2011 CHEVROLET COLORADO Owners Manual

Black plate (1,1)Chevrolet Colorado Owner Manual - 2011
Infotainment System 7-1
Infotainment
System
Introduction
Introduction . . . . . . . . . . . . . . . . . . . 7-1
Theft-Deterrent Feature . . . . . . . 7-2
Operation . . . . . . . . . . . . . . . . . . . . . 7-3
Radio
AM-FM Radio . . . . . . . . . . . . . . . . . 7-7
Satellite Radio . . . . . . . . . . . . . . . 7-11
Radio Reception . . . . . . . . . . . . . 7-13
Fixed Mast Antenna . . . . . . . . . 7-14
Satellite Radio Antenna . . . . . . 7-14
Audio Players
CD Player . . . . . . . . . . . . . . . . . . . 7-14
Phone
Bluetooth . . . . . . . . . . . . . . . . . . . . 7-20
Introduction
Determine which radio the vehicle
has and read the following pages to
become familiar with its features.
{WARNING
Taking your eyes off the road for
extended periods could cause a
crash resulting in injury or death
to you or others. Do not give
extended attention to
entertainment tasks while driving.
This system provides access to
many audio and non audio listings. To minimize taking your eyes off the
road while driving, do the following
while the vehicle is parked:
.Become familiar with the
operation and controls of the
audio system.
.Set up the tone, speaker
adjustments, and preset radio
stations.
For more information, see Defensive
Driving on page 9‑2.

Black plate (2,1)Chevrolet Colorado Owner Manual - 2011
7-2 Infotainment System
Notice:Contact your dealer
before adding any equipment.
Adding audio or communication
equipment could interfere with
the operation of the vehicle's
engine, radio, or other systems,
and could damage them. Follow
federal rules covering mobile
radio and telephone equipment.
Notice: The chime signals related
to safety belts, parking brake, and
other functions of your vehicle
operate through the radio/
entertainment system. If that
equipment is replaced or
additional equipment is added to
your vehicle, the chimes may not
work. Make sure that replacement
or additional equipment is
compatible with your vehicle
before installing it. See
Accessories and Modifications on
page 10‑4. The vehicle has Retained
Accessory Power (RAP). With RAP,
the audio system can be played
even after the ignition is turned off.
See
Retained Accessory Power
(RAP) on page 9‑30 for more
information.
Theft-Deterrent Feature
Non-RDS Radios
TheftLock®is designed to
discourage theft of your vehicle's
radio. The feature works
automatically by learning a portion
of the Vehicle Identification
Number (VIN). If the radio is moved
to a different vehicle, it does not
operate and LOC displays.
With TheftLock activated, the radio
does not operate if stolen.
RDS Radios
TheftLock is designed to discourage
theft of your vehicle's radio. The
feature works automatically by
learning a portion of the Vehicle
Identification Number (VIN). If the
radio is moved to a different vehicle,
it does not operate and LOCKED
displays.
When the radio and vehicle are
turned off, the blinking red light
indicates that TheftLock is armed.
With TheftLock activated, the radio
does not operate if stolen.

Black plate (3,1)Chevrolet Colorado Owner Manual - 2011
Infotainment System 7-3
Operation
AM-FM Radio

Black plate (4,1)Chevrolet Colorado Owner Manual - 2011
7-4 Infotainment System
Radio with CD (MP3/WMA)
Playing the Radio
AM-FM Radio
PWR (Power):Press to turn the
system on and off.
VOL (Volume): Turn to increase or
to decrease the volume. RCL (Recall) :
Press to switch the
display between the radio station
frequency, band, and the time.
When the ignition is off, press to
display the time.
Radio with CD (MP3/WMA)
PWR (Power): Press to turn the
system on and off.
oVOLp(Volume): Turn to
increase or to decrease the volume.
DISPL (Display): When the ignition
is turned off, press to display
the time.
For RDS, press the DISPL knob to
change what displays while using
RDS. The display options are
station name, RDS station
frequency, PTY (program type), and
the name of the program (if
available).
For XM™ (if equipped), press the
DISPL knob while in XM mode to
retrieve four different categories of
information related to the current
song or channel: Artist, Song Title,
Category or PTY, Channel Number/
Channel Name.
To change the default on the
display, press the DISPL knob until
you see the desired display, then
press and hold this knob for
two seconds and the radio
beeps once.

Black plate (5,1)Chevrolet Colorado Owner Manual - 2011
Infotainment System 7-5
AUTO VOL (Automatic Volume):
Automatic volume automatically
adjusts the audio system to make
up for road and wind noise while
driving. The volume level should
always sound the same while
driving.
Set the volume at the desired level.
Press to select LOW, MEDIUM, and
HIGH. AVOL displays. Each higher
setting allows for higher volume
compensation at faster vehicle
speeds.
NONE displays if the radio cannot
determine the vehicle speed. To turn
automatic volume off, press until
OFF displays.
Setting the Tone (Bass/Treble)
AM-FM Radio
To adjust the bass or treble:
1. Press and release the AUDIObutton until BAS (bass) or TRE
(treble) displays. 2. Press and hold the
worx
button to increase or to
decrease the tone.
To adjust the bass or treble to the
center position:
1. Press and release the AUDIO button until BAS (bass) or TRE
(treble) displays.
2. Press and hold the AUDIO button for more than
two seconds until a beep
sounds.
To adjust both tone controls and
both speaker controls to the middle
position:
1. Exit out of audio mode by pressing another button, causing
the radio to perform that function
or wait five seconds for the
display to return to time of day.
2. Press and hold AUDIO for more than two seconds until a beep
sounds. CEN (center) displays. Radio with CD (MP3/WMA)
To adjust the bass or treble:
1. Press and release the AUDIO
knob until BASS (bass) or TREB
(treble) displays.
2. Turn the AUDIO knob to increase or to decrease
the tone.
To adjust the bass/treble to the
middle position, press and hold the
AUDIO knob. The radio produces
one beep and adjusts the display
level to the middle position.
To adjust all tone and speaker
controls to the middle position, push
and hold the AUDIO knob when no
tone or speaker control displays.
ALL CENTERED displays and a
beep sounds.
AUTO EQ (Automatic
Equalization): Press to select
customized equalization settings
designed for country/western, jazz,
talk, pop, rock, and classical.

Black plate (6,1)Chevrolet Colorado Owner Manual - 2011
7-6 Infotainment System
To return to the manual mode, press
the AUTO EQ button until CUSTOM
displays. Then manually adjust the
bass/treble, using the AUDIO knob.
Adjusting the Speakers
(Balance/Fade)
Fade may not be available if the
vehicle is a regular cab model.
AM-FM Radio
To adjust balance or fade:
1. Press and release the AUDIObutton until BAL (balance) or
FAD (fade) displays.
2. Press and hold the
worx
button to increase or to
decrease the level.
To adjust the balance or fade to the
center position:
1. Press and release the AUDIO button until BAL (balance) or
FAD (fade) displays. 2. Press and hold the AUDIO
button for more than
two seconds until a beep
sounds.
To adjust both speaker controls and
both tone controls to the middle
position:
1. Exit out of audio mode by pressing another button, causing
the radio to perform that function
or wait five seconds for the
display to return to time of day.
2. Press and hold AUDIO for more than two seconds until a beep
sounds. CEN (center) displays.
Radio with CD (MP3/WMA)
To adjust the balance or fade:
1. Press and release the AUDIO knob until BAL (balance) or
FADE (fade) displays.
2. Turn the AUDIO knob to increase or to decrease the
level. To adjust the balance or fade to the
middle position:
1. Press and release the AUDIO
knob until BAL (balance) or
FADE (fade) displays.
2. Press and hold the AUDIO knob until one beep sounds.
To adjust all tone and speaker
controls to the middle position, push
and hold the AUDIO knob when no
tone or speaker control displays.
ALL CENTERED displays and a
beep sounds.
Radio Messages
AM-FM Radio
CAL (Calibration Error): The
audio system has been calibrated
for the vehicle from the factory.
If CAL displays it means that the
radio has not been configured
properly for the vehicle and it must
be returned to your dealer for
service.

Black plate (7,1)Chevrolet Colorado Owner Manual - 2011
Infotainment System 7-7
LOC (Locked):This message
displays when the THEFTLOCK®
system has locked up. Take the
vehicle to your dealer for service.
If any error occurs repeatedly or if
an error cannot be corrected,
contact your dealer.
Radio with CD (MP3/WMA)
CAL ERR (Calibration Error): The
audio system has been calibrated
for the vehicle from the factory.
If CAL ERR displays it means that
the radio has not been configured
properly for the vehicle and it must
be returned to your dealer for
service.
LOCKED: This message displays
when the THEFTLOCK
®system has
locked up. Take the vehicle to your
dealer for service.
If any error occurs repeatedly or if
an error cannot be corrected,
contact your dealer.
Radio
AM-FM Radio
Finding a Station
AM-FM Radio
AM FM: Press to switch between
FM1, FM2, or AM.
TUNE : Turn to select radio
stations.
oSEEK: Press to go to the
previous station and stay there.
To scan stations, press and hold
o
SEEK for two seconds until a beep
sounds. The radio goes to a station,
plays for a few seconds, then goes
to the next station. Press
oSEEK
again to stop scanning.
To scan preset stations, press
and hold
oSEEK for more than
four seconds until two beeps sound. The radio goes to the first preset
station, plays for a few seconds,
then goes to the next preset station.
Press
oSEEK again to stop
scanning presets.
SEEK
p: Press to go to the next
station and stay there.
To scan stations, press and hold
SEEK
pfor two seconds until a
beep sounds. The radio goes to a
station, plays for a few seconds,
then goes to the next station. Press
SEEK
pagain to stop scanning.
To scan preset stations, press
and hold SEEK
pfor more than
four seconds until two beeps sound.
The radio goes to the first preset
station stored on the pushbuttons,
plays for a few seconds, then goes
to the next preset station. Press
SEEK
pagain to stop scanning
presets.

Black plate (8,1)Chevrolet Colorado Owner Manual - 2011
7-8 Infotainment System
Radio with CD (MP3/WMA)
BAND:Press to switch between
FM1, FM2, AM, or XM1 or XM2 (if
equipped). The selection displays.
qTUNEr: Turn to select radio
stations.
qSEEKr: Press to go to the
previous or next station and stay
there.
qSCANr: Press and hold for
more than two seconds, SCAN
displays and the radio beeps once.
The radio goes to a station, plays
for a few seconds, then goes to the
next station. Press
qorragain, to
stop scanning presets.
To scan preset stations, press
and hold
qorrfor more than
four seconds, PSCN displays and
the radio beeps once. The radio
goes to a preset station, plays for a
few seconds, then goes to the next
preset station. Press
qorragain,
to stop scanning presets.
Radio Data System (RDS)
The Radio with CD (MP3/WMA) has
an RDS system. RDS features are
available for use only on FM
stations that broadcast RDS
information.
With RDS, the radio can do the
following:
.Seek to stations broadcasting
the selected type of
programming.
.Receive announcements
concerning local and national
emergencies.
.Display messages from radio
stations.
.Seek to stations with traffic
announcements.
This system relies upon receiving
specific information from these
stations and only works when the
information is available. In rare
cases, a radio station could
broadcast incorrect information that causes the radio features to work
improperly. If this happens, contact
the radio station.
While the radio is tuned to an RDS
station, the station name or call
letters display instead of the
frequency. RDS stations can also
provide the time of day, a program
type (PTY) for current programming,
and the name of the program being
broadcast.
RDS Messages
ALERT!:
The Alert feature warns of
local or national emergencies. When
an alert announcement comes on
the current radio station, ALERT!
displays. The announcement is
heard, even if the volume is low or a
CD is playing. If a CD is playing,
play stops during the
announcement. Alert
announcements cannot be
turned off.
ALERT! is not affected by tests of
the emergency broadcast system.
This feature is not supported by all
RDS stations.
