2010.5 Citroen DS4 Owner's Manual

361
2
3
1
05
DIRECTORY
The telephone directory is sent to the system, depending on the compatibility of the telephone.
The directory is provisional and depends on the Bluetooth connection.
Contacts imported from the telephone to the audio system di rectory are saved in a permanent directory visible to all, whatever the telephone connected.
To modify the contacts saved in the system, press MENU then select " Telephone " and confi rm.
Select " Directory management " and confi rm.
You can:
- " Consult an entry ",
- " Delete an entry ",
- " Delete all entries ".
Select " Directory " to see the list of contacts.
Make a long press on SOURCE for access to the directory
or press OK , and
select " Call " and confi rm.

362
1
206
3
Press  to display the audio settings menu.
The settings available are:
- Ambience,
- Bass,
- Treble,
- Loudness,
- Distribution: Personalised or Driver * ,
- Left/right balance,
- Fader (front/rear balance),
- Auto. volume.
SCREEN C
The distribution, or spatialisation of sound, is an audi
o process which allows the sound quality to be improved according to th e setting chosen, corresponding to the position of the listeners in the vehicle.
AUDIO SETTINGS
* According to equipment.
Select and confi rm " Other settings… " to display the next setting in the list.
The Ambience, Treble and Bass audio settings are different a nd independent for each sound source.

363
5
63
4
07
2
1
CONFIGURATION
SETTING THE DATE AND TIME
Select the setting to be modifi ed. Confi rm by pressing OK , then make the change and confi rm again to save the modifi cation.
Using the arrows, select " Display confi guration " and confi rm.
Press the MENU button.
Using the arrows, select " Personalisation-confi guration " and confi rm.
SCREEN C
Using the arrows, select " Date and time adjustment " and confi rm.
Adjust the settings one by one, confi rming by pressing the OK button. Next select the " OK " tab on the screen then confi rm to exit from the " Date and time adjustment " menu.

364
08 TRIP COMPUTER
Each press of the button, located at the end of the wiper stalk, displays the different trip computer information in succession, depending on the screen.
- the "vehicle " tab with:

365
09
SCREEN C
Multimedia
Media parameters
Choice of playback mode
Choice of track listing
Telephone
Call
Dial
Directory
Calls list
Voice mail box
Directory management
Consult an entry
Delete an entry
Delete all entries
Normal
Random
Random all
Repeat
By folders
By artists
MAIN FUNCTION
Option A1
Option A2
OPTION A
OPTION B
1
2
2
1
2
2
2
2
1
2
2
2
3
3
3
3
3
3
1
2
2
1
By genres
By playlists
Radio parameters
3
3
1
Telephone management
Telephone status
Hang up
1
2
1

366
09 SCREEN MENU MAP
Personalisation-
configuration
Defi ne the vehicle parameters
Access to the vehicle
Plip action
Driving position setting
Unlocking boot only
Driving assistance
Parking brake automatic
Rear wipe in reverse gear
Speeds memorised
Vehicle lighting
Directional headlamps
Daytime lights
Interior lighting
Follow-me-home headlamps
Welcome lighting
Choice of language
Display confi guration
Choice of units
Date and time adjustment
Display parameters
Brightness
Choice of sounds
Trip computer
Vehicle diagnosis *
Bluetooth connection
Connections management
Search for a device
* The parameters vary according to the vehicle.
1
2
3
3
3
2
3
3
3
2
3
3
2
3
3
1
1
2
2
2
2
1
1
1
1

367
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
There is a difference in sound quality between the different audio sources (radio, CD…).
For optimum sound quality, the audio settings (Volume, Bass, Treble, Ambience, Loudness) can be adapted to the different sound sou rces, which may result in audible differences when changing source (rad io, CD…).
Check that the audio settings (Volume, Bass, Treble, Ambience, Loudness) are adapted to the sources listened to. It is advisable to set the AUDIO functions (Bass, Treble, Front-Rear Fader, Left-Right Balance) to the middle position, select the musical ambience "None" and set the loudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
When changing the settings for treble and bass, the ambience setting is deselected.
When changing the ambience setting, treble and bass are reset to zero.
Choosing an ambience imposes settings for treble and bass. Modifying one without the other is not possible. Modify the treble and bass settings or the ambience setting to obtain the desired sound quality.
When changing the balance setting, distribution is deselected.
Choosing a distribution setting imposes a balance setting. Modifying one without the other is not possible. Modify the balance setting or the distribution setting to obtain the desired sound quality.
The following tables contain answers to the most frequently asked questions.

368
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
The quality of reception of the radio station listened to gradually deteriorates or the stored stations do not function (no sound, 87.5 MHz is displayed…).
The vehicle is too far from the transmitter used by the station listened to or there is no transmitter in the geographical area through which the vehicle is travelling.
Activate the RDS function to enable the system to check whether there is a more powerful transmitter in the geographical area.
The environment (hills, buildings, tunnels, basement car parks…) b lock reception, including in RDS mode. This phenomenon is normal and does not indicate a failure of the audio equipment.
The aerial is absent or has been damaged (for example when going through a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to 2 seconds in radio mode. During this brief sound cut-out, the RDS searches for any freque ncy permitting better reception of the station. Deactivate the RDS function if the phenomenon is too frequent and always on the same route.
The traffi c announcement (TA) is displayed. I do not receive any traffi c information.
The radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c information.
The stored stations are not found (no sound, 87.5 MHz is displayed…).
An incorrect waveband is selected. Press the BAND AST button to return to the waveband (AM, FM1, FM2, DAB * ) on which the stations are stored.
* Digital Audio Broadcasting.
