2010 Lancia Delta Owner handbook (in English)

120GETTING TO KNOW YOUR CAR
PARKING SENSORS
(for versions/markets, where provided)
The parking sensors are located in the rear bumper fig. 75
and their function is to inform the driver, through an in-
termittent buzzer, of the presence of obstacles behind the
car.
ACTIVATION/DEACTIVATION
The sensors are automatically activated when the reverse
gear is engaged. As the distance from the obstacle behind
the car decreases, the acoustic alarm becomes more fre-
quent.
fig. 75L0E0059m
BUZZER WARNINGS
When reverse gear is engaged a buzzer warning is acti-
vated if there is an obstacle behind the car. The frequen-
cy of the buzzer varies according to the distance from the
obstacle.
The frequency of the buzzer warning:
❍increases as the distance between the car and the ob-
stacle decreases;
❍becomes continuous when the distance between the car
and the obstacle is less than 30 cm and stops imme-
diately if the distance increases;
❍remains constant if the distance between the car and
the obstacle remains constant.
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 120

GETTING TO KNOW YOUR CAR121
1
Detection distances
Central operating range 140 cm.
Side operating range 60 cm.
If several obstacles are detected by the sensors, only the
nearest one is considered.
FAILURE INDICATIONS
Any faults in the parking sensor system are indicated,
when reverse gear is engaged, by the
èwarning light on
the instrument panel lighting up and a dedicated message
appearing on the multifunctional display.
OPERATION WITH TRAILER
Parking sensor operation is deactivated automatically
when the trailer electric cable plug is fitted into the car
tow hook socket.
The sensors are automatically reactivated when the trail-
er cable plug is disconnected.
The sensor must be clean of mud, dirt, snow
or ice in order for the system to work. Be
careful not to scratch or damage the sensors
while cleaning them. Avoid using dry, rough or hard
cloths. Clean the sensors with clean water with the
addition of car shampoo if necessary. In washing
stations, clean the sensors quickly, keeping the
steam jet/high pressure washing nozzles at least 10
cm away from the sensors.
GENERAL WARNINGS
❍During parking manoeuvres, pay the utmost attention
to any obstacles that could be located above or below
the sensors.
❍Under certain circumstances objects located close to
the car are not detected and could therefore cause dam-
age to the car or be damaged themselves.
The following conditions may influence the performance
of the parking sensor system:
❍Reduced sensor sensitivity and reduced parking aid
system performance could be caused by the presence
of the following on the sensor: ice, snow, mud, multi-
ple layers of paint.
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 121

122GETTING TO KNOW YOUR CAR
❍The sensor detects objects that are not there (“echo dis-
turbance”) caused by mechanical disturbances, for ex-
ample: washing the car, rain (extreme wind condi-
tions), hail.
❍The indications sent by the sensor can also be altered
by the presence of ultrasound devices (e.g. pneumat-
ic brake systems or pneumatic drills) near the car.
❍Parking sensor system performance can also be influ-
enced by the position of the sensors, for example due to
a change in the ride setting (caused by wear to the shock
absorbers, suspension), or by overloading the vehicle and
carrying out specific tuning operations that require the
vehicle to be lowered. The ultimate responsibility when parking
and carrying out other dangerous manoeu-
vres still rests with the driver. When park-
ing, make sure that no-one is standing in the area,
especially children or animals. Parking sensors are
designed to assist drivers: in all cases, you must al-
ways pay the utmost attention during potentially
dangerous manoeuvres, even when these are carried
out a low speed.
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 122

GETTING TO KNOW YOUR CAR123
1
MAGIC PARKING
(for versions/markets, where provided)
The Magic Parking system notifies the driver of a free par-
allel parking space that is a suitable length for the vehi-
cle; it helps the driver when manoeuvring by automati-
cally managing the movement of the steering wheel.During the manoeuvre the driver is also assisted by infor-
mation from the parking sensors (4 front and 4 rear) which
provide further distance information when approaching
obstacles in front of and behind the vehicle.
When looking for a parking space it is helpful if the front
and rear sensors are not activated, whilst during the ma-
noeuvre, the front and rear sensors will be automatically
activated when reverse gear is engaged.
The ultimate responsibility when parking,
however, always rests with the driver. Dur-
ing the entire manoeuvre it it always neces-
sary to make sure that there are no people or ani-
mals in the space.
Parking sensors are designed to assist drivers:
in all cases, you must always pay the utmost
attention during potentially dangerous ma-
noeuvres, even when these are carried out a low
speed: the Magic Parking system does NOT in nay
way adjust the speed of the vehicle during the ma-
noeuvre, the control of the acceleration speed and
braking remain the responsibility of the driver.
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 123

124GETTING TO KNOW YOUR CAR
SENSORS
The system uses the side sensors (see fig. 76) when look-
ing for a parking space.
These sensors are automatically activated below around
30 km/h; during this stage if the driver has just passed a
space that might be useful for a manoeuvre, the function
can be requested using the special button, at this point the
instructions for carrying out the manoeuvre will be shown
on the display; if the function is not requested by the dri-
ver using the special button, no information will be dis-
played on the instrument panel.
fig. 76L0E0240mfig. 77L0E0241m
OPERATION
The assisted parking manoeuvre can only be activated with
the instrument panel on and at speeds below about 30
km/h and is divided into the following stages:
❍Activation: pressing the button fig. 77 activates the
search stage.
❍Search: the system is continuously searching for a free
parking space that is a suitable size for the vehicle using
the side sensors. The driver determines on which side of
the road they intend to park using the direction indicators
(if no information is available from the direction indica-
tors or hazard warning lights, the search takes place on
the passenger side).
IMPORTANT The SEARCH stage in the system logic is
deactivated after about 10 mins if a suitable parking space
is not identified.
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 124

GETTING TO KNOW YOUR CAR125
1
❍Identification: if the system identifies a free parking
space that is a suitable size for the vehicle, it signals its
presence and indicates the actions required for starting the
manoeuvre.
❍Manoeuvre: the driver is asked to engage reverse gear
and leave the steering wheel and manage the accelerator,
brake and clutch (in the case of manual transmission) or
accelerator and brake (in the case of automatic transmis-
sion). The system manages the steering wheel automat-
ically when reverse gear is engaged in the parking posi-
tion.
It suggests that the manoeuvre be concluded in reverse
gear (if the conditions permit) when the continuous sound
of the buzzer for the rear sensors is heard.
IMPORTANT The MANOEUVRE stage in the system log-
ic is deactivated after about 3 mins if the parking ma-
noeuvre has not been completed.❍Conclusion: If parking space is big enough, the ma-
noeuvre is completed by the system in one stage and the
positioning of the vehicle does not require any further in-
tervention on behalf of the driver. If further corrective
manoeuvres are required, the system returns control to the
driver who must complete the manoeuvre manually.
IMPORTANT Steering will be realigned after reversing
when reverse gear is disengaged. The driver must com-
plete the manoeuvre by hand.
The operation of the parking assistance is
based on different components:
❍front and rear parking sensors;
❍side sensors;
❍electric steering;
❍wheels and braking system;
❍instrument panel.
It is necessary to bear in mind that a malfunction
in one of these systems could compromise the op-
eration of the Magic Parking system.
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 125

126GETTING TO KNOW YOUR CAR
fig. 78L0E1015g
DESCRIPTION OF MANOEUVRING STAGES
Activation
The system is activated by pressing the button Fig. 76 and,
as soon as it is activated, the system starts the search stage.
The LED in the button coming on indicates that the sys-
tem is activated.
Since the system recognizes parking spaces even when it
is deactivated, the system can be activated straight away
after having driven past an adjacent parking space that is
deemed suitable. If the system has effectively identified
a parking space, the search stage will not be performed
and the system will notify the driver of the operations re-
quired to carry out the manoeuvre.Searching for a parking space
During the search stage Fig. 78 the vehicle should contin-
ue following its route at a speed of below around 30 km/h
and at a distance of between around 50 cm and 130 cm
from parked cars. A parking space is considered suitable
if it is about 130 cm longer than the dimensions of the ve-
hicle.
There are two possible types of parking:
❍a parking space more than about 160 cm longer than
the dimensions of the vehicle:parking can take place in
one single manoeuvre;
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 126

GETTING TO KNOW YOUR CAR127
1
❍a parking space more than about 130 cm longer than
the dimensions of the vehicle:parking can take place in
several manoeuvres of which only the first takes place with
automatic management of the steering (the subsequent ma-
noeuvres are entirely the responsibility of the driver).
To chose the side on which to search and carry out the ma-
noeuvre, the driver can;
1)
DChoose to carry out the search for the space and
the manoeuvre on the passenger side with:
❍the direction indicator in the middle position;
❍the hazard warning lights on;
❍the hazard warning lights on and the direction indi-
cator in the passenger side position;
❍the direction indicator pointing towards the passenger
side.
2)
FChoose to carry out the search for the space and
the manoeuvre on the driver’s side with:
❍the direction indicator in the driver’s side position;
❍the hazard warning lights on and the direction indi-
cator in the driver’s side position.
The system will notify the driver, on the side in which
the search and the manoeuvre are taking place by means
of dedicated messages in the instrument panel display and
the symbol (
Fand
D) different on the right and left sides. The search will, however, take place on both sides, there-
fore it is possible to make the selection using the direc-
tion indicators even when having just driven past a park-
ing space that is deemed suitable.
During the search stage the speed should be less than
around 30 km/h; if a speed of about 25 km/h is reached
the driver will be advised to decrease the speed, if a speed
of about 30 km/h is exceeded, the system will be deacti-
vated; in this case the system should be reactivated by
pressing button A-fig. 77.
If the Lane Change function is activated (see chapter 1
in the Exterior lights) the search for the parking space
always takes place on the passenger side.
If the parking sensors are activated during the search for
a parking space (see “Front and rear parking sensors”
chapter), the operation of the Magic Parking system is de-
activated.
The manoeuvres of searching for a parking
space and carrying out the parking manoeu-
vre should be carried out following the High-
way Code.
001-142 Delta 3ed gb 30-11-2009 11:22 Pagina 127
