2010 INFINITI QX56 Ignition switch

AV
POWER SUPPLY AND GROUND CIRCUITAV-69
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Ignition OFF.
2. Check continuity between AV control unit harness connectors M42 and M45 and ground.
Are the continuity results as specified?
YES >> Inspection End.
NO >> Repair AV control unit ground.
DISPLAY UNIT
DISPLAY UNIT : Diagnosis ProcedureINFOID:0000000005146302
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch to ACC
2. Check voltage between display unit harness connector M93 and ground.
Does specified voltage exist?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector.
3. Check continuity between display unit harness connector M93 and ground.
Does continuity exist?
YES >> Inspection end.
Connector (+)
(-)Continuity
Te r m i n a l
M42 20
Ground Yes
M45 65
67
86
87
AWNIA1555ZZ
Signal name Connector Terminal
Ignition switch
position Value (Approx.)
B+ M932
ACC Battery voltage
ACC 3
ALNIA0317GB
(+)
(-)Continuity
Connector Terminal
M93 1
Ground Yes
13
ALNIA0407GB
Revision: April 20092010 QX56

AV-70
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
NO >> Repair harness or connector.
A/C AND AV SWITCH ASSEMBLY
A/C AND AV SWITCH ASSEMBLY : Diagnosis ProcedureINFOID:0000000005146303
Regarding Wiring Diagram information, refer to
AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the A/C and AV switch assembly fuse is not blown.
Is the fuse OK?
YES >> GO TO 2.
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect A/C and AV switch assembly connector M98.
2. Check voltage between the A/C and AV switch assembly con- nector M98 and ground.
Are the voltage results as specified?
YES >> GO TO 3.
NO >> • Check connector housings for disconnected or loose
terminals.
• Repair harness or connector.
3.GROUND CIRCUIT CHECK
1. Ignition OFF.
2. Check continuity between A/C and AV switch assembly harness connector M98 and ground.
Are the continuity results as specified?
YES >> Inspection End.
NO >> Repair A/C and AV switch assembly ground.
BOSE SPEAKER AMP
BOSE SPEAKER AMP : Diagnosis ProcedureINFOID:0000000005146304
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the BOSE speaker amp. fuse is not blown.
Unit Terminal Signal name Fuse No.
A/C and AV switch assembly 2Ignition switch ACC or ON 4
(+)
(-) OFF ACC ON
Connector Terminal
M98 2 Ground 0V Battery
voltage Battery
voltage
ALNIA0315GB
(+) (-) Continuity
Connector Terminal
M98 1 Ground Yes
ALNIA0316GB
Revision: April 20092010 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-71
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
Are the fuses OK?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speak er amp. connector.
3. Check voltage between BOSE speaker amp. harness connector M112 terminal 11 and ground.
Is battery voltage present?
YES >> GO TO 3.
NO >> Check harness between BOSE speaker amp. and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speak er amp. connector.
3. Check continuity between BOSE speaker amp. harness connec-
tor M112 terminal 12 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
WOOFER
WOOFER : Diagnosis ProcedureINFOID:0000000005146305
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the subwoofer fuse is not blown.
Is the fuse OK?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Unit Terminal Signal name Fuse No.
BOSE speaker amp. 11Battery power 31
(+)
(-) Voltage (approx.)
Connector Terminal
M112 11 Ground Battery voltage
ALNIA0339GB
(+) (-)Continuity
Connector Terminal
M112 12Ground Yes
ALNIA0340GB
Unit Terminal Signal name Fuse No.
Subwoofer 6Battery power 17
Revision: April 20092010 QX56

AV-72
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect subwoofer connector.
3. Check voltage between subwoofer harness connector B72 ter-
minal 6 and ground.
Is battery voltage present?
YES >> GO TO 3.
NO >> Check harness between subwoofer and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between subwoofer harness connector B72 terminal 5 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
REAR VIEW CAMERA CONTROL UNIT
REAR VIEW CAMERA CONTRO L UNIT : Diagnosis ProcedureINFOID:0000000005146306
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the following fuses of the rear view camera control unit are not blown.
Are the fuses OK?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between rear view camera control unit harness con-
nector B73 and ground.
Are the voltage readings as specified?
YES >> GO TO 3.
NO >> Check harness between rear view camera control unit and fuse.
(+) (-) Voltage (approx.)
Connector Terminal
B72 6 Ground Battery voltage
ALNIA0367GB
(+) (-)Continuity
Connector Terminal
B72 5Ground Yes
ALNIA0368GB
Unit Terminals Signal name Fuse No.
Rear view camera control unit 1
Battery power 31
2 Ignition switch ACC or ON 4
Signal name Connector TerminalIgnition switch
position Value (Approx.)
Battery power supply B731OFF
Battery voltage
ACC power supply 2 ACC
ALLIA0244ZZ
Revision: April 20092010 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-73
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear view camera control unit connector.
3. Check continuity between rear view camera control unit harness connector B31 terminal 3 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
REAR VIEW CAMERA
REAR VIEW CAMERA : Diagnosis ProcedureINFOID:0000000005146307
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT (REAR VIEW CAMERA SIDE)
Check voltage between rear view camera harness connector D504
and ground.
Is voltage reading approximately 6 volts?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT (CONTINUITY)
1. Turn ignition switch OFF.
2. Disconnect rear view camera and rear view camera control unit connectors.
3. Check continuity between rear view camera harness connector D504 (A) terminal 1 and rear view camera control unit harness
connector B73 (B) terminal 8.
4. Check continuity between rear view camera harness connector D504 (A) terminal 1 and ground.
Are continuity test results as specified?
YES >> GO TO 3.
NO >> Repair harness or connector.
(+) (-) Continuity
Connector Terminal
B31 3 Ground Yes
ALLIA0245ZZ
Signal name Connector Terminal Transmission
position Value (Approx.)
Camera ON signal D504 1 Reverse 6V
ALLIA0243ZZ
AB
Continuity
Connector Terminal Connector Terminal
D504 1 B73 8 Yes
A —Continuity
Connector Terminal
D504 1 Ground No
ALLIA0246ZZ
Revision: April 20092010 QX56

AV-74
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
3.CHECK POWER SUPPLY CIRCUIT (REAR
VIEW CAMERA CONTROL UNIT SIDE)
1. Connect rear view camera control unit harness connector.
2. Turn ignition switch ON.
3. Check voltage between rear view camera control unit harness connector B73 and ground.
Is voltage reading approximately 6 volts?
YES >> Inspection End.
NO >> Replace rear view camera control unit. Refer to AV-189,
"Removal and Installation".
4.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear view camera harness connector.
3. Check continuity between rear view camera harness connector D504 terminal 2 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
DVD PLAYER
DVD PLAYER : Diagnosis ProcedureINFOID:0000000005146308
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK FUSE
Check that the DVD player fuse is not blown.
Is the fuse OK?
YES >> GO TO 2.
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
Signal name Connector Terminal Transmission
position Value (Approx.)
Camera ON signal B73 8 Reverse 6V
ALLIA0247ZZ
Signal nameContinuity
Ground Yes
ALLIA0248ZZ
UnitTerminal Signal name Fuse No.
DVD player 21
Battery power 31
24 Ignition switch ACC or ON 4
Revision: April 20092010 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-75
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Disconnect DVD player connector M205.
2. Check voltage between the DVD player connector M205 and ground.
Are the voltage results as specified?
YES >> GO TO 3.
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
3.GROUND CIRCUIT CHECK
1. Ignition OFF.
2. Check continuity between DVD player harness connector M205 terminal 5 and ground.
Are the continuity results as specified?
YES >> Inspection End.
NO >> Repair DVD player ground.
VIDEO MONITOR
VIDEO MONITOR : Diagnosis ProcedureINFOID:0000000005146309
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT
Check voltage between video monitor harness connector R202 and
ground.
Does specified voltage exist?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
(+) (-) OFF ACC ON
Connector Terminal
M205 21
Ground Batter volt-
age Battery
voltage Battery volt-
age
24 0VBattery
voltage Battery volt-
age
ALNIA0325GB
(+) (-)Continuity
Connector Terminal
M205 5Ground Yes
ALNIA0326GB
Signal name Connector Terminal Ignition switch
position Value (Approx.)
Display B+ R202 11
ACC 12V
12
ALNIA0328GB
Revision: April 20092010 QX56

AV-76
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the video monitor connector R202 and the DVD
player connector M205.
3. Check continuity between the video monitor harness connector R202 (A) and the DVD player connector M205 (B).
4. Check continuity between video monitor harness connector R202 (A) and ground.
Are continuity test results as specified?
YES >> Check DVD player power and ground supply. Refer to AV-68, "AV CONTROL UNIT : Diagnosis
Procedure".
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect video monitor connector.
3. Check continuity between video monitor harness connector
R202 and ground.
Does continuity exist?
YES >> Inspection end.
NO >> Repair harness or connector.
MICROPHONE
MICROPHONE : Diagnosis ProcedureINFOID:0000000005146310
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT
Check voltage between microphone harness connector R109 termi-
nal 4 and ground.
Is approximately 5V present?
YES >> GO TO 3.
NO >> GO TO 2.
AB Continuity
Connector Terminal Connector Terminal
R202 11
M205 9
Ye s
12 25
A -Contin u it y
Connector Terminal
R202 11
Ground No
12
AWLIA1600ZZ
Connector Terminal Ignition switch position Continuity
R202 1
OFF Yes
2
ALNIA0329GB
Signal name Connector Terminal Ignition switch
position Value (Approx.)
MIC power R109 4ON 5V
WKIA5796E
Revision: April 20092010 QX56
