2010 Peugeot 207 Dag Owner's Manual

18
PETROL - DIESEL, MANUAL, 2 TRONIC OR AUTOMATIC GEARBOX
INSTRUMENT PANELS
Panel which groups together the vehicle
operation dials and indicator lamps.
5. Screen.

6. Display zero reset button.
Resets the selected function to zero (trip distance recorder or service in-
dicator).

7. Instrument panel lighting button.
Adjusts the brightness of the lighting of the instruments and controls.

8. "
2 Tronic
" or automatic gearbox.
Indicates the programme selected and the gear engaged.
Dials

1. Rev counter.
Indicates the speed of rotation of the engine (x 1000 rpm).

2. Fuel gauge.
Indicates the quantity of fuel remain- ing in the tank.

3. Coolant temperature.
Indicates the temperature of the en- gine coolant (° Celsius).

4. Speedometer.
Indicates the current speed of the moving vehicle (mph or km/h).
A. Speed limiter.
or
Cruise control.
(mph or km/h)

B. Trip distance recorder.
(miles or km)

C. Service indicator.
(miles or km) then,
Engine oil level indicator.
then
Distance recorder.
(miles or km)
These three functions are displayed in succession when the ignition is
switched on.
Screen
For more information, refer to the sec-
tion which corresponds to the function
and to the display associated with it.

!
19
Indicator and warning lamps
Visual indicators informing the driver that a system is in operation (operation or
deactivation indicator lamps) or of the occurrence of a fault (wa rning lamp).
When the ignition is switched on

Certain warning lamps come on for a few seconds whe n the vehicle's ignition is switched on.
When the engine is started, these same warning lam ps should switch off.
If they remain on, before moving off, refer to the information on the warning lamp concerned.
Associated warnings
The switching on of certain warning lamps may be accompanied b y an audible
signal and a message on the multifunction screen. The warning lamps may come on
continuously (fi xed) or fl ash.
Certain warning lamps may come
on in two different modes. Only by
relating the type of lighting to the
operating status of the vehicle can
it be ascertained whether the situ-
ation is normal or whether a fault
has occurred.
Operation indicator lamps
If one of the following indicator lamps comes on, this confi rms that the correspond-
ing system has come into operation.

Warning lamp is on Cause Action/Observations

Left-hand
direction
indicato
r fl ashing with
buzzer. The lighting stalk is pushed
down.


Right-hand
direction
indicator fl ashing with
buzzer. The lighting stalk is pushed
up.


Dipped beam
headlamps fi xed. The lighting stalk is in the
"Dipped beam headlamps"
position. Turn the control to the desired position

Main beam
headlamps fi xed. The lighting stalk is pulled
towards you. Pull the stalk to return to dipped beam
headlamps.

20

Warning lamp is on Cause Action/Observations

Front
foglamps fi xed. The front foglamps are
switched on. Turn the ring on the stalk rearwards twice to
switch off the front foglamps.

Rear
foglamps fi xed. The rear foglamps are
switched on. Turn the ring on the stalk rearwards to switch off
the rear foglamps.

Diesel engine
pre-heating fi xed. The ignition switch is at the
2nd position (ignition on). Wait until the warning lamp has switched off before
starting.
The duration for which the warning lamp is on is d etermined
by the climatic conditions.

Parking brake fi xed. The parking brake is
applied or not properly
released. Release the parking brake to switch off the
warning lamp, keeping your foot on the brake
pedal.
Observe the safety recommendations.
For further information on the parking brake, refer
to the "Driving" section.

21
Deactivation warning lamps
If one of the following warning lamps comes on, this confi rms that the corresponding system has been switched off intentionally.

Warning lamp is on Cause Action/Observations

Passenger's
airbag
system fi xed. The control, located in the
glove box, is set to the
OFF
position.
The passenger's front
airbag is deactivated.
In this case you can install
a "rear facing" child seat. Set the control to the
ON position to activate the
passenger's front airbag. In this case, do not fi t a
child seat in the rear-facing position.
The passenger's airbag system is put into service
automatically when the vehicle is started
( ON position).

ESP/ASR fi xed. The button, located
in the centre of
the dashboard,
is pressed. Its
indicator lamp is on.
The ESP/ASR is
deactivated.
ESP: electronic stability
programme.
ASR: anti-skid regulation. Press the button to activate the ESP/ASR. Its
indicator lamp switches off.
From approximately 30 mph (50 km/h), the
system is reactivated automatically.
The ESP/ASR system is activated automatically
when the vehicle is started.

!
22
Warning lamps
When the engine is running or the vehicle is
being driven, the switching on of one of the fol-
lowing warning lamps indicates a fault which
requires action on the part of the driver. Any fault resulting in the switching on of a warning lamp must be investigated
further by reading the associated message on the multifunction screen.
If you encounter any problems, do not hesitate to contact a PEUGEOT dealer.

Warning lamp is on Cause Action/Observations

STOP
fi xed, associated
with another warning
lamp and
accompanied by
an audible signal.
It is associated with the
braking system or the
engine coolant temperature. Stop as soon as it is safe to do so.
Park, switch off the ignition and call a PEUGEOT
dealer.

Service temporarily.
A minor fault has occurred
for which there is no
specifi c warning lamp. Identify the fault by reading the message shown
on the screen, such as, for example:
- the engine oil level,
- the screenwash level,
- the remote control battery,
- saturation of the particle emission fi lter
(Diesel).
For any other faults, contact a PEUGEOT dealer.
fi xed. A major fault has occurred
for which there is no
specifi c warning lamp. Identify the fault by reading the message shown
on the screen and contact a PEUGEOT dealer.


Braking fi xed.
The braking system
fl uid level has dropped
signifi cantly. Top up with brake fl uid recommended by
PEUGEOT.
If the problem persists, have the system checked
by a PEUGEOT dealer.
+
fi xed, associated with the ABS
warning lamp. The electronic brake force
distribution (EBFD) system
has a fault. Have it checked by a PEUGEOT dealer.

23

Warning lamp is on Cause Action/Observations


Anti-lock
Braking System (ABS) fi xed.
The anti-lock braking
system has a fault. The vehicle retains conventional braking.
Drive carefully at reduced speed and contact a
PEUGEOT dealer without delay.


Dynamic
stability control
(ESP/ASR) fl ashing.
The ESP/ASR regulation is
active. The system optimises traction and improves the
directional stability of the vehicle.
fi xed. Unless it has been
deactivated with the indicator
lamp on the button on, the
ESP/ASR system is faulty. Have it checked by a PEUGEOT dealer.

Engine
autodiagnosis system fi xed.
The emission control
system has a fault.
This lamp should switch off when the engine is sta
rted.
If it does not switch off, contact a PEUGEOT deale r
urgently.
fl ashing. The engine management
system has a fault. Risk of destruction of the catalytic convertor.
Have it checked by a PEUGEOT dealer.

Low fuel level fi xed. When it fi rst comes on there
remains
approximately
5 litres of
fuel in the tank. You must refuel as soon as possible to avoid
running out of fuel.
This warning lamp will come on every time the
ignition is switched on, until a suffi cient addition
of fuel is made.
Fuel tank capacity: approximately 50 litres
(petrol) or 48 litres (Diesel).
Never continue to drive until you run out of fuel
as this could damage the emission control and
injection systems.

24

Warning lamp is on Cause Action/Observations

Maximum
coolant
temperature fi xed red.
The temperature of the
cooling system is too high. Stop as soon as it is safe to do so.
Wait until the engine has cooled down before
topping up the level, if necessary.
If the problem persists, contact a PEUGEOT
dealer.

Engine oil
pressure fi xed. There is a fault with the
engine lubrication system. Stop as soon it is safe to do so.
Park, switch off the ignition and contact a
PEUGEOT dealer.

Battery
charge fi xed. The battery charging circuit
has a fault (dirty or loose
terminals, slack or cut
alternator belt, ...). This lamp should switch off when the engine is
started.
If it does not switch off, contact a PEUGEOT
dealer.

Door(s) open fi xed if the
speed is
below 6 mph (10 km/h).
A door, the boot or the rear
screen is still open. Close the door or boot.
fi xed and
accompanied
by an audible signal if the speed is
above 6 mph (10 km/h).

Directional
headlamps fl ashing. The directional headlamps
system is faulty. Have it checked by a PEUGEOT dealer.

25

Warning lamp is on Cause Action/Observations

Airbags temporarily.
This lamp comes on for
a few seconds when you
turn on the ignition, then
switches off. This lamp should switch off when the engine is
started.
If it does not switch off, contact a PEUGEOT
dealer.
fi xed. One of the airbag or seat
belt pretensioner systems
has a fault. Have it checked by a PEUGEOT dealer.


Front seat
belt not
fastened/
unfastened fi xed then
fl ashing
accompanied by an
increasing
audible signal. The driver and/or the front
passenger has not fastened
or has unfastened their seat
belt.
Pull the strap then insert the tongue in the
buckle.

Rear seat belt
not fastened/ unfastened fi xed then
fl ashing
accompanied
by an audible signal. One or more rear
passengers have
unfastened their seat belt.

Power
steering fi xed. The power steering has a
fault. Drive carefully at reduced speed.
Have it checked by a PEUGEOT dealer.

Water in
Diesel fi xed. The diesel fi lter contains
water. Risk of damage to the injection system on Diesel
engines.
Contact a PEUGEOT dealer without delay.

Punctured
wheel fi xed. One or more wheels are
punctured or seriously
defl ated. Stop immediately avoiding any sharp action on
the steering wheel or the brakes.
Repair or change the damaged wheel and have
the pressure of the tyres checked as soon as
possible.
