Page 2152 of 4210
FRONT GRILLEEXT-17
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
FRONT GRILLE
Removal and InstallationINFOID:0000000005147320
REMOVAL
1. Remove the bolts and nuts attaching grille.
2. Remove the front grille.
INSTALLATION
Installation is in the reverse order of removal.
1. Front grille 2. J-Clip
AWKIA0022ZZ
Revision: April 20092010 QX56
Page 2153 of 4210

EXT-18
< SERVICE INFORMATION >
COWL TOP
COWL TOP
Removal and InstallationINFOID:0000000005147321
REMOVAL
1. Remove the right and left wiper arms. Refer to WW-79, "Front Wiper Arms".
2. Remove the cowl top seal. • Release the plastics clips on the cowl top seal which go through the cowl tops LH and RH and the cowltop extension.
3. Remove the cowl top covers LH and RH. • Release the plastic clips under the cowl top covers attaching to grommets on hoodledge.
• Disconnect the washer tubes from the wa sher nozzles under the cowl top covers.
4. Remove the cowl top extension brackets LH and RH. • Disconnect the wiper motor harness from the cowl top extension bracket LH.
• The cowl top extension bracket LH must be removed prior to the removal of the wiper motor and con-
necting rod assembly.
5. Remove the wiper motor and connecting rod linkage. Refer to WW-80, "
Wiper Motor and Linkage".
1. Clip CG1042. Clip C103 3. Cowl top cover RH
4. Cowl top seal 5. Drain tube6. Cowl top extension bracket RH
7. Cowl top extension 8. Cowl top extension bracket LH 9. Cowl top cover LH
WIIA0955E
Revision: April 20092010 QX56
Page 2154 of 4210
COWL TOPEXT-19
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
6. Disconnect the windshield washer tube. Refer to WW-81, "Washer Tube Layout".
7. Remove the water cut valve bracket from the cowl top extension. Refer to EXT-18, "
Removal and Installa-
tion".
8. Remove the A/C line bracket from the cowl top extension. Refer to EXT-18, "
Removal and Installation".
9. Remove the drain tube from each side of the cowl top extension.
10. Remove the cowl top extension.
INSTALLATION
Installation is in the reverse order of removal.
Revision: April 20092010 QX56
Page 2155 of 4210
EXT-20
< SERVICE INFORMATION >
FRONT FENDER
FRONT FENDER
Removal and InstallationINFOID:0000000005147322
REMOVAL
1. Remove the headlamp assembly. Refer to EXL-149, "Removal and Installation".
2. Remove the over fender. Refer to EXT-21
.
3. Remove the fender protector. Refer to EXT-23
.
4. Remove the hood stay. Refer to DLK-234, "
Removal and Installation of Hood Assembly".
5. Remove the front fender.
INSTALLATION
Installation is in the reverse order of removal.
1. Front fender 2. Over fender3. Headlamp assembly
4. Fender protector
WIIA0956E
Revision: April 20092010 QX56
Page 2156 of 4210

OVER FENDEREXT-21
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
OVER FENDER
Removal and InstallationINFOID:0000000005147323
REMOVAL
1. Remove the screws from the front and/or rear over fender.
CAUTION:
Never apply tack-paper adhesive remover to body pa nel surface finished with lacquer-based paints.
• Original over fenders are affixed to body panel with double-faced adhesive tape.
2. Heat the over fender to between 30 ° and 40 °C (86° to 104 °F) with a heat gun.
3. Raise the end of the over fender and cut away tape, release the plastic clips and remove the over fender.
Remove all traces of tape.
INSTALLATION
• On vehicles coated with Hard Clear Coat, use double-faced 3M adhesive tape Product No, 4210 or equiva- lent, after priming with 3M primer Product No. N200, C-100 or equivalent.
• The repair parts are also affixed with double-faced adhesive tape.
• To re-use existing over fender, clean all traces of double-faced tape from the over fender and apply new dou-
ble-faced tape to the over fender.
1. Clean the panel surface with isopropyl alcohol or equivalent to degrease the surface.
2. Heat the panel and double-faced tape surface to 30 ° to 40° C (86° to 104 °F).
3. Remove the backing sheet from the tape surface.
4. Align the plastic clips on the back side of the front and/or rear over fender to the mounting grommets.
5. Press the ends by hand and use a roller to apply 5 kg-f (11lbs-f) to press the over fender surface to body panel.
CAUTION:
To secure contact, do not wash vehic le for 24 hours after installation.
1. Clip CG104 2. Front over fender3. Clip CF118
4. Double-faced adhesive tape 5. J-clip 6. Rear over fender
7. Double-faced adhesive tape
WIIA0957E
Revision: April 20092010 QX56
Page 2157 of 4210
EXT-22
< SERVICE INFORMATION >
OVER FENDER
6. Install the front and/or rear over fender screws.
Revision: April 20092010 QX56
Page 2158 of 4210
FENDER PROTECTOREXT-23
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
FENDER PROTECTOR
Removal and InstallationINFOID:0000000005147324
REMOVAL
1. Remove the screws.
2. Remove the plastic clips.
3. Remove the front fender protector.
4. Remove the clips from the fender protector.
INSTALLATION
Installation is in the reverse order of removal.
1. Fender protector (LH shown) 2. Clip C205 3. J-clip
4. Clip 5. Clip CS101
WIIA0958E
Revision: April 20092010 QX56
Page 2159 of 4210
EXT-24
< SERVICE INFORMATION >
LICENSE LAMP FINISHER
LICENSE LAMP FINISHER
Removal and InstallationINFOID:0000000005147325
REMOVAL
1. Remove the back door trim. Refer to INT-21, "Removal and Installation".
2. Disconnect the harness connectors and remove with bulbs from license lamps.
3. Disconnect the back-up lamp bulbs.
4. Disconnect the rear view camera connector.
5. Remove the nuts and screws from the license lamp finisher.
6. Release the clips and remove the license lamp finisher.
INSTALLATION
Installation is in the reverse order of removal.
1. Seal 2. Plastic clip3. Nut
4. License lamp finisher 5. Clip CS101 6. Seal
WIIA0959E
Revision: April 20092010 QX56
