2011 INFINITI QX56 BATTERY

DLN-4
Commercial Service Tools .....................................125
SYMPTOM DIAGNOSIS ............................126
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... .
126
NVH Troubleshooting Chart ................................ ..126
PERIODIC MAINTENANCE ..................... ..127
FRONT PROPELLER SHAFT ........................ .127
Inspection ............................................................ ..127
REMOVAL AND INSTALLATION ..............128
FRONT PROPELLER SHAFT ........................ .128
Exploded View ..................................................... ..128
Removal and Installation .......................................129
Disassembly and Assembly ...................................129
Inspection ..............................................................131
SERVICE DATA AND SPECIFICATIONS
(SDS) .............. ............................................
133
SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................... .
133
General Specification .......................................... ..133
Propeller Shaft Runout ..........................................133
Journal Axial Play ..................................................133
REAR PROPELLER SHAFT: 2F P26
SYMPTOM DIAGNOSIS .. ..........................
134
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... .
134
NVH Troubleshooting Chart ................................ ..134
PERIODIC MAINTENANCE ..................... ..135
REAR PROPELLER SHAFT .......................... .135
Inspection ............................................................ ..135
REMOVAL AND INSTALLATION ..............136
REAR PROPELLER SHAFT .......................... .136
Exploded View ..................................................... ..136
Removal and Installation .......................................137
Disassembly and Assembly ...................................137
Inspection ..............................................................139
SERVICE DATA AND SPECIFICATIONS
(SDS) .............. ............................................
140
SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................... .
140
General Specification .......................................... ..140
Propeller Shaft Runout ..........................................140
Journal Axial Play ..................................................140
REAR PROPELLER SHAFT: 2S1410
SYMPTOM DIAGNOSIS .. ..........................
141
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... ..
141
NVH Troubleshooting Chart ................................. .141
PERIODIC MAINTENANCE ......................142
REAR PROPELLER SHAFT .......................... ..142
Inspection ............................................................. .142
REMOVAL AND INSTALLATION .............143
REAR PROPELLER SHAFT .......................... ..143
Exploded View ..................................................... .143
Removal and Installation .......................................144
Disassembly and Assembly ..................................144
Inspection ..............................................................146
SERVICE DATA AND SPECIFICATIONS
(SDS) ........ .................................................
147
SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................. ..
147
General Specification ........................................... .147
Propeller Shaft Runout ..........................................147
Journal Axial Play .................................................147
FRONT FINAL DRIVE: R180A
PRECAUTION ............... ............................
148
PRECAUTIONS .............................................. ..148
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect ................................ .
148
Precaution for Servicing Front Final Drive ............148
PREPARATION .........................................149
PREPARATION .............................................. ..149
Special Service Tool ............................................ .149
Commercial Service Tool ......................................151
SYSTEM DESCRIPTION ..........................153
STRUCTURE AND OPERATION ................... ..153
Sectional View ..................................................... .153
SYMPTOM DIAGNOSIS ...........................154
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... ..
154
NVH Troubleshooting Chart ................................. .154
PERIODIC MAINTENANCE ......................155
FRONT DIFFERENTIAL GEAR OIL .............. ..155
Inspection ............................................................. .155
Draining .................................................................155
Refilling .................................................................155
REMOVAL AND INSTALLATION .............156
FRONT OIL SEAL .......................................... ..156
Exploded View ..................................................... .156
Revision: 2010 May2011 QX56

DLN-6
< PRECAUTION >[TRANSFER: ATX90A]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint S
ystem (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006222209
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
 Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
 When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation after Battery Disconnect
INFOID:0000000006222210
NOTE:
 Before removing and installing any control units, first tu rn the push-button ignition switch to the LOCK posi-
tion, then disconnect bot h battery cables.
 After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
 Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnos is according to self-diagnosis results.
For vehicle with steering lock unit, if the battery is disconnected or discharged, the steering wheel will lock and
cannot be turned.
If turning the steering wheel is required with the bat tery disconnected or discharged, follow the operation pro-
cedure below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position. (At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock wi ll remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
Revision: 2010 May2011 QX56

PRECAUTIONSDLN-7
< PRECAUTION > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button ignition switch is turned to LOCK position.)
6. Perform self-diagnosis check of a ll control units using CONSULT-III.
Service Notice or Precautions for TransferINFOID:0000000006222211
CAUTION:
 Use Genuine NISSAN Transfer Fluid. Refer to MA-10, "
Fluids and Lubricants".
 Never reuse transfer fluid, once it has been drained.
 Check the fluid level or repl ace the fluid only with the vehicle parked on level ground.
 During removal or installati on, keep inside of transfer clear of dust or dirt.
 Replace all tires at the same time. Always use tir es of the proper size and the same brand and pat-
tern. Fitting improper size and unusually worn tires applies excessive force to vehicle mechanism
and can cause longitudinal vibration.
 Disassembly should be done in a clean work area, it is preferable to work in dustproof area.
 Before proceeding with disassembly, thoroughly clean the transfer. It is important to prevent the
internal parts from becoming contamin ated by dirt or other foreign matter.
 All parts should be carefully cl eaned with a general purpose, non-flammable solvent before inspec-
tion or reassembly.
 Check for the correct installation status prior to removal or disassembly. If matching marks are
required, be certain they do not interfere wit h the function of the parts when applied.
 Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace
them with a new ones if necessary.
 Gaskets, seals and O-rings should be replaced any time the transfer is disassembled.
 In principle, tighten bolts or nu ts gradually in several steps workin g diagonally from inside to out-
side. If tightening sequence is specified, use it.
 Observe the specified torque when assembling.
 Clean and flush the parts su fficiently and blow-dry them.
 Be careful not to damage sliding surfaces and mating surfaces.
 Clean inner parts with lint-free cloth or towels . Do not use cotton work gloves and rags to prevent
adhering fibers.
Revision: 2010 May2011 QX56

TRANSFER CONTROL UNITDLN-25
< ECU DIAGNOSIS INFORMATION > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
HI-LO POSI SEN 3 4WD mode: AUTO or 4H ON
4WD mode: Shifting OFF
4WD mode: 4L OFF
HI-LO POSI SEN 1 4WD mode: AUTO or 4H ON
4WD mode: Shifting ON
4WD mode: 4L OFF
LOCK POSI SEN When lock sleeve is opening OPEN
When lock sleeve locking LOCK
When transfer lock position sensor
signal circuit is short. (Battery
short) BAT
When transfer lock position sensor is unlearned. UNLEAN
When the temperature of transfer lock position sensor is high. HI TMP
When transfer lock position sensor is malfunctioning. ERROR
When transfer lock position sensor signal circuit is short. (Ground
short) GND
AT P I N D ATP lamp: ON ON
AT P l a m p : O F F O F F
4WD FAIL LAMP 4WD warning lamp: ON ON
4WD warning lamp: OFF OFF
4WD MODE IND 4WD shift switch: AUTO AUTO
4WD shift switch: 4H LOCK
4WD shift switch: 4L 4L
MOTOR DRIVE B When transfer motor is driving in reversal. (100% duty controlled) HI
When transfer motor is driving or stopping. LO
When transfer motor is driving in reversal. (PWM output) PWM
MOTOR DRIVE A When transfer motor is driving. (100% duty controlled) HI
When transfer motor is driving in reversal or stopping. LO
When transfer motor is driving. (PWM output) PWM
FLUID TEMP SE The temperature of transfer fluid is 20 – 80 °C. Approx. 1.1 – 0.3 V
MOTOR TEMP The temperature of transfer motor is 20 – 80 °C. Approx. 1.1 – 0.3 V
C/U POWER SUP Always Battery voltage
MOTOR POWER SUP Always Battery voltage
ROTARY POSI SEN 4WD mode: AUTO
A/T shift selector: DDepress the accelerator pedal several
times.
Value is changing
THRTL POS SEN When depressing accelerator pedal
(Value rises gradually in response to throttle position) 0 – 100 %
AT R SPEED Vehicle stopped 0.00 km/h (0.00 mph)
Vehicle driving (4WD mode: AUTO)
CAUTION:
Check air pressure of tire under standard condition. Approx. equal to the indication
on speedometer (inside of ±10
%)
T/M GEAR A/T shift selector: D
Vehicle driving 1
2
3
4
5
6
7
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

TRANSFER CONTROL UNITDLN-27
< ECU DIAGNOSIS INFORMATION > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
7
(Y) Ground
Transfer fluid tempera-
ture sensor power supply Input Engine running 0 – 5V
9
(G) Ground Transfer internal speed
sensor (GND) —Always 0 V
10
(Y/G) Ground Transfer internal speed
sensor (IMP)
Input IGN ON Transfer motor driving
11
(V) Ground 4WD shift SW (4Lo) Input IGN ON 4WD shift switch: 4L Battery voltage
4WD shift switch: Except
4L
0 V
12
(L) —CAN-H Input/
Output ——
13
(P) —CAN-L
Input/
Output ——
14
(W/R) Ground 4WD shift SW (AUTO) Input IGN ON 4WD shift switch: AUTO Battery voltage
4WD shift switch: Except
AUTO
0 V
15
(P/B) Ground Transfer rotary position
sensor (PWM)
Input IGN ON
16
(LG) Ground
Transfer rotary position
sensor (GND) —Always 0 V
17
(W/L) Ground Transfer lock position
sensor power supply InputIGN ON 5V
10 seconds or more later after ignition
switch turned OFF 0V
18
(BR/Y) Ground Transfer rotary position
sensor power supply
InputIGN ON 5V
10 seconds or more later after ignition
switch turned OFF 0V
20
(GR) Ground
Transfer control unit pow-
er supply Input Always Battery voltage
25
(P/L) Ground Hi-Lo position sensor 3 Input/
Output Engine
running
(Never
drive the
vehicle.) 4WD mode: AUTO or 4H 0 V
4WD mode: Shifting 5 V
4WD mode: 4L 5 V
28
(W) Ground
Transfer motor tempera-
ture sensor power supply InputIGN ON 0 – 5V
IGN OFF 0V
Te r m i n a l N o .
(Wire color) Description
Condition Value (Approx.)
+ - Signal name Input/
Output
JPDIE0267GB
JPDIE0268GB
Revision: 2010 May2011 QX56

DLN-28
< ECU DIAGNOSIS INFORMATION >[TRANSFER: ATX90A]
TRANSFER CONTROL UNIT
CAUTION:
When using circuit tester to measure voltage for in
spection, be sure not to extend forcibly any con-
nector terminals.
Fail-SafeINFOID:0000000006222228
 If any malfunction occurs in 4WD electrical system, and control unit detects the malfunction, 4WD warning
lamp on combination meter turns ON to indicate system malfunction.
 When 4WD warning lamp is ON, vehicle changes to rear-wheel drive or shifts to 4-wheel drive (front-wheels
still have some driving torque).
29
(LG/R) Ground Hi-Lo position sensor 2
Input/
Output Engine
running
(Never
drive the
vehicle.)
Always 0 V
30
(R/B) Ground Transfer lock position
sensor (GND) —Always 0 V
31
(L/O) Ground Transfer internal speed
sensor (DIR)
Input IGN ONWhen changing the trans-
fer motor rota
tion direc-
tion.
32
(BR/R) Ground IGN SW Input IGN ON Battery voltage
IGN OFF 0V
35
(R) Ground 4WD shift SW (4H) Input IGN ON 4WD shift switch: 4H Battery voltage
4WD shift switch: Except
4H
0 V
36
(L/R) Ground Transfer fluid tempera-
ture sensor (GND)
—Always 0 V
38
(G/O) Ground
Transfer lock position
sensor signal Input IGN ON
39
(R/W) Ground Transfer internal speed
sensor power supply
InputIGN ON 8 V
IGN OFF 0V
41
(W/R) Ground Transfer control actuator
power supply Input Always Battery voltage
43
(G/R) Ground Motor drive B Input/
Output Transfer motor driving 0V - Battery voltage
44
(B) Ground GND — Always 0 V
45
(G/Y) Ground Motor drive A Input/
Output Transfer motor driving 0V - Battery voltage
46
(B) Ground Transfer control actuator
(GND)
—Always 0 V
Te r m i n a l N o .
(Wire color) Description
Condition Value (Approx.)
+ - Signal name Input/
Output
JPDIE0269GB
JPDIE0268GB
Revision: 2010 May2011 QX56

TRANSFER CONTROL UNITDLN-29
< ECU DIAGNOSIS INFORMATION > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DTC Inspection Priority ChartINFOID:0000000006222229
If some DTCs are displayed at the same time, per form inspections one by one based on the following priority
chart.
DTC IndexINFOID:0000000006222230
Priority Detected items (DTC)
1  U1000 CAN COMM CIRCUIT
 U1010 CONTROL UNIT (CAN)
2  P1802 CONTROL UNIT 1
 P1803 CONTROL UNIT 2
 P1804 CONTROL UNIT 3
 P1809 CONTROL UNIT 4
 P180C SEN POWER SUPPLY (5V)
 P180E SEN POWER SUPPLY (8V)
 P1811 BATTERY VOLTAGE
 P181B INCOMP SELFSHUT
 P181C MOTOR POWER SUPPLY
 P181F INCOMP CALIBRATION
3  P1807 VECL SPEED SEN-AT
 P1808 VECL SPEED SEN-ABS
 P1816 PNP SW/CIRC
 P181E ST ANGLE SEN SIG
 P1820 ENGINE SPEED SIG
 P1829 THROTTLE POSI SEN
 P1830 ABS OP SIG
 P1831 VDC OP SIG
 P1832 TCS OP SIG
4  P180D ROTARY POSITION SEN
 P1813 4WD MODE SW
 P181A MOTOR TEMP SEN
 P1826 OIL TEMP SEN
 P182A HI-LO POSITION SEN
 P182B LOCK POSITION SEN
5  P180F MOTOR SYSTEM
 P1817 SHIFT ACTUATOR
DTC Display Items Reference
P1802 CONTROL UNIT 1 DLN-51, "
DTC Logic"
P1803 CONTROL UNIT 2DLN-51, "DTC Logic"
P1804 CONTROL UNIT 3DLN-51, "DTC Logic"
P1807 VHCL SPEED SEN-ATDLN-52, "DTC Logic"
P1808 VHCL SPEED SEN-ABSDLN-53, "DTC Logic"
P1809 CONTROL UNIT 4DLN-51, "DTC Logic"
P180C SEN POWER SUPPLY (5V) DLN-54, "DTC Logic"
P180D ROTARY POSITION SENDLN-57, "DTC Logic"
P180E SEN POWER SUPPLY (8V)DLN-59, "DTC Logic"
P180F MOTOR SYSTEMDLN-61, "DTC Logic"
P1811 BATTERY VOLTAGEDLN-64, "DTC Logic"
P1813 4WD MODE SW DLN-67, "DTC Logic"
P1816 PNP SW/CIRCDLN-69, "DTC Logic"
P1817 SHIFT ACTUATORDLN-70, "DTC Logic"
P181A MOTOR TEMP SEN DLN-72, "DTC Logic"
P181B IMCOMP SELFSHUTDLN-74, "DTC Logic"
Revision: 2010 May2011 QX56

DLN-64
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P1811 POWER SUPPLY CIRCUIT
FOR TRANSFER CONTROL UNIT
P1811 POWER SUPPLY CIRCUIT FOR TRANSFER CONTROL UNIT
DescriptionINFOID:0000000006222260
Supplies power to transfer control unit.
DTC LogicINFOID:0000000006222261
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P1811” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-64, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222262
1.CHECK TRANSFER CONTROL UNIT POWER SUPPLY (1)
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the voltage between transfer control unit harness connector and ground.
4. Turn the ignition switch ON. CAUTION:
Never start the engine.
5. Check the voltage between transfer control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK TRANSFER CONTROL UNIT POWER SUPPLY (2)
1. Turn the ignition switch OFF.
2. Check the 10A fuse (#34).
3. Check the harness for open or short between transfe r control unit harness connector No.20 terminal and
10A (#34).
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit. Refer to PG-11, "Wiring Diagram - BAT-
TERY POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
DTC Display item Malfunction detected condition Possible cause
P1811 BATTERY VOLTAGE When transfer control unit power supply
is lower or higher than normalMalfunction of transfer control unit pow-
er supply circuit (open or short)
Transfer control unit
—Voltage
Connector Terminal
E59 20 Ground Battery voltage
Transfer control unit —Voltage
Connector Terminal
E59 20 Ground Battery voltage
Revision: 2010 May2011 QX56
