation Low
Wiper HI operation High
YAW R AT E NOTE:
The item is indicated, but not monitored
0.0
BA WARNING Engine running IBA OFF indicator lamp ON
 When IBA system is malfunctioning
 When IBA system is turned to OFF
On
IBA OFF indicator lamp OFF
 When IBA system is normal
 When IBA system is turned to ON Off
STP LMP DRIVE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC brake hold relay is activated On
When ICC brake hold relay is not activated Off
D RANGE SW Engine running When the selector lever is in “D” position or manual
mode
On
When the selector lever is in any position other than “D”
or manual mode Off
NP RANGE SW Engine running When the selector lever is
in “N”, “P” position On
When the selector lever is in any position other than “N”,
“P” Off
PKB SW Ignition switch ON When the parking brake is applied On
When the parking brake is released Off
PWR SUP MONI Engine running Power supply
voltage value of ADAS control unit
VHCL SPD AT While driving Va l u e o f A / T v e -
hicle speed sen- sor signal
THRTL OPENING Engine running Depress accelerator pedal Displays the
throttle position
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS
ADAS CONTROL UNITDAS-37
< ECU DIAGNOSIS INFORMATION > [ADAS CONTROL UNIT]
C
D
E
F
G H
I
J
K L
M B
N P A
DTC Inspection Priority ChartINFOID:0000000006223478
If multiple DTCs are detected simultaneously, che ck them one by one depending on the following DTC inspec-
tion priority chart.
Lane Departure Prevention (LDP) Low-pitched
toneLane departure warning lamp Cancel
Blind Spot Warning (BSW) — BSW warning lamp Cancel System Buzzer Warning lamp/Indicator lamp Description
Priority Detected items (DTC)
1  U1507: LOST COMM (SIDE RDR R)
 U1508: LOST COMM (SIDE RDR L)
2  U1000: CAN COMM CIRCUIT
 U1010: CONTROL UNIT (CAN)
3  C1B00: CAMERA UNIT MALF
 C1F02: APA C/U MALF
 C1A17: ICC SENSOR MALF
 C1B53: SIDE RDR R MALF
 C1B54: SIDE RDR L MALF
Revision: 2010 May2011 QX56

DAS-38
< ECU DIAGNOSIS INFORMATION >[ADAS CONTROL UNIT]
ADAS CONTROL UNIT
DTC Index
INFOID:0000000006223479
NOTE:
 The details of time display are as per the following.
4  C1A01: POWER SUPPLY CIR
 C1A02: POWER SUPPLY CIR 2
 C1A04: ABS/TCS/VDC CIRC
 C1A05: BRAKE SW/STOP L SW
 C1A06: OPERATION SW CIRC
 C1A12: LASER BEAM OFFCNTR
 C1A13: STOP LAMP RLY FIX
 C1A14: ECM CIRCUIT
 C1A16: RADAR STAIN
 C1A18: LASER AIMING INCMP
 C1A2A: ICC SEN PWR SUP CIR
 C1A21: ICC SENSOR HIGH TEMP
 C1A24: NP RANGE
 C1A26: ECD MODE MALF
 C1A27: ECD PWR SUPLY CIR
 C1A33: CAN TRANSMISSION ERR
 C1A34: COMMAND ERROR
 C1A35: APA CIR
 C1A36: APA CAN COMM CIR
 C1A37: APA CAN CIR 2
 C1A38: APA CAN CIR 1
 C1A39: STRG SEN CIR
 C1A40: SYSTEM SW CIRC
 C1B01: CAM AIMING INCMP
 C1B03: CAM ABNRML TMP DETCT
 C1F01: APA MOTOR MALF
 C1F05: APA PWR SUPLY CIR
 U0121: VDC CAN CIR 2
 U0126: STRG SEN CAN CIR 1
 U0235: ICC SENSOR CAN CIRC 1
 U0401: ECM CAN CIR 1
 U0402: TCM CAN CIR 1
 U0415: VDC CAN CIR 1
 U0428: STRG SEN CAN CIR 2
 U1500: CAM CAN CIR 2
 U1501: CAM CAN CIR 1
 U1502: ICC SEN CAN COMM CIR
 U1503: SIDE RDR L CAN CIR 2
 U1504: SIDE RDR L CAN CIR 1
 U1505: SIDE RDR R CAN CIR 2
 U1506: SIDE RDR R CAN CIR 1
 U150B: ECM CAN CIRC 3
 U150C: VDC CAN CIRC 3
 U150D: TCM CAN CIRC 3
 U150E: BCM CAN CIRC 3
 U150F: AV CAN CIRC 3
 U1512: HVAC CAN CIRC3
 U1513: METER CAN CIRC 3
 U1514: STRG SEN CAN CIRC 3
 U1515: ICC SENSOR CAN CIRC 3
 U1516: CAM CAN CIRC 3
 U1517: APA CAN CIRC 3
 U1518: SIDE RDR L CAN CIRC 3
 U1519: SIDE RDR R CAN CIRC 3
 U1520: 4WD CAN CIRC 3
5  C1A03: VHCL SPEED SE CIRC
6  C1A15: GEAR POSITION
7  C1A00: CONTROL UNIT
Priority Detected items (DTC)
Revision: 2010 May2011 QX56

DAS
ADAS CONTROL UNITDAS-39
< ECU DIAGNOSIS INFORMATION > [ADAS CONTROL UNIT]
C
D
E
F
G H
I
J
K L
M B
N P A
- CRNT: A malfunction is detected now
- PAST: A malfunction was detected in the past
 IGN counter is displayed on FFD (Freeze Frame Data).
- 0: The malfunctions that are detected now CAN communication system (U1000, U1010)
- 1 - 39: It increases like 0 → 1 → 2 ··· 38 → 39 after returning to the normal condition whenever the ignition
switch OFF → ON. It returns to 0 when a malfunc tion is detected again in the process.
- If it is over 39, it is fixed to 39 unt il the self-diagnosis results are erased.
Other than CAN communication s ystem (Other than U1000, U1010)
- 1 - 49: It increases like 0 → 1 → 2 ··· 38 → 49 after returning to the normal condition whenever the ignition
switch OFF → ON. It returns to 0 when a malfunc tion is detected again in the process.
- If it is over 49, it is fixed to 49 unt il the self-diagnosis results are erased.
Systems for fail-safe
 A: Vehicle-to-vehicle distance control mode
 B: Conventional (fixed speed) cruise control mode
 C: Intelligent Brake Assist (IBA)
 D: Forward Collision Warning (FCW)
 E: Distance Control Assist (DCA)
 F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
 G: Blind Spot Warning (BSW)
DTC
CONSULT-III display Warning lamp Fail-safe
Reference
CONSULT-III On board
display
ICC system warning lamp
IBA OFF indicator lamp
Lane departure warning lamp BSW warning lamp
System
C1A00 0 CONTROL UNIT ON ON ON ON A, B, C, D, E, F, G DAS-57
C1A01 1 POWER SUPPLY CIR ON ON ON ON A, B, C, D, E, F, GDAS-58
C1A02 2 POWER SUPPLY CIR 2 ON ON ON ON A, B, C, D, E, F, GDAS-58
C1A03 3 VHCL SPEED SE CIRC ON ON ON ON A, B, C, D, E, F, GCCS-87
C1A04 4 ABS/TCS/VDC CIRC ON ON ON A, B, C, D, E, FCCS-89
C1A05 5 BRAKE SW/STOP L SW ON ON ON A, B, C, D, E, FCCS-90
C1A06 6 OPERATION SW CIRC ON ON A, B, E, FCCS-94
C1A12 12LASER BEAM OFFCN-
TR ON ON A, C, D, E
CCS-96
C1A13 13 STOP LAMP RLY FIX ON ON A, B, C, D, E CCS-97
C1A14 14 ECM CIRCUIT ON ON A, B, E, FCCS-103
C1A15 15 GEAR POSITION ON ON ON ON A, B, C, D, E, F, GCCS-104
C1A16 16 RADAR STAIN ON ON A, C, D, ECCS-106
C1A17 17 ICC SENSOR MALF ON ON A, B, C, D, ECCS-108
C1A18 18 LASER AIMING INCMP ON ON A, C, D, ECCS-109
C1A21 21ICC SENSOR HIGH
TEMP ON ON A, B, C, D, E
CCS-111
C1A24 24 NP RANGE ON ON ON ON A, B, C, D, E, F, G CCS-113
C1A26 26 ECD MODE MALF ON ON A, B, C, D, ECCS-115
C1A27 27 ECD PWR SUPLY CIR ON ON A, B, C, D, ECCS-116
C1A33 33CAN TRANSMISSION
ERR ON A, B, E
CCS-118
Revision: 2010 May2011 QX56

DAS-40
< ECU DIAGNOSIS INFORMATION >[ADAS CONTROL UNIT]
ADAS CONTROL UNIT
C1A34 34 COMMAND ERROR ON A, B, E
CCS-119
C1A35 35 APA CIR ON A, ECCS-120
C1A36 36 APA CAN COMM CIR ON A, ECCS-121
C1A37 133 APA CAN CIR 2 ON A, B, ECCS-122
C1A38 132 APA CAN CIR 1 ON A, B, ECCS-123
C1A39 39 STRG SEN CIR ON ON ON A, B, C, D, E, GCCS-124
C1A40 40 SYSTEM SW CIRC ON C, DCCS-126
C1A2A 80 ICC SEN PWR SUP CIR ON ON A, C, D, E CCS-117
C1B00 81 CAMERA UNIT MALF ON FDAS-361
C1B01 82 CAM AIMING INCMP ON FDAS-363
C1B03 83CAM ABNRML TMP DE-
TCT BLINK F
DAS-365
C1B53 84 SIDE RDR R MALF ON G DAS-482
C1B54 85 SIDE RDR L MALF ON GDAS-483
C1F01 91 APA MOTOR MALF ON A, ECCS-129
C1F02 92 APA C/U MALF ON A, ECCS-130
C1F05 95 APA PWR SUPLY CIR ON A, ECCS-131
NO DTC IS
DETECTED.
FURTHER TESTING
MAY BE RE-
QUIRED 55
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED ———— — —
U0121 127 VDC CAN CIR 2 ON ON ON ON A, B, C, D, E, F, G CCS-133
U0126 130 STRG SEN CAN CIR 1 ON ON ON A, B, C, D, E, GCCS-135
U0235 144 ICC SENSOR CAN
CIRC 1 ON ON A, B, C, D, E
CCS-137
U0401 120 ECM CAN CIR 1 ON ON ON A, B, E, F, G CCS-138
U0402 122 TCM CAN CIR 1 ON ON ON ON A, B, C, D, E, F, GCCS-139
U0415 126 VDC CAN CIR 1 ON ON ON ON A, B, C, D, E, F, GCCS-141
U0428 131 STRG SEN CAN CIR 2 ON ON ON A, B, C, D, E, GCCS-143
U1000NOTE100 CAN COMM CIRCUIT ON ON ON ON A, B, C, D, E, F, GDAS-59
U1010 110 CONTROL UNIT (CAN) ON ON ON ON A, B, C, D, E, F, G DAS-60
Systems for fail-safe
 A: Vehicle-to-vehicle distance control mode
 B: Conventional (fixed speed) cruise control mode
 C: Intelligent Brake Assist (IBA)
 D: Forward Collision Warning (FCW)
 E: Distance Control Assist (DCA)
 F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
 G: Blind Spot Warning (BSW)
DTC
CONSULT-III display Warning lamp Fail-safe
Reference
CONSULT-III On board
display
ICC system warning lamp
IBA OFF indicator lamp
Lane departure warning lamp
BSW warning lamp
System
Revision: 2010 May2011 QX56
