2010 INFINITI QX56 Ignition switch

AV-86
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
FRONT DOOR SPEAKER
1. Connect BOSE speaker amp. connector M112 and suspect
speaker connector.
2. Turn ignition switch to ACC.
3. Push “POWER” switch.
4. Check the signal between BOSE speaker amp. harness connec- tor M112 terminals with CONS ULT-III or oscilloscope.
Is audio signal voltage as specified?
YES >> Replace suspect speaker. Refer to AV-174, "Removal
and Installation".
NO >> GO TO 3.
3.HARNESS CHECK
1. Disconnect AV control unit connector M42 and BOSE speaker amp. connector M113.
2. Check continuity between AV control unit harness connector
M42 (A) and BOSE speaker amp. harness connector M113 (B).
3. Check continuity between AV control unit harness connector M42 (A) and ground.
Are continuity test results as specified?
YES >> GO TO 4.
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
4.FRONT SPEAKER SIGNAL CHECK
Connec-
tor Te r m i n a l
Condition Reference
signal
(+) (-)
M112 45
Receive
audio sig-
nal
813
ALNIA0343GB
SKIA0177E
AB
Continuity
Connector Terminal Connector Terminal
M42 2
M113 18
Ye s
33
2
11 1 9
12 20
A —Contin u it y
Connector Terminal
M42 2
Ground No
3
11
12
ALNIA0416GB
Revision: April 20092010 QX56

AV
FRONT DOOR SPEAKERAV-87
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Connect AV control unit connector and BOSE speaker amp. connector.
2. Turn ignition switch ACC.
3. Push “POWER” switch.
4. Check the signal between AV control unit harness connector M42 terminals with CONSULT-III or oscilloscope.
Are the audio signal voltage readings as specified?
YES >> Replace BOSE speak er amp. Refer to AV-182,
"Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and
Installation".
ConnectorTe r m i n a l s
Condition Reference
signal
(+) (-)
M42 23
Receive
audio sig-
nal
11 1 2
ALNIA0417GB
SKIA0177E
Revision: April 20092010 QX56

AV
FRONT TWEETERAV-89
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Connect BOSE speaker amp. connector M112 and suspect tweeter connector.
2. Turn ignition switch to ACC.
3. Push “POWER” switch.
4. Check the signal between BOSE speaker amp. harness connec- tor M112 terminals with CONSULT-III or oscilloscope.
Is audio signal voltage as specified?
YES >> Replace suspect tweeter. Refer to AV-172, "Removal
and Installation".
NO >> GO TO 3.
3.HARNESS CHECK
1. Disconnect AV control unit connector M42 and BOSE speaker
amp. connector M113.
2. Check continuity between AV control unit harness connector
M42 (A) and BOSE speaker amp. harness connector M113 (B).
3. Check continuity between AV control unit harness connector M42 (A) and ground.
Are continuity test results as specified?
YES >> GO TO 4.
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
4.FRONT SPEAKER SIGNAL CHECK
Connec-
tor Te r m i n a l
Condition Reference
signal
(+) (-)
M112 45
Receive
audio sig-
nal
813
ALNIA0343GB
SKIA0177E
AB
Continuity
Connector Terminal Connector Terminal
M42 2
M113 18
Ye s
33
2
11 1 9
12 20
A —Con tin uit y
Connector Terminal
M42 2
Ground No
3
11
12
ALNIA0416GB
Revision: April 20092010 QX56

AV-90
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
FRONT TWEETER
1. Connect AV control unit connector and BOSE speaker amp.
connector.
2. Turn ignition switch ACC.
3. Push “POWER” switch.
4. Check the signal between AV control unit harness connector M42 terminals with CONSULT-III or oscilloscope.
Are the audio signal voltage readings as specified?
YES >> Replace BOSE speaker amp. Refer to AV-182,
"Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and
Installation".
ConnectorTe r m i n a l s
Condition Reference
signal
(+) (-)
M42 23
Receive
audio sig-
nal
11 1 2
ALNIA0417GB
SKIA0177E
Revision: April 20092010 QX56

AV
CENTER SPEAKERAV-91
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
CENTER SPEAKER
DescriptionINFOID:0000000005146329
The AV control unit sends audio signals to the BOSE s peaker amp. The BOSE speaker amp. amplifies the
audio signals before sending them to the center speaker using the audio signal circuits.
Diagnosis ProcedureINFOID:0000000005146330
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.HARNESS CHECK
1. Disconnect BOSE speaker amp. connector M113 and center speaker connector M110.
2. Check continuity between BOSE speaker amp. harness connec-
tor M113 (A) and center speaker harness connector M110 (B).
3. Check continuity between BOSE speaker amp. harness connec-
tor M113 (A) and ground.
Are continuity test results as specified?
YES >> GO TO 2.
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
2.CENTER SPEAKER SIGNAL CHECK
1. Connect BOSE speaker amp. connector M113 and center speaker connector M110.
2. Turn ignition switch to ACC.
3. Push “POWER” switch.
4. Check the signal between BOSE speaker amp. harness connec- tor M113 terminals with CONSULT-III or oscilloscope.
Is the audio signal voltage reading as specified?
A B Continuity
Connector Terminal Connector Terminal
M113 15
M110 1
Ye s
28 2
A —Contin u it y
Connector Terminal
M113 15
Ground No
28
ALNIA0349GB
Connector Te r m i n a l s
Condition Reference
signal
(+) (-)
M113 15 28 Receive
audio sig-
nal
ALNIA0842GB
SKIA0177E
Revision: April 20092010 QX56

AV-92
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
CENTER SPEAKER
YES >> Replace center speaker. Refer to
AV-173, "Removal and Installation".
NO >> GO TO 3.
3.HARNESS CHECK
1. Disconnect AV control unit connector M42 and BOSE speaker amp. connector M113.
2. Check continuity between AV control unit harness connector
M42 (A) and BOSE speaker amp. harness connector M113 (B).
3. Check continuity between AV control unit harness connector M42 (A) and ground.
Are continuity test results as specified?
YES >> GO TO 4.
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
4.FRONT SPEAKER SIGNAL CHECK
1. Connect AV control unit connector and BOSE speaker amp. connector.
2. Turn ignition switch ACC.
3. Push “POWER” switch.
4. Check the signal between AV control unit harness connector M42 terminals with CONSULT-III or oscilloscope.
Are the audio signal voltage readings as specified?
YES >> Replace BOSE speaker amp. Refer to AV-182,
"Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and
Installation".
AB
Continuity
Connector Terminal Connector Terminal
M42 2
M113 18
Ye s
33
2
11 1 9
12 20
A —Contin u it y
Connector Terminal
M42 2
Ground No
3
11
12
ALNIA0416GB
Connector Te r m i n a l s
Condition Reference
signal
(+) (-)
M42 23
Receive
audio sig-
nal
11 1 2
ALNIA0417GB
SKIA0177E
Revision: April 20092010 QX56

AV-94
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
REAR DOOR SPEAKER
1. Connect BOSE speaker amp.
connectors and suspect speaker
connector.
2. Turn ignition switch to ACC.
3. Push “POWER” switch.
4. Check the signal between BOSE speaker amp. harness connec- tors M112 terminals with CONSULT-III or oscilloscope.
Are audio signal voltage readings as specified?
YES >> Replace suspect speaker. Refer to AV-175, "Removal
and Installation".
NO >> GO TO 3.
3.HARNESS CHECK
1. Disconnect AV control unit connector M42 and BOSE speaker amp. connector M113.
2. Check continuity between AV control unit harness connector
M42 (A) and BOSE speaker amp. harness connector M113 (B).
3. Check continuity between AV control unit harness connector M42 (A) and ground.
Are the continuity test results as specified?
YES >> GO TO 4.
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
4.REAR DOOR SPEAKER SIGNAL CHECK
Connector Te r m i n a l s
Condition Reference
signal
(+) (-)
M112 110
Receive
audio sig-
nal
23
ALNIA0843GB
SKIA0177E
AB

Continuity
Connector Terminal Connector Terminal
M42 4
M113 21
Ye s
52
2
13 23
14 33
A —Contin u it y
Connector Terminal
M42 4
Ground No
5
13
14
ALNIA0418GB
Revision: April 20092010 QX56

AV
REAR DOOR SPEAKERAV-95
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Connect AV control unit connector M42 and BOSE speaker amp. connector M113.
2. Turn ignition switch to ACC.
3. Push “POWER” switch.
4. Check the signal between AV control unit harness connector M42 terminals with CONSULT-III or oscilloscope.
Is the audio signal voltage reading as specified?
YES >> Replace BOSE speak er amp. Refer to AV-182,
"Removal and Installation".
NO >> Replace AV control unit. Refer to AV-169, "
Removal and
Installation".
ConnectorTe r m i n a l s
Condition Reference
signal
(+) (-)
M42 45
Receive
audio sig-
nal
13 14
ALNIA0419GB
SKIA0177E
Revision: April 20092010 QX56
