P1089, P1092 VVEL CONTROL SHAFT POSITION SENSOR
EC-389
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace.
8.REPLACE VVEL CONTROL MODULE
1. Replace VVEL control module.
2. Perform additional service when replacing VVEL control module. Refer to EC-144, "
Work Procedure".
>> GO TO 9.
9.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC Confirmation Procedure. See EC-387, "
DTC Logic".
Is the DTC P1089 or P1092 displayed again?
YES >> GO TO 10.
NO >> INSPECTION END
10.REPLACE VVEL ACTUATOR LADDER ASSEMBLY
Replace VVEL actuator ladder assembly. Refer to EM-75, "
Removal and Installation".
>> INSPECTION END
