The Tire and Loading Information label also
shows the size of the original equipment tires (C)
and the recommended cold tire inflation
pressures (D). For more information on tires and
inflation see Tires
on page 7 ‑ 58 and Inflation - Tire
Pressure
on page 7 ‑ 65 .
There is also important loading information on the
vehicle Certification/Tire label. It tells you the
Gross Vehicle Weight Rating (GVWR) and the
Gross Axle Weight Rating (GAWR) for the front
and rear axles. See “ Certification/Tire Label ” later
in this section.
Steps for Determining Correct Load Limit 1.
Locate the statement “ The combined weight
of occupants and cargo should never exceed
XXX kg or XXX lbs ” on your vehicle's placard.2.
Determine the combined weight of the driver
and passengers that will be riding in your
vehicle.
3.
Subtract the combined weight of the driver
and passengers from XXX kg or XXX lbs. 4.
The resulting figure equals the available
amount of cargo and luggage load capacity.
For example, if the “ XXX ” amount equals
1400 lbs and there will be five 150 lb
passengers in your vehicle, the amount of
available cargo and luggage load capacity is
650 lbs (1400 − 750 (5 x 150) = 650 lbs).5.
Determine the combined weight of luggage
and cargo being loaded on the vehicle. That
weight may not safely exceed the available
cargo and luggage load capacity calculated in
Step 4. 6.
If your vehicle will be towing a trailer, the load
from your trailer will be transferred to your
vehicle. Consult this manual to determine
how this reduces the available cargo and
luggage load capacity of your vehicle. See
Towing a Trailer
on page 6 ‑ 42 for important
information on towing a trailer, towing safety
rules and trailering tips.
6-33

Black plate (34,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Example 1
Item Description Total
A Vehicle Capacity
Weight for
Example 1 = 1,000 lbs
(453 kg)
B Subtract Occupant
Weight @ 150 lbs
(68 kg) × 2 = 300 lbs (136 kg)
C Available Occupant
and Cargo Weight = 700 lbs (317 kg ) Example 2
Item Description Total
A Vehicle Capacity
Weight for
Example 2 = 1,000 lbs
(453 kg)
B Subtract Occupant
Weight @ 150 lbs
(68 kg) × 5 = 750 lbs (136 kg)
C Available Cargo
Weight = 250 lbs (113 kg)
6-34

Black plate (35,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Example 3
Item Description Total
A Vehicle Capacity
Weight for
Example 3 = 1,000 lbs
(453 kg)
B Subtract Occupant
Weight @ 200 lbs
(91 kg) × 5 = 1,000 lbs
(453 kg)
C Available Cargo
Weight = 0 lbs (0 kg)
Refer to your vehicle's tire and loading information
label for specific information about your vehicle's
capacity weight and seating positions. The combined weight of the driver, passengers,
and cargo should never exceed your vehicle's
capacity weight.
Certification/Tire Label
A vehicle specific Certification/Tire label is
attached to the rear edge of the driver's door.
The label shows the size of your vehicle's original
tires and the inflation pressures needed to obtain
the gross weight capacity of your vehicle. This is
called Gross Vehicle Weight Rating (GVWR).
The GVWR includes the weight of the vehicle,
all occupants, fuel, and cargo.
6-35

Black plate (36,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
The Certification/Tire label also tells you the
maximum weights for the front and rear axles,
called Gross Axle Weight Rating (GAWR). To find
out the actual loads on your front and rear axles,
you need to go to a weigh station and weigh your
vehicle. Your dealer can help you with this. Be
sure to spread out your load equally on both sides
of the center line.
Never exceed the GVWR for your vehicle, or the
GAWR for either the front or rear axle.
And, if you do have a heavy load, you should
spread it out.
{ WARNING: Do not load the vehicle any heavier than
the Gross Vehicle Weight Rating (GVWR),
or either the maximum front or rear Gross
Axle Weight Rating (GAWR). If you do, parts
on the vehicle can break, and it can change
the way the vehicle handles. These could
cause you to lose control and crash. Also,
overloading can shorten the life of the
vehicle.
Your warranty does not cover parts or
components that fail because of overloading.
The label will help you decide how much cargo
and installed equipment your truck can carry.
Using heavier suspension components to get
added durability might not change your weight
ratings. Ask your dealer to help you load your
vehicle the right way.
6-36

Black plate (37,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
If you put things inside your vehicle — like
suitcases, tools, packages, or anything
else — they will go as fast as the vehicle goes.
If you have to stop or turn quickly, or if there is a
crash, they will keep going.
{ WARNING: Things you put inside your vehicle can strike
and injure people in a sudden stop or turn,
or in a crash. .
Put things in the cargo area of your
vehicle. Try to spread the weight evenly. .
Never stack heavier things, like
suitcases, inside the vehicle so that some
of them are above the tops of the seats. .
Do not leave an unsecured child restraint
in your vehicle. .
When you carry something inside the
vehicle, secure it whenever you can. .
Do not leave a seat folded down unless
you need to. There is also important loading information for
off-road driving in this manual. See “ Loading Your
Vehicle for Off-Road Driving ” under Off-Road
Driving on page 6 ‑ 13 .
Add-On Equipment When you carry removable items, you may need
to put a limit on how many people you can carry
inside your vehicle. Be sure to weigh your vehicle
before you buy and install the new equipment. Notice :
Overloading the vehicle may cause
damage. Repairs would not be covered by the
vehicle warranty. Do not overload the vehicle.
Remember not to exceed the Gross Axle Weight
Rating (GAWR) of the front or rear axle.
Automatic Level Control The automatic level control rear suspension
comes as a part of the Road Sensing Suspension.
See Road Sensing Suspension
on page 6 ‑ 9 .
This type of level control is fully automatic and will
provide a better leveled riding position as well as
better handling under a variety of passenger and
loading conditions. An air compressor connected
to the rear shocks will raise or lower the rear of
the vehicle to maintain proper vehicle height.
6-37

Black plate (38,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
The system is activated when the ignition key is
turned to RUN and will automatically adjust
vehicle height thereafter. The system may exhaust
(lower vehicle height) for up to 10 minutes after
the ignition key has been turned to LOCK. You
may hear the air compressor operating when the
height is being adjusted.
If a weight-distributing hitch is being used, it is
recommended to allow the shocks to inflate,
thereby leveling the vehicle prior to adjusting the
height. See “ Weight distributing Hitches and
Weight Carrying Hitches ” under Towing a Trailer
on page 6 ‑ 42 .
Towing Towing Your Vehicle To avoid damage, the disabled vehicle should be towed
with all four wheels off the ground. Consult your dealer
or a professional towing service if the disabled vehicle
must be towed. See Roadside Service on page 9 ‑ 8 .
To tow the vehicle behind another vehicle for
recreational purposes (such as behind a motorhome),
see “ Recreational Vehicle Towing ” following. Recreational Vehicle Towing If the vehicle has a two – mode hybrid engine, see the
Two – mode Hybrid manual for more information.
Recreational vehicle towing means towing the vehicle
behind another vehicle – such as behind a motorhome.
The two most common types of recreational vehicle
towing are known as “ dinghy towing ” (towing the vehicle
with all four wheels on the ground) and “ dolly towing ”
(towing the vehicle with two wheels on the ground and
two wheels up on a device known as a “ dolly ” ).
Here are some important things to consider before
recreational vehicle towing: .
What is the towing capacity of the towing vehicle?
Be sure to read the tow vehicle manufacturer's
recommendations. .
What is the distance that will be travelled? Some
vehicles have restrictions on how far and how long
they can tow. .
Is the proper towing equipment going to be used?
See your dealer or trailering professional for
additional advice and equipment
recommendations. .
Is the vehicle ready to be towed? Just as preparing
the vehicle for a long trip, make sure the vehicle is
prepared to be towed. See Before Leaving on a
Long Trip on page 6 ‑ 26 .
6-38

Black plate (39,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
All-Wheel-Drive Vehicles Dinghy and Dolly Towing
Notice: Towing an all-wheel-drive vehicle with all
four wheels on the ground, or even with only two of
its wheels on the ground, will damage drivetrain
components. Do not tow an all-wheel-drive vehicle
with any of its wheels on the ground.
All-wheel-drive vehicles are not designed to be towed
with any wheels on the ground. If the vehicle must be
towed, see Towing Your Vehicle previously.
6-39

Black plate (40,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Two-Wheel-Drive Vehicles Dinghy Towing
Notice: If a two-wheel-drive vehicle is towed with all
four wheels on the ground, the transmission could
be damaged. The repairs would not be covered by
the vehicle warranty. Do not tow a two-wheel-drive
vehicle with all four wheels on the ground.
Two-wheel-drive vehicles should not be towed
with all four wheels on the ground. Two-wheel-drive
transmissions have no provisions for internal lubrication
while being towed. To dolly tow a two ‐ wheel ‐ drive vehicle, the vehicle must
be towed with the rear wheels on the dolly. See “ Dolly
Towing (Rear Wheels Off the Ground) ” following.
Dolly Towing (Front Wheels Off the Ground)
Notice: If a two-wheel-drive vehicle is towed with
the rear wheels on the ground, the transmission
could be damaged. The repairs would not be
covered by the vehicle warranty. Never tow the
vehicle with the rear wheels on the ground.
6-40
